Viavito Praia Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Treadmill Owner's Manual.
Praia
Treadmill
www.viavito.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Praia and is the answer not in the manual?

Questions and answers

Related Manuals for Viavito Praia

Summary of Contents for Viavito Praia

  • Page 1 Treadmill Owner’s Manual. Praia Treadmill www.viavito.com...
  • Page 2 Getting Started manual as it will help you to get the most out of your new piece of equipment. How to use Your Viavito Treadmill For more information, or if you require any assistance please email us at Console Feedback Functions support@viavito.com...
  • Page 3 06 There must be 2 metres of clear space behind the running deck where you www.viavito.com...
  • Page 4 Reduce the speed by the treadmill. Remove drops of sweat pressing the ‘-’ speed button. Increase from the treadmill immediately after the speed by pressing the ‘+’ speed finishing training. button. www.viavito.com...
  • Page 5 31 For your safety, only ever use the treadmill in accordance with these instructions. 32 Viavito assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
  • Page 6 Product Overview www.viavito.com...
  • Page 7 Assembly Instructions Step One. 01 Open the package, take out all parts NOTE: Please do not cut down the packing and place the main frame on the flat straps before taking out the whole ground. product from carton. www.viavito.com...
  • Page 8 02 Lock the Base cover metal plate main frame is positioned on a flat level (12L/R) onto the Bottom frame (1) floor. (NOTE: Don’t move it any more.) with hex bolt M8*15 (60) & Serrated lock washer Φ8*1.2 (78). www.viavito.com...
  • Page 9 Right upright tube backlight power (78) as shown; (Only mount the Bolts without Tightening.) lower wire (91) with the Right upright tube backlight power upper wire (93). Finally connect the Computer lower wire (97) with the Computer connect- ing wire (98). www.viavito.com...
  • Page 10 02 Attach the Front armrest (6) to the and Heart rate connecting wire (95); Upright tubes (3L/R) with the Hex bolt M10*15 (60) and Serrated lock washer Φ10*1.2 (78) as shown. (Do not fully tighten bolts at this stage) www.viavito.com...
  • Page 11 05 Insert Bottle case (87) to metal plate G (98) and Computer upper wire (99); of Computer frame (7) 03 Lock the Computer frame (7) to the Rear upright tube (5L/R) and secured with the -hex bolt M8*15 (60) and Ser- rated lock washer Φ8*1.2 (78); www.viavito.com...
  • Page 12 02 As shown picture 2 , Lock the Base 04 Number the images below and remove cover 1 (32L/R) to the Bottom frame the 4th image – Bottom right (1) and secure with the Phillips tapping screw ST4×16 (73); www.viavito.com...
  • Page 13 Folding Instructions When you FOLD the Machine: Put your hands on place A, lift up the machine in the direction of the arrow until you hear the Click sound from the Cylinder (14). www.viavito.com...
  • Page 14 WARNING: Stand clear and ensure the place B of Cylinder (14) with your right area is free of objects when the deck is foot, pull the running deck to the level lowering. of place C, then the running deck will get down automatically. www.viavito.com...
  • Page 15 Technical Parameters ASSEMBLY SIZE 1505*740*1200 POWER AS ORDER (mm) RUNNING 430x1200 MAX OUTPUT AS ORDER SURFACE (mm) POWER NET WEIGHT 53KG INPUTVOLTAGE 220V GROSS WEIGHT 60KG SPEED RANGE 0.8-12 KM/H USER’S WEIGHT 100KG INCLINE 0-12 Operation Instructions. Function specifications www.viavito.com...
  • Page 16 LCD display; B.TIME: Display exercising time, forward timing from 0:00-99:59, when the timing is 99:59, the treadmill smoothly slows down and stops running, consistent with the LCD display; C.DISTANCE: Display current exercising distance, consistent with the LCD display; www.viavito.com...
  • Page 17 Function after Every 100 Minutes single running. 2: Three setting functions under manual mode: time setting, distance setting and K. “Lubrication” reminder: Treadmill total calorie setting. working after Every 300KM, the screen will www.viavito.com...
  • Page 18 59 (100min). operating after 3s of countdown; the initial speed will be 0.8km/h for metric system or 0.5mile/h for imperial system; B. Press SPEED +/ SPEED - to adjust speed; C. Press INCLINE +/ INCLINE - to adjust the incline; www.viavito.com...
