Talius CO-2010 Instructions

or
Press UP or DOWN Press CH+ once, enter
to adjust MINUTE the MO day timer
setting of UP direction,
HOUR twinkles
Effective Timer Channel Selection
(Non Group Control)
or
Under random and auto Press CH+ button
mode, press CH- or CH+ to more than 3S
select the desired channel
......
Finish the timer setting of UP and DOWN
direction of each day; Press time setting
button 3S, HOUR and MINUTE twinkle at
the same time, saving all the setting and
exit the setting status
If the channel flashes, the auto
or random timer setting is invalid;
if no flash, then the timer setting of
this channel has been done circulary
CO-2010
5-channel Timer
Emitter Instruction
Version: A/00
Instruction Of Buttons
LCD
UP
STOP
DOWN
Channel(-) Channel(+)
Setting
(CH-) (CH+)
button
(P2)
Mode
button
CO-2010
5-channel timer emitter
Week
Hour
Manual mode/
Auto mode/
Random mode
Channel number
CO-2010
Technical specification
Battery: 3V (CR2450) Battery life: >2 years
Working temperature: -10℃~50℃ Transmitting power: 25 mW
Warning
1, Emitter couldn't expose to moisture or be striked heavily, or else the emitter life will be affected.
2, If the emitter is not so sensitive or the radio range becomes shorter, pls check whether to change the battery.
3, If the voltage is less than 2.6V, there will be a low voltage indication.
4, Under uni-directional mode, if you press any button more than 20S, while under bi-directional mode, you press any button 5S,
the emitter will stop sending radio signals.
5, It's forbidden to use different type battery to avoid any dangerous risk.
6, Dispose of used batteries properly.
Use a tool (such as Sim card
pin,mini screw driver, fine
Time needle as above) to press the
elastic button meanwhile
setting
push the battery cover down
button
CO-2010
Back
Battery
Up
Minute
Down
LCD
Radio frequency: 433.05~434.79MHz
Radio range: 200 meters outdoor, 35 meters indoor
