- Page 1 Media Board INSTALLATION GUIDE V1.0...
-
Page 2: Table Of Contents
Content Safety And Operation Introduction Installation 4. System Config Care and Maintenance 6. Technical Specification 7. Troubleshooting Warranty Statement For your own safety and that of the product, please read this installation guide carefully before beginning setup and installation. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. -
Page 3: Safety And Operation
Safety And Operation Please read through Safety and Operation before start of the installation. CAUTION - Unplug the power supply from the mains power before connecting any cables as this can damage the products. CAUTION - Avoid looking directly into the LED light source at close range for your own safety. Persons installing this product should make sure: The installation complies with all applicable codes, state and local laws, ordinances, standards and safety regulations. The installation environment is carefully studied and suitable surge protection measure(s) is taken. He or she is qualified for the handling of electrical equipment. Do not attempt to install or use the product until installation instructions and safety labels are fully understood. This product is designed for indoor and outdoor use. Ensure product operates within the specified temperature range. Do not attempt to open the product. Not user serviceable. Do not use the product if any part of it, or the power cables are damaged. Only use product for specified voltage, do not exceed. Always maintain connection to ensure waterproofing. If the product has been subjected to drastic temperature variances, for example, following transportation, do not connect the fixture until it has reached room temperature, as moisture condensation may cause electric shock and product damages. When installing the products and system power supplies, please ensure they will not be exposed to moisture and extreme heat (and direct sunlight for outdoor products). Besides, keep a clean operating environment for the fixtures and system power supplies. Please study this Installation Guide thoroughly and check the latest Technical Specification Sheets available from the Traxon website www.traxon-ecue.com before setup. Any non-compliance of the Installation Guide will void the Traxon warranty. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. -
Page 4: Introduction
Introduction General The Media Board Plus features color-calibrated, controllable ultra-bright SMT LEDs with a 31.25mm [1.23”]/62.5mm [2.46”] pitch, ensuring precise white balance and delivering vivid and vibrant colors. Example applications encompass architectural highlights (on walls, floors, counters, decorative elements) for back lighting in light boxes or stretch ceilings, as well as in light panels, to make an impact at trade fairs. This product is intended for use in high-quality colored light applications. Features: Direct View: RGB − DMX / e:pix Control − Daisy Chain System with quick lock connectors − Auto-addressing − IP20 − Media Board Plus 16PXL Family Maximum Number of Pixels (PXL) MEDIA BOARD PLUS 16PXL BOARD RGB WT 62.5 24VDC MEDIA BOARD PLUS 4PXL ADD ON STRIP RGB WT 62.5 24VDC MEDIA BOARD PLUS 4PXL ADD ON BOARD RGB WT 62.5 24VDC Media Board Plus 64PXL Family Maximum Number of Pixels (PXL) MEDIA BOARD PLUS 64PXL BOARD RGB BL 31.25 24VDC MEDIA BOARD PLUS 8PXL ADD ON STRIP RGB BL 31.25 24VDC MEDIA BOARD PLUS 16PXL ADD ON BOARD RGB BL 31.25 24VDC... -
Page 5: Media Board Plus 16Pxl Board Rgb Wt 62.5 24Vdc
Dimensions 2.2.1 Media Board Plus 16PXL Family MEDIA BOARD PLUS 16PXL BOARD RGB WT 62.5 24VDC FIG.1: Media Board Plus 16PXL Mounting Pattern "D" 230mm [9.06''] Mounting Pattern "C" 170mm [6.69''] Mounting Pattern "B" Mounting Pattern "A" 300mm [11.81''] 125mm [4.92''] 125mm [4.92''] 170mm [6.69''] 187.5mm [7.38''] BACK VIEW FRONT VIEW 1.6mm [0.06''] 12mm [0.47''] TOP VIEW... -
Page 6: Media Board Plus 4Pxl Add On Board Rgb Wt 62.5 24Vdc
