Dynex DX-LCD32-09 - 32" LCD TV Faqs

I am programming my universal remote, what code is needed?
Please use the Dynex universal remote code website to determine the universal remote code you need:
o
www.dynexproducts.com/universalcontrolcodes.aspx
How do I hook up my external device (e.g., game system, DVD player, VCR, etc.)?
What type of cable are you using?
o
HDMI Cable
•
•
Component Video Cables are red, green and blue. The audio cables will be red and white.
•
•
S-Video Cable has a round end with prongs in a semi-circle and Audio Cables that are red and white.
•
•
•
Composite Cables (A/V Cables, Composite Cables) have a yellow video cable, and red and white audio
cables.
•
•
Dynex 32" LCD HDTV 720p (DX-LCD32-09)
September 30, 2008
Connect an HDMI cable to the HDMI 1 or HDMI 2 jack on the side of your TV and to the HDMI Out
jack on the HDMI device.
To play from an HDMI device:
Turn on the HDMI device, then set it to the correct mode. See the documentation that came
o
with the device for further instructions.
Turn on your TV, then press INPUT. The INPUT SOURCE menu opens.
o
Press ^ or v to select HDMI 1 or HDMI 2, then press ENTER.
o
Connect a component video cable to the COMPONENT IN 1 or COMPONENT IN 2 jacks on the
side of your TV and to the COMPONENT Out jacks on the component device.
To play from a component video device:
Turn on the component video device, then set it to the correct mode. See the
o
documentation that came with the device for further instructions.
Turn on your TV, then press INPUT. The INPUT SOURCE menu opens.
o
Press ^ or v to select COMPONENT 1 or COMPONENT 2, then press ENTER.
o
Connect an S-Video cable to the S-VIDEO jack on the side of your TV and to the S-Video Out jack
on the S-Video device.
Connect an audio cable to the L AUDIO and R AUDIO jacks on the side of your TV and to the
Audio Out jacks on the S-Video Device.
To play from an S-Video Device:
Turn on the S-Video device, then set it to the correct mode. See the documentation that
o
came with the device for further instructions.
Turn on your TV, then press INPUT. The INPUT SOURCE menu opens.
o
Press ^ or v to S-VIDEO, then press ENTER.
o
Connect a composite cable to the AV IN jacks on the side of your TV and to the Video Out and
Audio Out jacks on the composite device.
To play from an Composite Device:
Turn on the Composite device, then set it to the correct mode. See the documentation that
o
came with the device for further instructions.
Turn on your TV, then press INPUT. The INPUT SOURCE menu opens.
o
Press ^ or v to AV, then press ENTER.
o
FAQs
