ELECTRIC OPERATED, OIL-FREE PORTABLE AIR COMPRESSORS
Flexzilla® designs and manufactures products for safe operation. However, operators and maintenance persons are
responsible for maintaining safety. All safety precautions are included to provide a guideline for minimizing the
possibility of accidents and property damage while equipment is in operation. Keep these instructions for reference.
WARRANTY INFORMATION
DO NOT RETURN TO RETAILER FOR WARRANTY. MUST RETURN TO MANUFACTURER.
CONTACT LEGACY MFG COMPANY
PHONE: 800-645-8258
Operating, Service and
Warranty Manual
EMAIL: SERVICE@LEGACYMFG.COM
WEBSITE: WWW.FLEXZILLA.COM
(Published 2020-04-01 Revised 2025-01-15)
Advertisement
Table of Contents
Related Manuals for Flexzilla CF10050F
Summary of Contents for Flexzilla CF10050F
- Page 1 Warranty Manual ELECTRIC OPERATED, OIL-FREE PORTABLE AIR COMPRESSORS Flexzilla® designs and manufactures products for safe operation. However, operators and maintenance persons are responsible for maintaining safety. All safety precautions are included to provide a guideline for minimizing the possibility of accidents and property damage while equipment is in operation. Keep these instructions for reference.
-
Page 2: Table Of Contents
Flexzilla Electric Operated, Oil-Free Portable Air Compressors Contents Important Safety Notes - Please read ....3-4 5. Troubleshooting ............7 2. Set Up Instructions ............5 6. Exploded Diagrams ..........8-10 2.1 Initial Set Up ............5 CF10050F ..............8 2.2 Location ...............5 CB20100F / CB20200F ..........9 2.3 Electrical ..............5... -
Page 3: Important Safety Notes - Please Read
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 1. IMPORTANT SAFETY NOTES DANGER Safety Messages & Signal Words: There is a danger of electric shock. Use only undamaged electrical cords. DANGER DO NOT touch bare wires or receptacles. Danger indicates an immediate hazardous situation which, if not DO NOT operate air compressor in wet weather or in wet avoided, will result in death or serious injury. - Page 4 Flexzilla Electric Operated, Oil-Free Portable Air Compressors WARNING DANGER RISK TO BREATHING RISK OF CUTTING Dust or dust-like particulates caused by power-sanding, sawing, Moving parts can cause severe trauma. grinding, drilling or any other construction-like activities can Keep hands and feet away from rotating parts, tie up long hair, contain contaminants that are harmful to breathe.
-
Page 5: Set Up Instructions
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 2. SET UP INSTRUCTIONS 6.) Always shut off the compressor pressure switch before unplugging the compressor. 2.1 Initial Set Up 3. OPERATION 1.) Read safety warnings before setting up air compressor. 3.1 Test Run 2.2 Location... -
Page 6: Maintenance
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 4.3 Draining the Air Tank 8.) To regulate air flow. While the air compressor is running, turn on your tool and turn the regulator The frequency at which you should drain the air knob to the right increasing the pressure. -
Page 7: Troubleshooting
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 5. TROUBLESHOOTING Problem Possible Cause Repair Pressure drop in the tank. Air leaks at connections. Let the compressor build pressure in the tank, to the maximum pressure if possible. Brush soapy water on air connections and look carefully for air bubbles. -
Page 8: Exploded Diagrams
CYLINDER HEAD CONNECTION 36 F CABLE LOCK KIT CODE PART NO. DESCRIPTION RP000540 Flexzilla Portable Air Compressors Replacement Pump and Motor for CF10050F ® RP000541 Flexzilla Portable Air Compressors Pump Repair Kit for CF10050F ® RP000542 Flexzilla Portable Air Compressors Replacement Fan and Cover for CF10050F ®... -
Page 9: Cb20100F/Cb20200F
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 6. EXPLODED DIAGRAMS CB20100F/CB20200F 20 21 22 23 2 3 4 5 37 36 # PART NO./KIT CODE DESCRIPTION QTY. # PART NO./KIT CODE DESCRIPTION QTY. # PART NO./KIT CODE DESCRIPTION QTY. 1 RP000600... -
Page 10: Pre-Operation Checklist
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 7. PRE-OPERATION CHECKLIST FOOT KIT DIAGRAM Initial Set-up: Package Contents: Bolt 1.) Air compressor 2.) Owner’s Manual 3.) Air Filter Kit (2) - Includes pre-assembled unit consisting of male housing, female housing, filter element, and intake tube Elastomer Foot 4.) Anti-Vibration Foot Kit (4) -
Page 11: Location Of Product Labels
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 8. LOCATION OF PRODUCT LABELS PRODUCT LABEL Read these important labels before operating. These labels provide important safety and maintenance information. These labels should be considered as permanent parts of the air compressor. -
Page 12: Check Valve Maintenance
Flexzilla Electric Operated, Oil-Free Portable Air Compressors 9. CHECK VALVE MAINTENANCE (CB20100F / CB20200F MODELS) Figure 1: The check valve is an integral piece to the compressor being able to pump and hold air. It is located on the back of the tank. Prior to any maintenance on the system the air must be fully released. -
Page 13: Warranty
Contact Legacy Manufacturing Co.: 800-645-8258 Email service@legacymfg.com or visit www.flexzilla.com FLEXZILLA and The Flexzilla Stylized X as applied to the body of the air compressor are registered trademarks of Weems Industries, Inc. WARRANTY DO NOT RETURN TO RETAILER FOR WARRANTY. MUST RETURN TO MANUFACTURER.
