Product Description
The Wind Flow is a high power 4Pin PWM Controlled Blower to simulate Wind tunnel effect
based on Game telemetry.
Technical Specifications
• Input voltage: 12V 0.9 A DC
• Output power: Up to 10.8W
• Built in standard 4Pin PWM Header
• Dimensions: 140 mm × 130 mm × 39 mm
Connection
• Connect up to two IMMERSION Wind Flow Units with your IMMERSION Wind BOX.
• If required, extend the PWM Cable with a standard extension used in PC Systems.
Installation and Usage Instructions
• Install Simhub: Download the latest version of Simhub from the official website (https://www.
simhubdash.com) and install the software on your PC.
• Establish the connection: Connect the Wind BOX according to the scenario described in its
Manual.
• Connect the Wind Flow: Connect the Unit to the corresponding 4 Pin PWM header of the Wind
BOX.
• Configure the software: Start Simhub and Add the Wind BOX
to your Configuration. Scan the QR Code for the Simhub Setup
Instruction Video. Configure the Wind Flow settings according to
your needs.
Operation
Use Simhub to adjust the Wind Effects to your liking. Switch
between different profiles and scenarios directly in the software.
