- Page 1 INSTRUCTION MANUAL EAGLE PEAK Vinyl Potting Bench W 43 x D 22 x H 43 in Thank you for choosing Eagle Peak !
- Page 2 Before You Begin: • Please read and save the instruction manual before attempting to use your potting bench. • Keep all heat and flame away from this potting bench. • This is a permanent potting bench, please do not disassemble it after assembly. Table Top 330 lbs Bottom Shelf 200 lbs LIMITED WARRANTY:...
- Page 3 Part List: Description Sketch QTY. Back Left Post 2” x 2” x 43.3” Back Right Post 2” x 2” x 43.3” Front Post 2” x 2” x 32.7” Table Support 1.5” x 3” x 43.3” Shelf Support 1.5” x 3” x 43.3” Side Rail 1.5”...
- Page 4 Dimensions & Specifications: 43.5 in 21.5 in 3.5 in 43.5 in Potting Bench...
- Page 5 Step 1 Insert Narrow Back Rail (8), Wide Back Rail (9), Table Support (4), and Shelf Support (5) into the holes of Back Right Post (2) as shown in the figure. Insert free ends of all rails into corresponding holes of Back Left Post (1).
- Page 6 Step 3 Insert Table Support (4) and Shelf Support (5) into the holes in Front Post (3) as shown in the figure. Insert free ends of all supports into corresponding holes of the other Front Post (3). Post Post Note: The free holes of posts MUST face the same direction. Step 4 Lay the assembly rear side down onto a flat surface, keeping the rail parts...
- Page 7 Step 5 Insert three (3) Potting Bench Rails (#7) into Table Support (#4) of back panel. Insert nine (9) Potting Bench Rails (#7) into the Shelf Support of back panel. Insert four (4) Side Rails (#6) into posts of back panel. Insert free ends of all rails into corresponding holes of front panel with the help of an assistant.
- Page 8 Step 7 Lay out three (3) Table Top Boards (#12). Using a tape measure, mark Table Top Boards (#12) 5.5" from each end. Fasten two (2) Table Braces (#13) to the Table Top Boards using six (6) screws per Table Brace.
- Page 9 Step 9 Lay out Shelf Board (#10) and 2 Metal Plates (#11). Using a tape measure, mark Shelf Board (#10) 6" from each end. Fasten the metal plate to the Shelf board using the two holes in the center of the metal plate. Put Plugs (#15) into both ends of Shelf Board.
- Page 10 Step 11 Wide Back Rail (9) 6" 6" Drill holes in Rail through the reserved holes before screw. Lay out four (4) screws and two (2) Support Brackets (#16), Use a tape measure, mark Shelf Board 6" from each end. Use 2 Screws per bracket, fasten each bracket to Back Rail.
