Contents User Manual User Manual flyfine 1 Important information in the manual 1 Important information in the manual 1.1 Scope 1.1 Scope 1.2 Description of FAR-HV 1.3 Meaning of symbols The installation and operation manual applies to the modular battery energy storage system.
User Manual User Manual flyfine flyfine 1.4 General Safety Information Symbols on equipment: The following types of warning, prohibition, and mandatory symbols are also used on the equipment. Danger! Failure to comply with the safety information can lead to life-threatening situations.
User Manual User Manual flyfine flyfine 2 Safety It is forbidden for the freight forwarder to open the outer package of the battery module. Use only approved lifting equipment to move the battery cabinet system. Use only the hanging lug on the top 2.1 Safety rules...
5.4 Description of Rack 5.5 Description of Battery Module 5.4.1 3U-HRack Parts description User Manual High Voltage Rack Mount Battery Series FAR20480 / FAR25600 / FAR30720 / FAR35840 / FAR40960 / FAR46080 / FAR51200 Name Description Battery module negative pole (black) ①...
User Manual User Manual flyfine flyfine 1. Remove the cabinet from the packaging wooden box and move it to the installation Name Description position. The installation position should be level with the cabinet on the ground and have a certain bearing capacity. After placing the cabinet, screw out the four support feet at the ①...
User Manual User Manual flyfine flyfine 2. Connect the battery pack installed in the cabinet as shown in the figure. Before installing 1. Firstly, remove the battery pack from the cardboard box and locate the optional the connecting cable, be sure to wear insulated gloves (do not touch the battery output metal accessories.
Page 9
User Manual User Manual flyfine flyfine 3. After the stacking is complete, fix the battery pack stacking bracket with M5 5. After the system starts, locate the corresponding accessories. Install the protective combination screws. cover as shown in the diagram.
User Manual User Manual flyfine flyfine 6 FAR-HV User Interface 6.2 Engineering mode Enter engineering mode, with the date displayed on the top left, faults displayed between 6.1. User mode date and time, and time displayed on the right; Central display of total voltage, SOC, total Current, highest voltage, lowest voltage, highest temperature, lowest temperature;...
User Manual User Manual flyfine flyfine 6.4 Monomer temperature 2023-10-31 16:22 Click on [Single Body Temperature] to enter the temperature details interface. You can swipe Charged 0 h 0min left and right to view each temperature value, and click to...
User Manual User Manual flyfine flyfine 6.7.3 Accumulated time information 2023-10-31 16:22 Click on 'Accumulated Time Information' to enter the third level interface of accumulated time details. You can view the accumulated discharge time and accumulated charging InslResist Inf time, and click back to the previous page Level interface.
User Manual User Manual flyfine flyfine 8 Disposal 6.9 Fault information interface VoltLine Observe applicable regulations on waste battery disposal. Immediately stop the use of Click on the main interface to enter the fault information interface, where damaged batteries. Please contact your installer or sales partner before disposal. Ensure you can view the fault name and time of occurrence.
