- Page 1 Triex LLC Vermont, USA, Earth 1-802-505-6772 Feedstock Agitator User Manual REV. 1 10/20/2021...
- Page 2 Agitator or damage to the components will occur. • Do not use this device if any parts appear missing or damaged. • Do not modify this device without authorization from Massive Dimension. Contact Massive Dimension with any questions 1-802-505-6772 contact@massivedimension.com...
-
Page 3: General Specifications
General Specifications Power Input: Power Supply Input: 100-240VAC 1.7A Feedstock Agitator Control Box Power Input: 24VDC 1.67A 40Watt... - Page 4 ● 6mm air supply line - 10 ft. ● 24VDC Power Supply MDPH2 Version ● MDPH2 Feed Elbow with Vibrator ● Hopper Connector Bolts - 8-32 Thread Size, 1-1/8" Long QTY 2 ● Enclosure Rivets QTY 4 MDPE10 Version ●...
-
Page 5: Installation
This is the 3D printed part that mates the clear feed tube to the angled metal feed throat extension. 5. Attach the new MDPH2 feed elbow using the two bolts that came with this design. Thread in until both bolts bottom out on the gearbox flange. - Page 6 MDPE10 Installation 1. Begin with your extruder empty of pellets and powered off. 2. Remove the two phillips head screws on the front of the MDPH10 and swing down the front cover to expose the internal components. 3. Remove the four machine bolts that secure the original feed elbow. 4.
-
Page 7: Adjusting The Timer
Adjusting the Timer The timer on the Feedstock Agitator Control Box can be independently adjusted for the OFF time and the ON time of the vibrator. Your desired frequency will be dependent on factors including print speed and feedstock material. A reasonable default setting to begin experimenting with would be OFF for 1 minute, ON for three seconds. - Page 8 2021, Triex LLC, Barre VT, USA. No part of this manual may be copied, stored, transmitted, or otherwise released without the express written consent of Triex LLC. This manual applies only to the Massive DimensionFeedstock Agitator. While Triex LLC has applied all possible caution in producing this manual, we urge the customer or user of this device to contact Triex LLC with any questions or concerns about operation, before operating the device or making any adjustments.
