H-7986, S-20860
PORTABLE PRESSURE
SPRAYER
OPERATING ISSUE
Difficulty in moving pump
handle.
Low pressure and resistance
during pumping.
Leaks from end of spray wand.
Leaks from inside cylinder.
Leaks under cap.
Leaks from shut-off valve.
Leaks from hose.
Pressure relief valve sticks.
PAGE 1 OF 6
1 800 295-5510
uline.ca
TROUBLESHOOTING
CAUSES
Dirty cylinder wall.
O-ring on piston swollen
(not cleaned properly).
Tank cap not tight.
No lubricant on piston/cylinder.
Chemical in cylinder.
Damaged o-ring in pressure
relief valve.
Worn or damaged o-ring in
shut-off valve.
Worn or damaged o-ring in
pump piston.
Worn or damaged o-ring in
shut-off valve.
No lube on piston/cylinder.
Worn or damaged umbrella
valve.
Damaged or missing gasket.
Screw cap not tight.
Worn, damaged or loose
fittings, lack of lubrication.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
RECOMMENDATIONS
Remove piston. Clean, grease
and replace.
Replace o-ring. Grease.
Tighten cap.
Lubricate with heavy grease.
Replace umbrella valve.
Replace o-ring.
Replace o-ring.
Replace o-ring.
Rebuild shut-off valve.
Lubricate piston, o-ring and
cylinder.
Replace umbrella valve at
bottom of cylinder.
Replace gasket.
Tighten tank cap.
Tighten fittings and replace
worn parts, disassemble and
lubricate o-rings.
0225 TS-20860
