  • Page 2: Table Of Contents

    BSM48106 USER MANUAL ______________________________________ Content 1. Introduction ............................ 3 1.2 Brief Introduction ........................4 1.3 Product Properties ........................4 2. Product Specification ........................5 2.1 Size and Weight ........................5 2.2 Performance Parameter ....................... 6 2.3 Equipment Interface Instruction ..................6 2.4 Battery Management System(BMS) ..................9 2.4.1 BMS Protection and Alarm ..................
  • Page 3: Introduction

    BSM48106 USER MANUAL ______________________________________ 1. Introduction 1.1 Important Safety Instructions Danger! Please do not put the battery into water or fire, in case of explosion or any other situation that might endanger your life. Please connect wires properly while installation, do not reverse connect. To avoid short circuit, please do not connect positive and negative poles with conductor on the same device.
  • Page 4: Brief Introduction

    BSM48106 lithium iron phosphate battery system is a standard battery system unit, customers can choose a certain number of BSM48106HP according to their needs, by connecting series to form a larger capacity battery pack, to meet the user's long-term power supply needs. The product is especially suitable for energy storage applications with high operating temperatures, limited installation space, long power backup time and long service life.
  • Page 5: Product Specification

    BSM48106 USER MANUAL ______________________________________ 2. Product Specification 2.1 Size and Weight BSM48106 Module Control module Battery base Battery...
  • Page 6: Performance Parameter

    Working Temperature 0℃~50℃ Charge -10℃ ~50℃ Disharge Shelf Temperature -20℃~60℃ Certification CE/IEC/UL/UN38.3/MSDS Design Life 10 years+ Cycle Life >6000 2.3 Equipment Interface Instruction This section details the front and back interface functions of the BSM48106HP pack BSM48106 Product Front Interface...
  • Page 7 BSM48106 USER MANUAL ______________________________________ Control Box Module Front Interface Table 2-3 Interface Definition Item Name Definition Power Connector Connect battery in series Screen Show battery information Air Switch Current Protection BMS ON/OFF Start BMS Ground Point Ground Point WiFi WiFi Positive Output DC + To Inverter Negative Output...
  • Page 8 BSM48106 USER MANUAL ______________________________________ 2.3.2 CAN/RS485 interface definition RS485/CAN RS485/CAN Communication to Communication between inverter battery cluster PIN position Color Definition PIN1 Orange/White 485B PIN2 Orange 485A PIN3 Green/White RS485/CAN PIN4 Blue CANH PIN5 Blue/ White CANL PIN6 Green PIN7 Brown/White 485A PIN8...
  • Page 9: Battery Management System(Bms)

    BSM48106 USER MANUAL ______________________________________ 2.3.4 Display Home Page Parameter Page Change Language Parameter Page of detail information Detailed information of cells 2.4 Battery Management System(BMS) 2.4.1 BMS Protection and Alarm Over Voltage Alarm/ Protection in Charging: When total voltage or any battery cell voltage reaches the rated alarm value during charging stage, the alarm light will flash.
  • Page 10: Installation And Configuration

    BSM48106 USER MANUAL ______________________________________ Over Current Protection in Charging: When the charge current > 100A, BMS will stop output, after current lower than 100A, will start automatically. Over Current Protection in Discharging: When the discharge current is higher than 1 0 0 A , BMS will stop output, after current lower than 100A, will start automatically.
  • Page 11: Environmental Requirements

    BSM48106 USER MANUAL ______________________________________ The isolation gloves Safety shoes Safety goggles 3.1.2 Environmental requirements Working temperature: - 1 0 ℃ ~ + 5 0 ℃ Charging temperature range is 0℃~+50℃, Discharging temperature range is - 1 0 ℃ ~ + 5 0 ℃ Storage temperature: - 2 0 ℃...
  • Page 12: Technical Preparation

    BSM48106 USER MANUAL ______________________________________ 3.1.4 Technical preparation Electrical interface check Devices that can be connected directly to the battery can be user equipment, power supplies, or other power supplies. Confirm whether the user's PV power generation equipment, power supply or other power supply equipment has a DC output interface, and measure whether the DC power output voltage meets the voltage range requirements in Table 2-2.
  • Page 13: Equipment Installation

    BSM48106 USER MANUAL ______________________________________ Control 100A Front Module Interface Positive Cable to Red/25mm2 inverter / L2000mm Negative Cable to Black/25mm2 inverter / L2000mm Communication L2000mm Cable to inverter Ground Wire L500mm/4mm2 User Manual 3.2 Equipment installation 3.2.1 Installation Steps Step 1 Mechanical Installation Installation step: Step 3: Install the Control Box Module Step 2: Install the battery pack...
  • Page 14 BSM48106 USER MANUAL ______________________________________ Step 2 Electrical installation (1) Connect with inverter Positive/Negative wire to inverter Communication wire to inverter...
  • Page 15: Installation And Configuration

    BSM48106 USER MANUAL ______________________________________ 4. Installation and Configuration 4.1 Battery system usage and operation instructions After completing the electrical installation, follow these steps to start the battery system. 1. Open the BMS on/off, wait the screen open and show battery with normal status. 2.
  • Page 16 BSM48106 USER MANUAL ______________________________________ Cell voltage Start charging undervoltage 4.3 Analysis and treatment of common faults Analysis and treatment of common faults in the Table 4-2: Table 4-2 Analysis and treatment of common faults Fault phenomenon Reason analysis Solution The indicator does not respond Total voltage lower than 4 0 V * N Check the total voltage after the power on Total...
