VFG54+ LRW
Contact temperature sensor
Datasheet
Subject to technical alteration
Issue date: 08.11.2022 • A120
»
APPLICATION
Sensor with hinged lid enclosure USE for temperature measurement of pipes and round surfaces. Spring loaded brass contact sensor.
»
TYPES AVAILABLE
Contact sensors temperature – active 0..10 V
• VFG54+ LRW
»
SECURITY ADVICE – CAUTION
The installation and assembly of electrical equipment should only be performed by authorized personnel.
The product should only be used for the intended application. Unauthorised modifications are prohibited! The product must not
be used in relation with any equipment that in case of a failure may threaten, directly or indirectly, human health or life or result
in danger to human beings, animals or assets. Ensure all power is disconnected before installing. Do not connect to live/operating
equipment.
Please comply with
• Local laws, health & safety regulations, technical standards and regulations
Condition of the device at the time of installation, to ensure safe installation
•
• This data sheet and installation manual
»
PRODUCT TESTING AND CERTIFICATION
Declaration of conformity
The declaration of conformity of the products are available on our website https://www.thermokon.de/ .
»
NOTES ON DISPOSAL
As a component of a large-scale fixed installation, Thermokon products are intended to be used permanently as part of a building or a
structure at a pre-defined and dedicated location, hence the Waste Electrical and Electronic Act (WEEE) is not applicable. However,
most of the products may contain valuable materials that should be recycled and not disposed of as domestic waste. Please note the
relevant regulations for local disposal.
»
USE ENCLOSURE WITH UV AND WEATHER RESISTANCE
After some time, outdoor mounted plastics can lose their color and quality. Therefore, all USE housings are made of special white polycarbonate
(PC). The light-stable colorants and additives are used to achieve optimum protection of the polymer while maintaining color stability. The titanium
dioxide used is specially developed for polycarbonate and offers excellent UV protection through the reflection of the entire light spectrum including
the UV component by 340 nm. This effectively counteracts the otherwise occurring photochemical polymer degradation. The colors stay full for a
long time without fading. The material is also resistant to cold and frost.
