- Page 1 TR959M6SE User Manual Tumble Dryer USER MANUAL...
-
Page 2: Table Of Contents
9. BEFORE FIRST USE..................23 10. DAILY USE....................... 25 11. HINTS AND TIPS....................28 12. CARE AND CLEANING..................30 13. TROUBLESHOOTING..................33 14. TECHNICAL DATA................... 36 15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017....................... 38 16. ENVIRONMENTAL CONCERNS..............39 My AEG Care app... -
Page 3: Customer Care And Service
ENGLISH FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 4: Children And Vulnerable People Safety
1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. This appliance can be used by children aged from 8 • years and above and persons with reduced physical, sensory or mental capabilities or lack of experience... - Page 5 ENGLISH houses and other similar accommodation where such use does not exceed (average) domestic usage levels. Do not change the specification of this appliance. • If the tumble dryer is put on top of a washing machine, • use the stacking kit. The stacking kit, available from your authorized vendor, can be used only with the appliance specified in the instructions supplied with the accessory.
- Page 6 WARNING: In the appliance enclosure or in the built - • in structure, keep ventilation opening clear of obstruction. WARNING: Do not damage the refrigerant circuit. • WARNING: Fill the water reservoir for steam treatment • with distilled water only. Do not use tap water or any additives.
-
Page 7: Safety Instructions
ENGLISH 2. SAFETY INSTRUCTIONS 2.1 Installation electrical ratings of the mains power supply. • Always use a correctly installed shockproof socket. Warning: Risk of fire / Flammable • Do not use multi-plug adapters and materials. extension cables. • Remove all the packaging. •... -
Page 8: Internal Lighting
• Clean the appliance with a moist soft WARNING! cloth. Use only neutral detergents. Do Fill the water reservoir for not use abrasive products, abrasive steam treatment with cleaning pads, solvents or metal distilled water only. Do not objects. -
Page 9: Product Description
ENGLISH • Remove the door catch to prevent for the disposal of Waste Electrical children or pets from becoming and Electronic Equipment (WEEE). trapped in the drum. • Dispose of the appliance in accordance with local requirements 3. PRODUCT DESCRIPTION Water container Airflow slots Control panel... -
Page 10: Control Panel
The rating plate reports: A. QR code Mod. xxxxxxxxx Prod.No. 910000000 00 B. model name 000V ~ 00Hz 0000 W C. product number 00000000 D. electrical ratings B C D E. serial number 4. CONTROL PANEL Programmes Start/Pause button... - Page 11 ENGLISH Symbol on the display Symbol description cycle time indication maximum load finish in selection (up to 24h) wireless connection remote control APP notification to check + Anti Crease option on buzzer off child lock on laundry dryness: iron dry, cupboard dry, extra dry Time Dry option on drain the water container indicator:...
-
Page 12: Wi-Fi - Connectivity Setup
QR code can be used in two ways: Frequency 2.412 - 2.472 GHz for • Scan the QR code with the built-in European market camera app to download the My AEG Care application from the App store Protocol IEEE 802.11b/g/n on your smart device and follow the required steps. -
Page 13: Wireless Connection Configuration
Access Point is open for select the programmes around 3 minutes. already available from the 4. Configure the My AEG Care app on appliance control panel, plus your smart device and follow the on unlock additional screen instructions to connect the programmes available only appliance to your WiFi network. -
Page 14: Over-The-Air Update
My AEG Care app provides you with a refer to the "Favourite programmes " wide choice of additional hidden paragraph in "Options" section. programmes. Connect the appliance to My AEG Care and you will be able to choose a drying programme that suits your needs most. - Page 15 ENGLISH Programme names are subject to change depending on market requirements without notice. The My AEG Care app will give you a complete description of each programme. Sportswear Curtains Denim Daily Training Pillow Silk Down Jackets Towels Baby Soccer/Rugby Pet Hair...
- Page 16 Programmes Load Properties / Fabric mark Gently dries for machine and hand-washable wool‐ lens. Remove immediately the items when the pro‐ gramme is completed. 1,0 kg Wool The wool drying cycle of this machine has been ap‐ proved by The Woolmark Company for the drying of wool garments labelled as "hand wash"...
- Page 17 ENGLISH Programmes Load Properties / Fabric mark Ensures proper drying of inner parts Duvet 3,0 kg through single or double duvets, pil‐ lows, and padded blankets. For dry clothes only Short low temperature cycle that helps in removing odours from a 2,0 kg Refresh small amount of garments.
-
Page 18: Consumption Data
Options Dry‐ Steam Time + Anti Programmes ness Lev‐ Silent Crease Duvet Refresh 1) Aside from the programme, you can set one or more options at the same time. 2) Touch Steam option to select steam level 1,2,3 3) Set by default... -
Page 19: Options
ENGLISH Energy consump‐ Program Spun at / residual humidity Drying time tion 800 rpm / 50% 76 min 0,62 kWh 1) For partial loads, the cycle time is shorter and appliance uses less energy. 2) Improper ambient temperature and/or poorly centrifuged laundry can prolong cycle time and increase the energy consumption. -
Page 20: Favourite Programmes
Once the washing programme has come to an end, the washing machine transfers the programme data via the home router Wi-Fi to the AEG Cloud, as well as to your tumble dryer. In order to use the SyncDry function, the AEG tumble... -
Page 21: Steam Function
ENGLISH retrieving is unsuccessful, the button LED is switched off and the machine gives an acoustic error signal. Then When SyncDry programme previously selected programme is is set, user is still allowed to restored. change options or select another program by rotating 5. - Page 22 Steam This option is to set the required steam load. It depends on the: type, weight and volume of the laundry. There are 3 possible selections: minimum load moderate load maximum load 5. Put the water container. The icon alerts you when the steam tank is empty.
