STM Goods DUX Quick Start Manual

KEYBOARD TRACKPAD USB-C
A brilliantly designed keyboard case,
with rugged bump protection, Apple
Pencil 1, Pencil USB-C or Logitech
Crayon storage, full-function trackpad,
and USB-C connectivity to make your
iPad experience even smarter
TRACKPAD GESTURES
Left Click: Press left side of keyboard until
you feel a click to select.
Right Click: Press right side of keyboard
until you feel a click to show quick
action menu.
Click and hold: Press and hold with
one finger.
Wake iPad: Click or tap the trackpad, or
press any key.
Open the Dock: Use one finger to swipe the
pointer past the bottom of the screen.
Go Home: Swipe up with three fingers.
Or, use one finger to swipe the pointer past
the bottom of the screen. After the Dock
appears, swipe the pointer past the bottom
of the screen again.
View Slide Over: Use one finger to swipe the
pointer past the right edge of the screen. To
hide Slide Over, swipe right again.
Open Control Center: Use one finger to
move the pointer to select the status icons
at the top right, then click.
Or, select the status icons at the top right,
then swipe up with one finger.
Open Notification Center: Use one finger to
move the pointer to select the status icons
at the top left, then click.
Or, use one finger to move the pointer past
the top of the screen near the middle.
Open search from the Home Screen: Swipe
down with two fingers.
FEATURES
1 iPAD HOME BUTTON 6 DICTATION/SIRI
Press in any open App
*Siri must be set up
on the iPad (in
2
SCREEN BRIGHTNESS
Settings/Siri &
Decrease
Search) for the Siri
function key to work
3
SCREEN BRIGHTNESS
Increase
7
SCREENSHOT
4
SPOTLIGHT SEARCH
MEDIA
8
On iPad
Previous track
5
TYPE ON-SCREEN
MEDIA
9
Keyboard
Play/Pause
10 MEDIA
Next track
1 2 3 4 5
Scroll Up or Down: Swipe two fingers
up or down.
Scroll Left or Right: Swipe two fingers
left or right.
Open App Switcher: Swipe up with
three fingers, pausing before you lift
your fingers.
Switch Between Open Apps: Swipe left
or right with three fingers.
Open Today View: When the Home
Screen or the Lock Screen is visible,
use two fingers to swipe right. To close
Today View, click the left side of the
trackpad.
SOUND
11 15
Mute
12
VOLUME
16
Decrease
VOLUME
13
Increase 17
14 SWITCH LANGUAGES
(with world icon) If
18
multiple language
keys are set up in the
iPad, use this key to
switch between
languages
19
6 7 8 9 10 1 1 12 13 14
15
Close Apps: In the App Switcher, swipe 2
fingers up to close open apps.
Zoom: Place two fingers near each other. Pinch
open to zoom in, or pinch closed to zoom out.
Open Search From Home Screen: Swipe down
with two fingers.
Secondary Click:
Click with two fingers to show the quick actions
menu for items like icons on the Home Screen,
messages in a mailbox, and the Camera button
in Control Center.
This keyboard is designed to work optimally in the primary region
and language that is printed on the keys. Additional languages that
are added through iPad settings may have different key layouts, and
may not show the same letter/accent on the screen as printed on
the keys.
TRACKPAD
Click, swipe, and scroll
CONNECTION INDICATOR LIGHT
Solid white - keyboard is
connected to iPad
CAPS LOCK INDICATOR LIGHT
• Solid white - On
USB-C PORT
• Charge iPad
• Charge Apple Pencil (using
adapter/cable, not included)
AUX PORT
3.5mm headphone plug
16
18
19
17
