Panasonic RE-7392 Service Manual

Panasonic
•
ervlce
R A D I D
anua
Panasonic
FM-AM FM STEREO
TABLE RADIO
MODEL
RE -7392/RE-7392C
• SPECIFICATIONS
Frequency Range:
FM 87.5~108 MHz
AM
525 ~ 1605
kHz
FM 10.7 MHz
Power Consumption :
7.5 W at 120V
Intermediate Frequency:
Sensitivity:
Peak Music Power:
Power Source:
AM 455 kHz
FM 5f.1V for 30 dB Quieting
AM 50f.1V/m for 50 mW Output
4W
AC 120V 60 Hz
Speakers:
Dimensions:
Weight:
I mpedance~
MATSUSHITA ELECTRIC CORP. OF AMERICA
MATSUSHITA ELECTRIC OF HAWAII. INC .
MATSUSHITA ELECTRIC OF CANADA LTD .
ORDE R NO. RD -873
Two 4" PM Dynamic Speaker
17%"(Wide)
x
6%;"(High)
x
6Ys"( Deep)
6 lb . 3 oz.
Speaker ..... .. ........ ... ....... .. 8.0.
FM Antenna Terminal. .... 75.0.
Phono Jack ............ .. .. 500 k.o.
Pan·Am Bldg .. 200 Park Ave. New York. N. Y. 10017
320. Waiakamilo Road Honolulu. Hawaii 96817
40 Ronson Drive. Rexdale. Ont.
