⑫
SUBWOOFER Output
Connect this SUB WOOFER OUT output to the external audio component input.
⑬
AUDIO Output
These jacks provide fixed audio signal which are used for recording.
⑭
MONITOR Output (S VIDEO)
This jack provides S video signal which are used for recording. (Please refer to monitor output table as below)
⑮
MONITOR Output (VIDEO)
This jack provides video and audio signals which are used for recording. (Please refer to monitor output table as below)
Monitor output table:
(a) Normal mode:
Output
Input
DTV
NTSC
VIDEO1/ VIDEO2
VIDEO3/ VIDEO4
(VIDEO)
VIDEO3/ VIDEO4
(S-VIDEO)
ANALOG RGB
DVI
(b) For POP/PIP mode:
The monitor output is according to user's selected source, the speaker's position.
The output table should be the same with the above table.
⑯
L/MONO /R (VIDEO 1 and VIDEO 2)
Connect audio of external devices.(if you have mono sound, insert the audio cable into the left (L) audio jack).
⑰
Y-P P (VIDEO 1 and VIDEO 2)
B R
Provide Y-P P jacks for connecting equipment with this capability, such as a DVD player or Set Top Box
B R
⑱
NTSC TUNER
RF input that connects to the antenna, cable box, or CATV cable. Support NTSC TV system.
⑲
DTV TUNER
RF input that connects to the antenna, cable box, or CATV cable. Support ATSC TV system.
S-VIDEO VIDEO AUDIO
○ ○
×
○
× ×
×
○
×
○
× ×
× ×
○
○
×
○
○
×
×
