ASSEMBLY INSTRUCTIONS GUIDE
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
TOP SHELF KIT
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
needs. Thank you for choosing StyleWell!
ITEM# xxxx
ITEM# xxxx
ITEM# xxxx
ITEM# xxxx
1-877-527-0313
HOMEDEPOT.CA
THANK YOU
MODEL# 1677015HD
MODEL# 1677341HD
MODEL# 1677342HD
MODEL# 1677356HD
Advertisement
Table of Contents
Related Manuals for StyleWell 1677341HD
Summary of Contents for StyleWell 1677341HD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
-
Page 2: Planning Assembly
L Bracket #8x5/8"(16mm) Flat Screw A54600-3 A54600-4 Wall Anchor #8x1-3/4"(43mm) Flat Screw A54600-5 ITEM # xxxx / MODEL #1677341HD ITEM # xxxx / MODEL #1677342HD ITEM # xxxx / MODEL #1677356HD Parts List Description Quantity Part Code Part Number A54610-1... - Page 3 Part not shown to actual size. ITEM # xxxx / MODEL #1677015HD Parts List Description Quantity Part Code Part Number 31677015010 Shelf ITEM # xxxx / MODEL #1677341HD Parts List Description Quantity Part Code Part Number 31677341010 Shelf ITEM # xxxx / MODEL #1677342HD...
-
Page 4: Tower Installation
Assembly TOWER INSTALLATION: Align shelf bracket with top and front edges of tower. Fasten with two 5/8" wood screws. 1/8" Gap between Bracket edge and wall HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance. - Page 5 Assembly SUPPORT BRACKET INSTALLATION ONTO WALL: NO drilling or anchor required for stud installation! Place support bracket on back wall and mark hole locations. When attaching to wall, screw straight into stud. If you cannot screw into stud, drill " holes in that location and use the wall anchors. Then use screws to attach.
- Page 6 Assembly Sit shelf in place. Shelf Bracket mounted to wall L-Bracket mounted to wall Shelf Shelf Bracket mounted to Tower HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 7 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.CA Retain this manual for future use. HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
