Assembly Instructions
Instructions d'assemblage
We're here to help - Do not return this product !
Call, email or find us online first !
If you need help with assembly
If you received a damaged or defective part
If you are missing hardware
We will process replacement parts in 3-5 business days
or less. Parts are shipped via FedEx Ground or mail.
Nous sommes là pour vous - Ne retournez pas ce produit !
Appelez, écrivez ou trouvez-nous en ligne d'abord !
Si vous avez besoin d'aide avec l'assemblage
Si vous avez une pièce manquante ou endommagée
S'il vous manque de la quincaillerie
Nous vous enverrons les pièces de rechange dans un délai de
3 à 5 jours ouvrables, ou moins. Les pièces sont expédiées
via FedEx Ground ou par la poste.
product number
numéro de produit
276003
U
Lot #
Reversible
Ressources disponibles en ligne
How-to Videos
Vidéos d'aide
© 2021 nexeradistribution.com
Email
Courriel
Webpage
Page web
If you bought a headboard with
this bed, you must assemble it first
Si vous avez acheté une tête de lit avec
ce lit, vous devez l'assembler en premier
Réversible
Online resources
FAQ's
Commande de pièces de remplacement
Questions fréquentes
1 877 629-9022
Monday to Friday
7:30 AM - 4 PM - Eastern Time
Lundi au vendredi
7:30h à 16h - Heure normale de l'Est
service@nexeradistribution.com
www.nexeradistribution.com
Weight capacity : 500 lb
Capacité maximale : 500 lb
Order replacement parts
U
90-276003
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 276003 and is the answer not in the manual?

Questions and answers

Summary of Contents for NEXERa 276003

  • Page 1 If you bought a headboard with product number numéro de produit this bed, you must assemble it first 276003 Lot # Si vous avez acheté une tête de lit avec ce lit, vous devez l’assembler en premier Weight capacity : 500 lb Capacité...
  • Page 2 Read these assembly instructions carefully before beginning. Verify that you have in hands all the wood parts and hardware. Keep this document for future reference. Lisez attentivement ce guide d’assemblage avant de débuter. Assurez vous que toutes les composantes de bois et de quincaillerie sont présentes. Conservez ce document. Two people are required to assemble and move this unit.
  • Page 3: Exploded View