MEDIA BOARD PLUS 4PXL ADD ON BOARD RGB WT 62.5 24VDC FIG.3: Media Board Plus 4PXL Add On Board 25mm [0.98''] Mounting Pattern "A" 10mm [0.39''] 185mm [7.28''] 52.5mm [2.07''] 62.5mm [2.46''] 105mm [4.13''] BACK VIEW FRONT VIEW 1.6mm [0.06''] 12mm [0.47''] TOP VIEW 2.2.2 Media Board Plus 64PXL Family MEDIA BOARD PLUS 64PXL BOARD RGB BL 31.25 24VDC FIG.4: ... -
Page 7: Media Board Plus 8Pxl Add On Strip Rgb Bl 31.25 24Vdc
MEDIA BOARD PLUS 8PXL ADD ON STRIP RGB BL 31.25 24VDC FIG.5: Media Board Plus 8PXL Add On Strip 110mm [4.33''] 125mm [4.92''] Ø6mm [Ø0.24''] 224mm [8.82''] 240mm [9.45''] BACK VIEW Mounting Pattern “A” 31.25mm [1.23''] FRONT VIEW 1.6mm [0.06''] 12mm [0.47''] TOP VIEW MEDIA BOARD PLUS 16PXL ADD ON BOARD RGB BL 31.25 24VDC... - Page 8 2.2.3 Accessories FIG.7: Connection Accessories 300mm [11.81”] Converter Cable (For retro fit projects) 500mm [19.69”]/1000mm [39.37”]/3000mm [118.11”]/ 5000mm [196.85]/10000mm [393.7”] Extension Cable 20mm [0.79”]/50mm [1.97”]/100mm [3.94”]/ 500mm [19.69”]/1000mm [39.37”] Gray 24V+ Power Starter Cable (From PSU to Injector box) White GND 200mm [7.87”] Power Injector Cable (To inject new power to existing data)
-
Page 9: Packing Contents
FIG.8: Mounting Accessories DA24102170055: DA24202070555: DA24102170155: BOARD MOUNTING KIT (100x SPACER, 100x SCREWS) BOARD HOLDER, PUNCH VERSION (1,5-2MM SHEET METAL; BOARD HOLDER, DRILL VERSION (WOOD; REQUIRES HOLE REQUIRES HOLE Ø=5.5MM), 12MM (100x) Ø=8MM, >9MM DEEP), 12MM (100x) 6mm [0.24”] 14.3mm [0.56”] 3.7mm [0.15”] 5mm [0.20”] 4mm [0.16”]... - Page 10 2.3.2 Media Board Plus 64PXL Family FIG.10: Packing Contents Mounting Spacers x 4 Mounting Screws x 4 Media Board Plus 64PXL Board RGB x 1 Mounting Spacers x 2 Mounting Screws x 2 Media Board Plus 16PXL Add-on Board RGB x 1 Mounting Spacers x 2 Mounting Screws x 2 Media Board Plus 8PXL Add-on Strip RGB x 1...
-
Page 11: Installation
Installation Points To Consider Plan your installation before mounting the Media Board Plus. The following should be considered for a successful installation. — Ambient temperature of installation site. — Appropriate cable lengths (cable gauges described in system diagram). Please consult your local Traxon office or authorized agent for necessary aid. — The number of the Media Board Plus and appropriate LED Engines. — e:pix / DMX512 to be used to control the Media Board Plus. — Distance between each Board to maintain a consistent pixel pitch. — Mounting distances should be considered. — Proper surge protection. Pre-Installation Checks 3.2.1 Installation Checklist Select suitable mounting kits for different mounting surface/plane. Prepare necessary accessories and tools(spirit level, marking pencil etc). Perform functional check of the Media Board Plus. Take care not to damage cables/ connectors during pre-installation checks. Ensure all the Cables, Media Board Plus RGB and LED Engines are initially stored in a dry area, and they are well organized. Ensure all pre-installation checks laid out above have been followed. 3.2.2 Installation Sequence Measure the correct distances for mounting kits and install the Media Board Plus. -
Page 12: On-Site Installation
On-Site Installation — DO NOT attempt installation in wet or severe weather conditions, especially indoor using products. — DO NOT leave and expose any Media Board Plus RGB or LED Engines unconnected under wet environment. — IP failure induced by stressed/damaged cables during or after installation will not be under warranty. - Page 13 The Media Board Plus are interconnected using the IN and OUT cables/connectors .Connectors will make an audible “click” when connected. Gently pull on the cables in opposites directions to ensure they are fully locked and do not come loose. The below diagram shows the Board connections. (Refer to “4. System Configuration” on page 16 for more details.) FIG.12: Media Board Plus Connections IN OUT IN OUT IN OUT Be sure not to compress the IN/OUT cables. To keep LED pitch consistent, be sure to keep a Specific distance between NOTE consecutive Media Board Plus (See below Mounting Pattern). FIG.13: Media Board Plus 16PXL Family Mounting Pattern Mounting spacer (4x) All Board holder types Mounting Pattern:...