  • Page 19 7. Each program is divided into 20 sections; operating time for each section will be 1/20 of the set time. 8. The buzzer will sound for three times when switching from one section to another; www.viavito.com...
  • Page 20 Parameters in fixed program mode (metric system) Time Set time/ 20 =running time for each section section Program Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline www.viavito.com...
  • Page 21 Parameters in fixed program mode (imperial system) Time Set time/ 20 =running time for each section section Program Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline Speed Incline www.viavito.com...
  • Page 22 Initial setting value Setting range Display range Time (m: s) 0:00 30:00 5:00-99:00 0:00-99:59 Speed in metric system (km/h) Speed in imperial 0.8—12.0KMH system (mi/h) 0.5-7.5MPH Incline (%) 0-15 Distance (km/mi) 1.00 0.50—99.90 0.00—99.99 Calorie (kcal) 50.0 10.0—999.0 0.0—999.9 www.viavito.com...
  • Page 23 When connecting to USB in powering on state, the electronic meter can automatically play MP3 format music. Sound volume can be controlled through keys on the panel; please properly adjust the volume to obtain better sound quality and avoid impact to built-in audio circuit. www.viavito.com...
  • Page 24 Whether the sensor Reconnect the motor wire has been open interface, and examine circuited, short the sensor wire. circuited or broken circuited. Whether the sensor Change the sensor. has been broken down, www.viavito.com...
  • Page 25 Failure of the controller 24C02 is broken down or you forgot to install EEPROM 24C02, please change the motor control board. www.viavito.com...
  • Page 26 External AC under-voltage Check whether external AC voltage is lower than 160VAC or if is unstable, if yes, stop using the product and ask the electrical engineers for help. www.viavito.com...
  • Page 27 www.viavito.com...
  • Page 28 www.viavito.com...
  • Page 29 If you reach the recommended beats per minute below and feel you’re • Improve flexibility over-exerting yourself stop, rest and when you feel recovered return to exercise • Lower blood pressure at a lower intensity. • Relieve insomnia www.viavito.com...
  • Page 30 • If you are sore or tired, give yourself you the THR for your age. Always be aware a few extra days to recover. of how you feel when you exercise. If you feel dizzy or light-headed, stop immediately and rest. www.viavito.com...
  • Page 31 • Stretch at least three times a week to reduces the risk of injury. Stretching maintain flexibility. develops flexibility and reduces muscles soreness. Stretches should be held for 15 to 30 seconds. www.viavito.com...
  • Page 32 A proper cool-down slowly lowers your heart rate, allows blood to return to the heart and helps prevent muscle soreness caused by the build-up of lactic acid in the muscles. www.viavito.com...
  • Page 33 Every 30 days the motor and under the belt. At least once a year remove the motor cover and We suggest buying lubricating oil from a vacuum under the it. local distributor or by contacting us. www.viavito.com...
  • Page 34 1/4 turn clockwise, and insert the safety key and power cord. Then start the treadmill and test to con- firm if the belt no longer slips. Repeat the above steps until the belt is moderately tight and does not slip. www.viavito.com...
  • Page 35 www.viavito.com...
  • Page 36 • Precise description of the issue or defect. 5 Mill Square IMPORTANT!! - Please retain your Featherstone Road, sales receipt, viavito Customer Care Wolverton Mill, Milton Keynes may request proof of purchase to validate eligibility for warranty service. MK12 5ZD Warranty cover starts from the date shown on the proof of purchase.
  • Page 37 Repairs not provided by viavito ltd conditions, for a period of 12 months from the date of the original purchase. e) Accidents, lightning, water, fire,...
  • Page 38 Exploded Diagram...
  • Page 39 Running belt Plug Plug Seal ring Speaker cover Oil tube Rear upright tube plug Inner-hex bolt M10*45 Safety key assembly Inner-hex bolt M10*25 Motor cover Inner-hex bolt M10*20 Edgings Phillips tapping screw ST4×12 Rear end cover Inner-hex bolt M8*40 www.viavito.com...
  • Page 40 Audio cable (Optional) Flat washer Φ26*Φ8.2*2.0 USB/Bluetooth module (Optional) Flat washer Φ20*Φ10*2.0 MP3/ Earphone jack (optional) Flat washer Φ8*1.5 Amplifier board (optional) Socket head cap bolt M8*45 110L/R Inductor (optional) Nylon nut M10 Filter (optional) Nylon nut M8 Power wire www.viavito.com...