    Exploded View Vue éclatée 15X #2213 30X #2214 2X #2212 4X #2219 4X #2211 Drawer Tiroir © 2021 nexeradistribution.com...
  • Page 4 Hardware List / Liste de quincaillerie 20-0203 20-0199 20-2300 20-2200 20-0207 20-2306 20-0120 20-1119 20-2307 20-2215 Cadre de métal avec lattes de bois Metal frame with wood slats 4X #2219 2X #2212 15X #2213 30X #2214 4X #2211 © 2021 nexeradistribution.com...
  • Page 5 ARRÊT STOP Faites un choix maintenant! Make a choice now! - (1) From Page 6 À partir de la page 6 Footboard Drawers are on the right side Pied de lit Les tiroirs sont sur le côté droit (2) From page 13 À...
  • Page 6 STEP/Étape : 1 Install the 8 cam locks # 0203 into the panels G and R Install the 14 push bolts # 2200 on the panels U and T Installez les 8 excentriques # 0203 dans les panneaux G et R Installez les 14 boulons # 2200 sur les panneaux U et T 14X #2200 8X #0203...
  • Page 7 STEP/Étape : 2 Install the 9 cam locks # 0203 into the panels E, M and H Install the 3 push bolt # 2200 on the panels H and M Insert the 2 wood dowels # 0207 into the panel M Installez les 9 excentriques # 0203 dans les panneaux E, M et H Installez les 3 boulons # 2200 sur les panneaux H et M Insérez les 2 goujons de bois # 0207 dans les panneaux M...
  • Page 8 STEP/Étape : 3 Use a hammer to fasten the 8 tack glides # 1119 to the panels T, U, R and M Utilisez un marteau pour installer les 8 patins cloutés # 1119 sur les panneaux T, U, R et M 8X #1119 Unfinished edge Chant non fini...
  • Page 9 STEP/Étape : 4 Use the Allen key # 2300 and the 20 screws # 0199 to fasten the 2 slat supports # 2212 to the panels G and H. Do not overtighten the screws. Utilisez la clé Allen #2300 et les 20 vis #0199 pour fixer le 2 supports de lattes #2212 aux panneaux G et H.
  • Page 10 STEP/Étape : 5 Fasten the panel M to the panel R with # 0111 Screw. Then, tighten the 2 cam locks # 0203 located on panel T with panel R. Fixez le panneau M au panneau R avec la vis # 0111. Ensuite, serrez les 2 excentriques #0203 situés sur le panneau T avec panneau R.
  • Page 11 STEP/Étape : 6 Fasten panel U with panel R. Then, tighten the 2 cam locks # 0203 on panel R Fasten the panels E between U, M and T. Then, tighten the 4 cam locks # 0203 on panels E Fasten panel G and H with panel U and T.
  • Page 12 STEP/Étape : 7 Use the 16 screws # 2215 to fasten the 4 brackets # 2211 to the 4 corners of the bed frame. Refer to the 4 pre-drilled holes in each corner to locate each bracket Utilisez les 16 vis # 2215 pour fixer les 4 équerres #2211 dans les 4 coins de la structure du lit.
  • Page 13 STEP/Étape : 1 Install the 8 cam locks # 0203 into the panels G and R Install the 14 push bolts # 2200 on the panels U and T Installez les 8 excentriques # 0203 dans les panneaux G et R Installez les 14 boulons # 2200 sur les panneaux U et T 14X #2200 8X #0203...
  • Page 14 STEP/Étape : 2 Install the 9 cam locks # 0203 into the panels E, M and H Install the 3 push bolt # 2200 on the panels H and M Insert the 2 wood dowels # 0207 into the panel M Installez les 9 excentriques # 0203 dans les panneaux E, M et H Installez les 3 boulons # 2200 sur les panneaux H et M Insérez les 2 goujons de bois # 0207 dans les panneaux M...
  • Page 15 STEP/Étape : 3 Use a hammer to fasten the 8 tack glides # 1119 to the panels T, U, R and M Utilisez un marteau pour installer les 8 patins cloutés # 1119 sur les panneaux T, U, R et M 8X #1119 Unfinished edge Chant non fini...
  • Page 16 STEP/Étape : 4 Use the Allen key # 2300 and the 20 screws # 0199 to fasten the 2 slat supports # 2212 to the panels G and H. Do not overtighten the screws. Utilisez la clé Allen #2300 et les 20 vis #0199 pour fixer le 2 supports de lattes #2212 aux panneaux G et H.
  • Page 17 STEP/Étape : 5 Fasten the panel M to the panel R with # 0111 Screw. Then, tighten the 2 cam locks # 0203 located on panel T with panel R. Fixez le panneau M au panneau R avec la vis # 0111. Ensuite, serrez les 2 excentriques #0203 situés sur le panneau T avec panneau R.
  • Page 18 STEP/Étape : 6 Fasten panel U with panel R. Then, tighten the 2 cam locks # 0203 on panel R Fasten the panels E between U, M and T. Then, tighten the 4 cam locks # 0203 on panels E Fasten panel G and H with panel U and T.
  • Page 19 STEP/Étape : 7 Use the 16 screws # 2215 to fasten the 4 brackets # 2211 to the 4 corners of the bed frame. Refer to the 4 pre-drilled holes in each corner to locate each bracket Utilisez les 16 vis # 2215 pour fixer les 4 équerres #2211 dans les 4 coins de la structure du lit.
  • Page 20 STEP/Étape : 8 Insert 2 plastic end caps # 2214 to each end of the 15 wood slats # 2213. Each end cap # 2214 should be fully inserted to the end. Insérez 2 embouts en plastique #2214 à chaque extrémité des 15 lattes de bois # 2213.
  • Page 21 STEP/Étape : 9 Insert each end of the 15 wood slats # 2213 into the holes located on the top side of the 2 slat supports # 2212. Apply a pressure on the end cap one side at a time to make it snap into the 2 holes Insérez chaque extrémité...
  • Page 22: Drawer Assembly

    Drawer Assembly Assemblage du tiroir STEP/Étape : 10.1 (2X) Install the 11 cam locks # 0203 into the panels P2 and P4 Install the 11 push bolts # 2200 on the panels P1 and P3 Assemble the # 2307 to the panel P1 Insert the 2 wood dowels # 0207 into the panel P4 Install the casters # 2306 into the panel P4 by using screw # 0120 Assemble panels P1, P2 and P3 first...
  • Page 23 STEP/Étape : 10.2 (2X) Assemble panels P1, P2 and P3 first Then, tighten the 8 cam locks # 0203 located on panel P2 Assemble panel P4 with pre-assembled P1-P2-P3 by using #0199 Assemblez d'abord les panneaux P1, P2 et P3 Ensuite, serrez les 8 verrous à...
  • Page 24 STEP/Étape : 11 Insert the 2 drawers into the unit Insérez les 2 tiroirs dans l’unité © 2021 nexeradistribution.com...
  • Page 25 This warranty is only applicable in Canada and the USA. Nexera reserves the right to request proof of purchase from an authorized retailer as well as any other proofs to document a warranty claim. This warranty is explicit on the limits of Nexera liability and entitles the original purchaser to specific rights.