-
Page 23: Before First Use
ENGLISH Steam chart Programmes / types of Steam Load the clothes minimum level 0,5 - 1 kg moderate level 1 - 1,5 kg Cottons maximum level 1,5 - 2kg minimum level 1 - 2 items moderate level 3 - 4 items Cottons / shirts maximum level... - Page 24 After product unpacking you can feel an Working fans. unusual smell. This is normal for brand new products. Appliance is built of several different types of material which all together can generate unusual smell. Over usage time, after few drying cycles unusual smell gradually disappears.
-
Page 25: Daily Use
ENGLISH 10. DAILY USE 10.1 Preparing the laundry • Do not dry large and small items together. Small items can be trapped Very often the clothes after inside the large items and remain wet. washing cycle are kneaded • Shake the large clothes, fabrics and tangled altogether. -
Page 26: Loading The Laundry
10.2 Loading the laundry 10.5 Setting a programme CAUTION! Ensure the laundry is not trapped between the appliance door and the rubber seal. Use the programme dial to set the programme. The approximate programme duration appears on the display. -
Page 27: Child Lock Option Activation
ENGLISH You can activate the child lock option: After setting a drying programme, the icon lights up on the display • before you touch the Start/Pause if the programme supports it. button - the appliance cannot start Touching the Start/Pause button, the •... -
Page 28: Programme End
10.11 Programme end 2. Open the appliance door. 3. Remove the laundry. Clean the filter and drain the 4. Close the appliance door. water container after each Possible causes of unsatisfactory drying drying cycle. (See chapter results: CARE AND CLEANING.) •... -
Page 29: Deactivating The Tank Indicator
ENGLISH 11.4 Operating hours counter Dryness Display symbol level This function gives a possibility to display the total operating time of the appliance Standard in hours, which is counted from the dryness moment it is first switched on. The actual operating time of the cycles is shown 5. -
Page 30: Care And Cleaning
If the procedure does not work (this could be due to timeout or wrong keys combination), switch the appliance off and repeat the sequence from the beginning. 12. CARE AND CLEANING 12.1 Cleaning the filter Filter At the end of each cycle the symbol comes on the display and you must clean the filter. -
Page 31: Emptying The Water Container
ENGLISH 12.3 Cleaning the condenser a vacuum cleaner. Place the filter back inside the filter socket. Heat exchanger flashes If the symbol on the display, inspect the condenser and its compartment. If it is dirty, clean it. Do the check not less than once a 6 months. - Page 32 2. Pull the filter. 3. Open the filter. 5. If necessary, remove the fluff from the condenser and its compartment. You can use a vacuum cleaner with a brush attachment. 4. Use a moist hand to clean the filter.
-
Page 33: Troubleshooting
ENGLISH 5. Close the cap. 6. Place the pipe back on its seat. 7. Close the condenser lid. 8. Turn the lever to lock the condenser lid. 9. Close the condenser cover. 12.6 Cleaning the drum WARNING! Disconnect the appliance 3. - Page 34 First try to find a solution to the problem (refer to the table). If the problem persists, contact the Authorised Service Centre. WARNING! Deactivate the appliance before carrying out any check. In case of major problems, the acoustic signals operate, the display shows an...
- Page 35 ENGLISH Problem Possible solution Clean the steam water filter After a steam programme, clothes are not Note the composition of the fabric. sufficiently smooth. Set a higher steam level. Load the machine with fewer clothes, or on‐ ly equivalent ones. Remove clothes quickly one at a time from the machine as soon as possible after the start of the anticrease phase.
-
Page 36: Technical Data
Problem Possible solution Set the Time Dry or the extra dry pro‐ gramme. The App cannot connect to the dryer. Check if your smart device is connected to the wireless network. Check your home network and router. Restart the router. - Page 37 ENGLISH Voltage 230 V Frequency 50 Hz Sound power level 63 dB Total power 1600 W Energy efficiency class A+++ Energy consumption on the standard cotton 1,68 kWh programme with the full load. Energy consumption on the standard cotton 0,86 kWh programme with the partial load.
-
Page 38: Product Information Sheet In Reference To E.u. Regulation 1369/2017
15. PRODUCT INFORMATION SHEET IN REFERENCE TO E.U. REGULATION 1369/2017 Product Information Sheet Trade Mark Model TR959M6SE PNC916099382 Rated capacity in kg Air vented or condenser tumble dryer Condenser Energy efficiency class A+++ Energy consumption in kWh per year, based on 160 drying cy‐... -
Page 39: Environmental Concerns
ENGLISH Average condensation efficiency of the standard cotton pro‐ gramme at partial load as a percentage Weighted condensation efficiency for the 'standard cotton pro‐ gramme at full and partial load' Sound power level in dB Built in appliance Y/N The information given in the chart above is compliant with the EU Commission regulation 392/2012 implementing directive 2009/125/EC. - Page 40 My AEG Care app The software in this product contains components that are based on free and open source software. AEG gratefully acknowledges the contributions of the open software and robotics communities to the development project. To access the source code of these free and open source software components whose license conditions require publishing, and to see their full copyright information and applicable license terms, please visit: http://aeg.opensoftwarerepository.com (folder NIUS)
