Summary of Contents for Samsung SyncMaster 500s
- Page 1 SyncMaster 500s Color Monitor Owner’s Instructions...
-
Page 2: Unpacking Your Monitor
C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Table Of Contents
Table of Contents Preface: Safety Information Chapter One: Overview of Your Monitor Front Panel Rear Panel Chapter Two: Installation Connecting Your Monitor to a Computer Chapter Three: Adjusting Your Monitor Overview Direct Access Features Contrast Brightness Control Function Features Horizontal Position Vertical Position Parallelogram Horizontal Size... -
Page 4: Preface: Safety Information
Preface: Safety Information Put your monitor in a location with Please read and follow these instruc- low humidity and a minimum of tions when connecting and using your dust. Avoid places like damp computer monitor. basements or dusty hallways. Before connecting the AC power Do not expose the monitor to rain cord to an outlet, make sure the or use it near water (in kitchens,... -
Page 5: Chapter One: Overview Of Your Monitor
Chapter One: Overview of Your Monitor Front Panel Function control buttons Use these buttons to control the shape of the display area, and to control the color qualities of the display image. Adjustment buttons Use the decrease ( – ) button to lower the value of the selected function. -
Page 6: Rear Panel
Chapter One: Overview of Your Monitor Rear Panel Power port Connect the power cable here. Signal port Connect your signal cable here. -
Page 7: Chapter Two: Installation
Chapter Two: Installation Connect the signal cable (with the C o n n e c t i n g Y o u r M o n i t o r adapter if necessary) to the video t o a C o m p u t e r port on the back of your computer. -
Page 8: Chapter Three: Adjusting Your Monitor
Chapter Three: Adjusting Your Monitor O v e r v i e w Your computer monitor allows you to easily adjust the characteristics of the image being displayed. All of these adjustments are made using the control buttons on the front of the monitor. -
Page 9: Control Function Features
Chapter Three: Adjusting Your Monitor Control Function Features The features described in this section can all be accessed using your monitor’s control function buttons. While implementing control functions, the indicator’s color is orange. However, you cannot adjust the display image while a control function is disabled (the indicator’s color is green). -
Page 10: Horizontal Size
Chapter Three: Adjusting Your Monitor Horizontal Size Follow these instructions to change the size of the moni- tor’s entire display. Push this button once to adjust the horizontal size of the entire display. Use the – and + buttons to change the horizontal size (width) of the entire display. -
Page 11: Pincushion
Chapter Three: Adjusting Your Monitor Pincushion Adjust the pincushion setting when the sides of the display are bowed in or bowed out. Push this button once to access the pincushion func- tions. Use the – and + buttons to change the pincushion setting. -
Page 12: Degauss
Chapter Three: Adjusting Your Monitor Degauss The Degauss feature will remove any color impurity caused by magnetic fields. Do not use the Degauss feature more than once within a 30-minute period. Push the button once to activate the degaussing cir- cuit. -
Page 13: Powersaver
DPMS software program to enable the power saving function. Please contact Samsung or your dealer for more information. For energy conservation, turn your monitor OFF when it is... -
Page 14: Troubleshooting
Chapter Three: Adjusting Your Monitor Troubleshooting Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the warranty card, the phone number on the back cover of this manual, or contact your dealer. -
Page 15: Specifications
A p p e n d i x Specifications 38 cm (15”) Full square type [35 cm (13.8") viewable] Picture Tube Flat face, 90° deflection 0.28 Dot pitch Silica coated with anti electrostatic Medium-short persistence phosphor Horizontal: 30 kHz to 55 kHz (automatic) Synchronization Vertical: 50 Hz to 120 Hz (automatic) Unlimited colors... -
Page 16: Appendix
Appendix Pin Assignments Sync Type 15 Pin Side of the Signal Cable (Figure 1) Cable Adapter (Figure 2) Pin No. Separate Composite Apple MAC II GND-R Green Green Blue Blue H/V Sync Sense 0 DDC Return DDC Return Green GND-R GND-R GND-G GND-G... -
Page 17: Fcc Information
A p p e n d i x FCC Information User Instructions The Federal Communications Commission Radio Frequency Interference Statement includes the following warning: NOTE: This equipment has been tested and found to com- ply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 18 A p p e n d i x User Information Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. If necessary, consult your dealer or an experienced radio/television technician for additional suggestions. You may find the booklet called How to Identify and Resolve Radio/TV lnterference Problems helpful.
-
Page 19: Ic Compliance Notice
When used near a radio or TV receiver, it may become the cause of radio interference. Read the instruc- tions for correct handling. MPR II Compliance The SyncMaster 500s monitor complies with SWEDAC (MPR II) recommendations for reduced electric and mag- netic fields. European Notice Manufacturer: Samsung Electronics Co., Ltd. -
Page 20: Index
Index Adapter Adjustment buttons Rear panel Brightness 3, 6 Recall Clear Moiré Safety Connecting Your Monitor to a Computer Signal cable Contrast 3, 6 Signal port Specifications Degauss Stand Display modes timing chart Trapezoid European notice Troubleshooting FCC information VCCI information Front Panel Vertical Position Function control buttons... - Page 22 Fax-on-Demand for product information : Fax. : (93) 261 67 50 1-800-229-2239 CANADA : Samsung Electronics (UK) Ltd. Samsung House, 225 Hook Rise South Samsung Electronics Canada Inc. Surbiton, Surrey KT6 7LD 7037 Financial Drive Mississauga, Ontario L5N 6R3 Tel. : (0181) 391 0168 Tel.