- Page 14 FIG.14: Media Board Plus 64PXL Family Mounting Pattern Mounting spacer (4x) All Board holder types Mounting Pattern: A: Ø6mm; 180mm (I) and 125mm (II); for use with Screw (4x) the supplied spacers and screws. For Screw Spacer only B: Ø4.3mm; 170mm (I) and 170mm (II); for Board holder drill version and punch version. C: Ø4.3mm;...
- Page 15 FIG.15: Set Data Termination Switch Set up the control system indoors as detailed in the system diagram and connect to the Media Board Plus. Start each unit and verify correct function. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 12/24 V1.0 15 of 22...
-
Page 16: System Config
System Configuration FIG.16: System Diagram for Media Board Plus 16PXL Multiple Media Boards Cable 2 BACK VIEW BACK VIEW BACK VIEW BACK VIEW BACK VIEW Cable 1 4Pin M 5 Pin M Cable 3 Cable 2 Cable 2 5 Pin F Multiple Media Boards BACK VIEW BACK VIEW BACK VIEW BACK VIEW BACK VIEW... - Page 17 FIG.17: System Diagram for Media Board Plus 64PXL Cable 2 BACK VIEW BACK VIEW BACK VIEW BACK VIEW BACK VIEW Cable 1 4Pin M 5 Pin M Cable 3 Cable 2 Cable 2 5 Pin F BACK VIEW BACK VIEW BACK VIEW BACK VIEW BACK VIEW 5 x Media Board Plus RGB 64PXL units can be powered by a single LED Engine Smart 100W.
- Page 18 FIG.18: System Diagram for Partial Retrofit Cable 4 Cable 1 Multiple Media Boards Cable 4 4Pin M Cable 2 5 Pin F Cable 3 Cable 2 Cable 2 5 Pin F Multiple Media Boards Cable 4 Cable 2 Cable 2 Cable 3 Cable 2 Cable 2 Multiple Media Boards Cable 4...
-
Page 19: Care And Maintenance
Care and Maintenance Traxon products are of superior design and quality and should be treated with care. The recommendations below will help fulfill any warranty obligations and gain good use and longevity from the products. — Do not attempt or use the product(s) until you read and understand the installation instructions. Failure to adhere to these instructions could result in serious injury or property damage. — Do not use product(s) if cables are damaged. — Do not connect cables and connectors when wet or in wet area. Moisture on bare connectors can cause electric shock and damage to product(s). — Do not use product(s) in extreme heat environment. Ensure there is sufficient airflow and use cool air circulation if required. — Do not drop, knock, or shake product(s). Rough handling can damage the electronics and void the warranty. — Do not use harsh chemicals, cleaning solvents, or strong detergents to clean products. Wipe with a damp cloth on housings and a dry cloth on electronics to remove dirt or dust. — Do not attempt to service or repair the product(s) unless done by an authorized service personnel. Contact your local Traxon office or distributor for details. — If the product is not working as specified, please contact your nearest authorized service center or Traxon Technologies office for assistance. — The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire shall be replaced. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 12/24 V1.0 19 of 22... -
Page 20: Technical Specification
6. Technical Specification For detailed product specifications, please refer to the product data sheet or www.traxon-ecue.com. As with all electronic devices, LED output degrades over time - a term called lumen depreciation. This also explains why it is nearly impossible to expect photometric performances of two LED products with different service life spans to be the same. The rate of LED degradation is a complex function of many factors such as operating efficiency, duration of continuous operation, and operating conditions (e.g. ambient temperature). Because LEDs are semiconductor devices, their performances are subject to inherent variability commonly found in semiconductor industry. To improve consistency in performance across the same product, LED manufacturers “sort” LEDs into bins according to different preset parameters, such as forward driving voltage, illumination, etc. Whereas binning is a sorting function, it is not a correction process. Inherent variability in the manufacturing process always results in different binning distributions according to different production lots. Traxon uses automatically binned LEDs on its products, thereby minimizing output variations within the model range. www.traxon-ecue.com ©2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 12/24 V1.0 20 of 22... -
Page 21: Troubleshooting
7. Troubleshooting CAUTION: Ensure power supply is OFF when disconnecting / connecting cables. Problem Cause Possible Solutions — Product does Incorrect power connection Check Mains Power NOT light up after — Check power supply leads and wire installation connections — Ensure output wires are connected with proper polarity — Check if LED Engine’s secondary output is working as specified. — Check for cables, wires or unwanted debris Shadowing Light source covered covering LED light source —... - Page 22 Please check for the latest updates and changes on the Traxon website. © 2024 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. www.traxon-ecue.com...
