- Page 1 Installation Guide Wall-Mount Lavatory Faucet Trim K-T14419 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej. K-12345M) Français, page “Français-1” Español, página “Español-1” 1023411-2-B...
-
Page 2: Tools And Materials
Observe all local plumbing and building codes. If needed, complete the finished wall before beginning this installation. Kohler Co. reserves the right to make revisions in the design of faucets without notice, as specified in the Price Book. 1023411-2-B Kohler Co. - Page 3 Apply plumbers putty or other sealant to the back surface of the spout escutcheon according to the putty manufacturer’s instructions. Carefully slide the spout escutcheon over the spout and press firmly against the finished wall. Remove any excess putty or sealant. Kohler Co. 1023411-2-B...
-
Page 4: Install The Handles
Thread an escutcheon onto the threaded sleeve. Remove any excess putty or sealant. Press a handle over the stem extension and move the handle to the closed position (Hot = Counterclockwise, Cold = Clockwise). Lever handles should be horizontal when closed. 1023411-2-B Kohler Co. - Page 5 Thread the handle assembly onto the escutcheon. To maintain the proper handle alignment, hold the handle in place with one hand and turn the base of the handle with the other hand. Repeat the procedures with the second handle. Kohler Co. 1023411-2-B...
-
Page 6: Complete The Installation
Remove the aerator. Open the valves and run water through the spout for about a minute to remove any debris. Check for leaks. Remove all debris from the aerator. Turn the valves off, and reinstall the aerator. 1023411-2-B Kohler Co.
