4 2 V W e a t h e r p r o o f N E T W O R K A B L E L C D M O N I T O R
CE42LM4WPN-NA
Weatherproof LCD Monitor
WEATHERPROOF LCD MONITOR
SANYO has used all of its expertise in creating a lightweight
aluminum framed LCD monitor which is protected by anti
reflected tamper glass. This means that the SANYO
weatherproof monitor can be used in a wide variety of
environments due to it having
approval. The SANYO weatherproof LCD will make the ideal
display for the pub courtyards and gardens (perfect due to the
recent no-smoking lows), Digital signage, Industries and public
display
EXTENSIVE INPUT & OUTPUT TERMINALS
The 42LM4WPN has various input and output terminals
including component(Y,Pb,Pr) or RGBHV input and output with
5-BNC, composite video input and output with BNC, and RS-
232 control port (serial D-Sub 9) input and output which offer
the daisy chain connection. There are computer inputs (a D-
Sub 15 RGB terminal) and HDMI input with HDCP for High
definition signals. There are also jacks for an external audio
amp and speakers system (RCA).
ANTI REFLECTION TAMPER GLASS
The 42LM4WPN has a tough anti refection tampered glass.
This offers the protection for the panel surface in the public
display circumstance. The glass is approx. 1/10 less reflection
and 5 times tougher than the usual float glass.
ALUMINUM CABINET & NON HOLES DESIGN
The 42LM4WPN uses Anodized aluminum the same materials
as a sailing boat and it has quite unique 'Non-Holes' ventilation
design which protect against mischief in the public display
applications and less maintenance from dust and oil
circumstance
OPTIONAL PJ-NET ORGANIZER
An optional network box (POA-LN01) makes it possible to use
the 42LM4WPN as a network monitor, using your internet
browser to monitor and control the display's properties.
Additional software is not required.
Issued 06/08
IP56
weather-resistant
S p e c i f i c a t i o n s
Type
Screen Size
Aspect Ratio
Resolution
Brightness
Contrast Ratio
Viewing Angle
Panel tilt angle
Response Time
Computer Compatibility
Audio Amp
Speaker
Input Terminals
AV1
AV2
AV3
Computer 1
HDMI
RS-232
Output Terminals
AV2
AV3
Audio Monitor Output
RS-232
Power Supply
Power Consumption
Operation Temperature
Operation Altitude
Dimensions (WxHxD)
Net Weight
Included Accessories
Optional Accessories
IP Rating
Safety
FCC Rating
Caution:
Due to product design considerations,
please consult with a qualified
installation engineer prior to monitor
ceiling mounting. Ceiling mounting
must be such so the ambient
temperature does not exceed 104°F
and that the proper side-supporting
bracket, specifically designed for
ceilings, is used.
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations. It is not
recommended to install the screen in direct sunlight without adequate shading. Using in direct
sunlight may cause a black shadow to appear on the screen and will disappear when panel
temperature goes down.
Rear Input Panel
Liquid Crystal Display Panel
42V (Landscape / Portrait use available)
Portrait is turning clockwise in 90 degree)
16:9
WXGA 1366 (H) x 768 (V)
500 (cd/m 2 for panel)
800:1 (typical)
178° (Vertical/Horizontal)
90 degree tilt available (panel downward)
8ms (gray to gray)
VGA, SVGA, XGA, SXGA, WXGA, UXGA
N/A
N/A
Video / Audio (Scart)
Component (Y,Pb,Pr) / RGBHV (BNC x 5)
Audio (RCA x 2)
Video (BNC x1)
RGB (D-Sub 15)
HDMI v1.1 w/HDCP
Serial (D-Sub 9)
Component (Y,Pr,Pb) / RGBHV (BNC x 5)
Audio (RCA x 2)
Video (BNC x1)
Audio (RCA x 2)
Serial (D-Sub 9)
AC 100-240V 50-60Hz
225W
Operation 32-115
(Continuous Operation -5 -115°F)
Up to 13, 124ft (4,000m)
41.3" x 25.7" x 6.4" (w/o Option)
82 lbs. (w/o Option)
Owner's Manual; Remote Control w/Batteries;
AC Power Cord
PJ-Net Organizer (POA-LN01)
IP56 Weather Proof
UL60950 2003
CAN/CSA-C22.2
FCC Part15 classB
Optional PJ-Net Organizer
(POA-LN01)
© 2008 SANYO
