FOLDING ELECTRIC VELOCITY 2.0 SCOOTER
WARRANTY
So that your warranty is
valid please register at
www.zincsports.com
within 30 days
of receiving the
product.
USER MANUAL
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VELOCITY 2.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zinc VELOCITY 2.0

  • Page 1 FOLDING ELECTRIC VELOCITY 2.0 SCOOTER WARRANTY So that your warranty is valid please register at www.zincsports.com within 30 days of receiving the product. USER MANUAL USER MANUAL...
  • Page 3 INTRODUCTION Hello World How to get help? Thank you for purchasing the Zinc We’re here to help regardless of the issue Velocity 2.0 scooter. you are facing. Visit our Support Page below to access our Servicing & Support The electric scooter industry is still young Centre, as well as to find various ways to...
  • Page 4: Table Of Contents

    Contents WARNING Unboxing Incorrect assembly, maintenance, or use of your Zinc Velocity 2.0 scooter can cause Assembly component or performance failure, loss of Operation control, serious injury, or death. Even if you’re an experienced scooter rider, you must read Settings...
  • Page 6: Unboxing

    Inside you should see protective styrofoam along with the We recommend having the following following contents: items ready prior to starting the setup • Zinc Velocity 2.0 process: • Manual • Box cutters or knife • Charger •...
  • Page 7: Assembly

    Do not operate the scooter if you notice anything wrong with the scooter stem, the safety button, or the locking mechanism. 1. The first step is to unfold your Zinc Velocity 2.0 scooter. To do so, ensure the hook is not clipped into the rear foot rest.
  • Page 8: Attach Handlebar

    Attach handlebar 1. Remove the six hex screws from the handlebars and connect the male connection cable coming out of the handlebar into the female cable coming out of the front stem. Make sure the pins are aligned. 2. Make sure the male port and the female port are aligned properly.
  • Page 9: Perform Test

    Perform test 1. Locate the power button The motor is communicating 2. Test gear change by quickly 3. When you press the right on the right side of the with the controller and pressing the Power Button once. brake handle, the power handlebar and press it identifying its position as well should be cut and the front...
  • Page 10 Remove the Zinc Velocity 2.0 scooter. front light. handlebar. The right signal safety cap and attach the If you experience di culties light should turn on.
  • Page 11: Operation

    OPERATION Charging • Wait 30 minutes after a ride before attempting to charge the battery. This section focuses on how to charge your scooter correctly. • Make sure to unplug your charger before standing on or For information about battery health and best practices, operating your scooter, as this can be very dangerous.
  • Page 12 • In an ideal situation, you would have somewhere secure to store/charge your scooter, such as a shed or garage. It would also be desirable for this area to have plugs where you can charge your scooter. • If you spot any signs of wear and tear or damage, visit our website at http://www.zincsports.com or contact us at customerservices@zinchq.com to buy a replacement charger.
  • Page 13 Folding 1. To fold, begin by locating the safety button and press it to unlock the folding lever. 2. Grab the folding latch, and pull it down to fold the stem. Make sure to keep one hand on the stem at all times as it will drop down instantly after the folding latch is released.
  • Page 14: On/Off Button

    Handlebar features Display Left Turn signal Display The display screen, located on the handlebar, shows you the speed, the battery charge, whether the front and rear lights are on, and any failure displays. 1. Display 1. ON/OFF BUTTON 2. Accelerator throttle Press one time to change the speed mode.
  • Page 15: Turn Signals

    2. TURN SIGNALS SPEED MODE Left arrow button - Press one time to turn on the left turning signal light and it will ACCELERATING FORCE be flashed continuously. Press one more time to turn it o . Right arrow button - Press one time to turn on the right turning signal light and it will be flashed continuously.
  • Page 16: Battery Warning

    BATTERY INFO & LOW BATTERY Charging NOTICE When there is only one battery bar remaining, it is • Do not connect the positive terminal and negative • Charge the scooter fully after every advisable to stop using the scooter if possible and terminal of the battery to each other with any ride.
  • Page 17: General Safety

