User Manual
Battery Cluster
FBC-107520 / FBC-143360 /
FBC-179200 / FBC-197120 /FBC-215040
ON
RUN
ALM
DC-
BAT-
Power switch
CAN-IN
24VDC
ON/OFF
RS485
COM
+
DC+
BAT+
CAN-OUT
BAT-
BAT+
BAT-
BAT+
COM-IN
COM-OUT
BAT-
BAT+
BAT-
BAT+
BAT-
BAT+
COM-IN
COM-OUT
BAT-
BAT+
BAT-
BAT+
COM-IN
COM-OUT
COM-IN
COM-OUT
COM-IN
COM-OUT
COM-IN
COM-OUT
COM-IN
COM-OUT
User Manual
Advertisement
Table of Contents
Related Manuals for FLYFINE FBC-107520
Summary of Contents for FLYFINE FBC-107520
- Page 1 User Manual Battery Cluster FBC-107520 / FBC-143360 / FBC-179200 / FBC-197120 /FBC-215040 BAT- Power switch CAN-IN 24VDC ON/OFF RS485 BAT+ CAN-OUT BAT- BAT+ BAT- BAT+ COM-IN COM-OUT COM-IN COM-OUT BAT- BAT+ COM-IN COM-OUT BAT- BAT+ BAT- BAT+ COM-IN COM-OUT COM-IN...
-
Page 2: Table Of Contents
3.1 Provisions on Shipping of Battery Modules 4 Preparation 1.2 Description of FBC 4.1 Safety Gear 4.2 Installation tools Model Configuration Rated energy(kwh) 5 Description and installation of FBC battery FBC-107520 107.52 3.2V280Ah(EVE)/120S1P 5.1 Installation precautions FBC-143360 143.36 3.2V280Ah(EVE)/160S1P 5.2 Technical Data 5.3 Description of rack FBC-179200 179.2... -
Page 3: General Safety Information
User Manual User Manual 1.4 General Safety Information Symbols on equipment: The following types of warning, prohibition, and mandatory symbols are also used on the equipment. Danger! Failure to comply with the safety information can lead to life-threatening situations. Attention! Improper use can cause death. -
Page 4: Safety
User Manual User Manual 2 Safety It is forbidden for the freight forwarder to open the outer package of the battery module. Use only approved lifting equipment to move the battery cabinet system. Use only the hanging lug on the top 2.1 Safety rules of the battery cabinet as the connection point. -
Page 5: Preparation
User Manual User Manual 4 Preparation 5.2 Technical Data 4.1 Safety Gear MODEL Cell Chemistry LiFePO4 Module Energy 5.12 Module Nominal 51.2 Safety goggles Safety shoes Insulated gloves Helmet Voltage Modulc Capacity 4.2 Installation tools Cell model / 128S1P Configuration System Nominal 409.6 voltago... -
Page 6: Description Of Rack
User Manual User Manual 5.3 Description of Rack 5.4 Description of Battery Module 5.3.1 FBC Pack Parts description BAT- BAT+ COM-IN COM-OUT Name Description ① Battery module positive pole (orange) BAT+ ② Battery module negative pole (black) BAT- ③ ④ COM-IN Connection position of battery module communication ⑤... -
Page 7: Cabinet-Type Battery Pack Installation
User Manual User Manual 1. Remove the cabinet from the packaging wooden box and move it to the installation Name Description position. Theinstallation position should be level with the cabinet on the ground and have ① a certain bearingcapacity. Power on ②... -
Page 8: User Interface
User Manual User Manual 6 User Interface 3. Connect the battery pack installed in the cabinet as shown in the figure. Before installing the connecting cable, be sure to wear insulated gloves (do not touch the battery output metal terminals with bare hands). The red connector represents the positive pole, while the 6.1. -
Page 9: Engineering Mode
User Manual User Manual 6.2 Engineering mode 6.5 Heating temperature Enter engineering mode, with the date displayed on the top left, faults displayed between date and Click [heating temperature] to enter the heating temperature details interface, slide left and right to time, and time displayed on the right;... -
Page 10: Others
User Manual User Manual 6.7.1 Heating information 6.7.3 Diagnostic Information Click [Diagnostic Information] to enter the diagnostic details three-level interface, click "Diagnostic Click [heating informationl to enter the three-level interface of heating details, you can view the Information" to enter the next interface, and click to return to the higher-level interface. -
Page 11: Set Up
User Manual User Manual 6.8 Set up 7 Maintenance and upgrade Click [Settings] to enter the settings interface, which includes language settings and brightness Warning! settings. Click to return to the upper level interface. Improper decommissioning may cause damage to the equipment and/or battery inverter. Before maintenance, ensure that FBC is decommissioned according to relevant provisions.
