Version: A/00
Instruction Of Buttons
UP
STOP
DOWN
CO-2005
Single-channel emitter
Technical specification
Battery: 3V (CR2450)
Working temperature:
-10℃~50℃
Warning
1, Emitter couldn't expose to moisture or be striked heavily, or else the emitter life will be affected.
2, If the emitter is not so sensitive or the radio range becomes shorter, pls check whether to change the battery.
3, Under uni-directional mode, if you press any button more than 20S, while under bi-directional mode, you press any button 5S,
the emitter will stop sending radio signals.
4, It's forbidden to use different type battery to avoid any dangerous risk.
5, Dispose of used batteries properly.
CO-2005
Single-channel Emitter
Instruction
LED
Setting
button
(P2)
CO-2005
Back
Battery life: >2 years
Transmitting power: 10 mW
Use a tool (such as Sim card
pin,mini screw driver, fine
needle as above) to press the
elastic button meanwhile
push the battery cover down
Radio frequency: 433.05~434.79MHz
Radio range: 200 meters outdoor, 35 meters indoor
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Talius CO-2005
Summary of Contents for Talius CO-2005
- Page 1 CO-2005 Single-channel Emitter Instruction Version: A/00 Instruction Of Buttons STOP DOWN Setting Use a tool (such as Sim card button pin,mini screw driver, fine needle as above) to press the (P2) elastic button meanwhile push the battery cover down CO-2005...
- Page 2 Uni-directional / Bi-directional Mode Switch Note: The factory default mode is Bi-directional mode, repeat the same operation to switch the mode circulary. Hold P2 button and install the battery LED flashes once Uni-directional mode Emitter without battery LED flashes twice Bi-directional mode Combination Button Lock / Unlock Operation Note: 1,If there is no operation for 10 seconds, it will automatically exit the setting status.
