Installation Guide
Wall Mount Kitchen Faucets
K-7853
K-7319
M product numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de
M corresponden a México (Ej.
K-12345M)
Français, page" Français-1"
Español, página" Español-1"
1015158-2-C
K-7855, K-7856
K-7320
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kohler K-7853
Summary of Contents for Kohler K-7853
- Page 1 Installation Guide Wall Mount Kitchen Faucets K-7853 K-7855, K-7856 K-7319 K-7320 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page“ Français-1” Español, página“ Español-1” 1015158-2-C...
-
Page 2: Tools And Materials
Carefully inspect waste and supply tubing for any sign of damage. Replace waste or supply tubing if necessary. Kohler Co. reserves the right to make revisions in the design of faucets without notice, as specified within the Price Book. 1015158-2-C... - Page 3 If the eccentric shank has male threads, the nipple should be flush with the front of the wall. Thread one eccentric shank assembly onto each cold and hot nipple. Ensure that each flange is snug against the finished wall. Kohler Co. 1015158-2-C...
- Page 4 Check to see that the faucet assembly is level. If the faucet assembly is not level, turn each cold and hot eccentric shank with a 7/16″ seat wrench. After adjustment, securely tighten each cold and hot coupling nut. 1015158-2-C Kohler Co.
-
Page 5: Installation Checkout
Twist the aerator counterclockwise until it is removed from the spout. Open both hot and cold valves. Run water through the spout for approximately one minute to remove debris. Check for leaks. Remove any debris from the aerator and reinstall. Kohler Co. 1015158-2-C...