    WARNING Do not store the battery in temperatures Velocity 2.0 Scooter is designed to be used and operated by riders over the age of 14 years. above 50˚C or below -20˚C. Should the rider have any disabilities or impairments (visual, hearing, language, seizure, etc.), please consult your physician before any ride or purchase of an electric scooter.
  • Page 18 WARNING • • ALWAYS wear comfortable clothes and flat, closed toe shoes when The scooter can be used on paved private land that is flat and even. riding. Never drive in or near puddles of water, mud, sand, stones, gravel, debris •...
  • Page 19: Protective Gear

    You must avoid exposing your scooter to water and system, the steering system and the brake shaft. Maximum and minimum rider weight: 50~100kg humidity. Zinc scooters are not waterproof and are Eliminate any sharp edges caused by use. not designed for extreme or prolonged exposure to...
  • Page 20: Maintenance

    MAINTENANCE WARNING Incorrect assembly, maintenance, or use of your Zinc scooter can cause component or performance failure, loss of control, serious injury, or death. Getting started Tire pressure Regular maintenance is Let’s get started with a tire your electric pump and get •...
  • Page 21: Bearing Lubrication

    and on the travel shaft of the Bearing lubrication Suspension lubrication spring located inside the coil. We recommend purchasing you don’t they will get worn We recommend purchasing Then spray on the top and lithium-based spray very rapidly. lithium-based spray bottom pivot points of the lubricants.
  • Page 22 Drum Brake Adjustment Screw Tightening Note: this section describes a basic 3. Release the line and the lever to check Your scooter motor creates vibrations adjustment to your front drum brake. the brake on the handlebars. If you when you ride it, which may cause the 1.
  • Page 23: Folding Mechanism Adjustment

    Folding Mechanism Adjustment How to Clean Your E-Scooter Wipe with a damp cloth to remove dirt and dust. Do not use 1. Use a 3mm allen wrench to loosen the 2 grub screws on industrial cleaners as they may damage the surfaces. Do not either side by turning counter clockwise.
  • Page 24: Troubleshooting

    Check all wire around the motors and all connectors to make sure they are tight. Battery requires charging. Charge the battery for at least 5 hours if only one light of battery power is on. Motor or electrical switch Contact ZINC damage. customerservices@zinchq.com for diagnosis and repair options.
  • Page 25: Error Codes

    Make sure the connection between the accelerator and display is tight. Loose wires or connection Make sure the connection between the digital display and controller is tight. Short circuit Contact ZINC customer service for diagnosis and repair options. Under voltage Check the battery voltage, and re-charge. Over voltage Check the battery voltage and replace the lithium battery.
  • Page 26: Maintenance Table

    Maintenance Table...
  • Page 27: Warranty

    You must report any defects to Zinc Sports within 30 days of discovery of said defect else the warranty will not be valid. The warranty will not be valid where the user is outside the recommended age group and maximum user weight.
  • Page 28: Spare Parts

    Zinc Sports advice that you contact the warranty if used. your insurance company to determine whether coverage is provided for the use of this scooter, or to take out a new policy.
  • Page 29 We hope you enjoy your Zinc Velocity 2.0 Scooter as much as we loved developing it! If you want to stay connected with us and learn all about our future innovations, you can follow us on social media. @zincsports zincsports.com...
  • Page 30 ©ZINC Hy-Pro Europe Hy-Pro Asia Manufactured by Cube Building, Monahan Road, Room 1011, 10/F, Peninsula Centre, Hy-Pro International Cork, T12H1XY 67 Mody Road, Kowloon, Unit 3, Holla Park, Thorn Road, Houghton Hong Kong Regis, Dunstable, Beds, LU5 6TZ Visit our website for replacement parts and product support WWW.ZINCSPORTS.COM need help? Contact us at customerservices@zinchq.com or call our customer service line on +44(0) 800 731 0006...
