ISOLATED USB (4KV) Port: Connect directly to standard USB devices
7
such as a mouse, keyboard or flash drive.
Note: This port is designed for connecting to specialized, electrically
isolated, USB devices.
USB Device Ports: Connect directly to standard USB devices such as a
8
mouse, keyboard or flash drive.
MIC IN Port: Connect to the analog output of a device such as a
9
microphone.
LINE IN Port: Connect to the analog stereo output of a device such as
10
an audio player or PC.
LINE OUT Port: Connect to powered speakers or an amplifier for
11
analog stereo audio output.
REMOTE Port: Connect to specialized RS-232 medical control devices,
12
such as foot switch pedals.
RS-232 Port: This is a standard PC serial port. Connect it to a serial
13
controllable device.
TRIGGER IN 10-pin Terminal Block: Connect to the Trigger Control
14
Keypad (Optional) or any device with trigger switch functionality
such as window security alarms, motion detectors, door switches, etc.
Each of the 8 triggers will activate an assigned unit function when
triggered.
Note: A minimum of 5V DC is required to activate a trigger.
Grounding Screw: Connect to an external electrical ground
15
connection point, if available.
DC 24V Port: Plug the 24V DC power adapter into this port and
16
connect it to an AC wall outlet for power.
