STM Goods DUX Quick Start Manual

KEYBOARD TRACKPAD USB-C
A brilliantly designed keyboard case,
with rugged bump protection, Apple
Pencil 1, Pencil USB-C or Logitech
Crayon storage, full-function trackpad,
and USB-C connectivity to make your
iPad experience even smarter
TRACKPAD GESTURES
Left Click: Press left side of keyboard until
you feel a click to select.
Right Click: Press right side of keyboard
until you feel a click to show quick
action menu.
Click and hold: Press and hold with
one finger.
Wake iPad: Click or tap the trackpad, or
press any key.
Open the Dock: Use one finger to swipe the
pointer past the bottom of the screen.
Go Home: Swipe up with three fingers.
View Slide Over: Use one finger to swipe the
pointer past the right edge of the screen. To
hide Slide Over, swipe right again.
Open Control Center: Use one finger to
move the pointer to select the status icons
at the top right, then click.
Or, select the status icons at the top right,
then swipe up with one finger.
Open Noti cation Center: Use one finger to
move the pointer to select the status icons
at the top left, then click.
Or, use one finger to move the pointer past
the top of the screen near the middle.
Open search from the Home Screen: Swipe
down with two fingers.
FEATURES
1 6
iPAD HOME BUTTON DICTATION/SIRI
Press in any open App
*Siri must be set up
on the iPad (in
2
SCREEN BRIGHTNESS
Settings/Siri &
Decrease
Search) for the Siri
function key to work
3 SCREEN BRIGHTNESS
Increase
7
SCREENSHOT
SPOTLIGHT SEARCH
4
8
MEDIA
On iPad
Previous track
TYPE ON-SCREEN
5
9
MEDIA
Keyboard
Play/Pause
10
MEDIA
Next track
20
15
17 16
19 18
Scroll Up or Down: Swipe two fingers
up or down.
Scroll Left or Right: Swipe two fingers
left or right.
Open App Switcher: Swipe down with
three fingers.
Drag: Click and hold an item, then
slide your finger across the trackpad to
move it.
11 SOUND CONNECTION INDICATOR LIGHT
16
Mute Solid white - keyboard is
connected to iPad
12
VOLUME
Decrease 17 CAPS LOCK INDICATOR LIGHT
• Solid white - On
13 VOLUME
Increase
18 USB-C PORT
• Charge iPad
14 LOCK
• Charge Apple Pencil (using
iPad
adapter/cable, not included)
15 TRACKPAD
19 AUX PORT
Click, swipe,
3.5mm headphone plug
and scroll
20
SWITCH LANGUAGES
If multiple language keyboards
are set up in the iPad, use this
key to switch between languages
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Switch Between Open Apps: Swipe left or
right with three fingers.
Open Today View: When the Home Screen or
the Lock Screen is visible, use two fingers to
swipe right. To close Today View, click the left
side of the trackpad.
Close Apps: In the App Switcher, move the
onscreen pointer to the bottom right corner of
the app, then click and hold the bottom right
corner of the trackpad and drag the app up
past the top of the screen, then release.
