Quick Start Guide
AT-6000-EUR Advanced Wire Tracer Series
Immediate, clear breaker
identification
Tested by Fluke and safety
certified by 3rd party labs
Intuitive transmitter
automatically senses whether
the system is energized or
de-energized
Most accurate wire tracing
in its class with eight
sensitivity modes
AT-6000-TE
TRANSMITTER
HI
LO
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Beha-Amprobe AT-6000-TE
Summary of Contents for Beha-Amprobe AT-6000-TE
- Page 1 AT-6000-EUR Advanced Wire Tracer Series Immediate, clear breaker Intuitive transmitter identification automatically senses whether the system is energized or Tested by Fluke and safety de-energized certified by 3rd party labs Most accurate wire tracing in its class with eight sensitivity modes AT-6000-TE TRANSMITTER...
- Page 2 Quick Guide Table of Contents 1. Tracing Energized and De-energized Wires • Quick Scan Mode • Precision Tracing Mode 2. Identifying Breakers and Fuses • Breaker Tracing 3. Non-Contact Voltage (NCV) and Passive Tracing • Passive Tracing • Verify if a wire is Energized 4.
- Page 3 If the signal is too strong for precise 3. Select HIGH signal mode by pressing HI, LED locating, change the Transmitter to LOW mode. display will quickly begin to blink. ©2018 Beha-Amprobe For detailed specifications and ordering go to beha-amprobe.com 6011095 A ®...
-
Page 4: Identifying Breakers And Fuses
AT-6000-EUR Identifying Breakers and Fuses Set-up: Set-up: AT-6000-TE Transmitter Test Leads TRANSMITTER Blinking AT-6000-TE TRANSMITTER Transmitter indicator showing signal in HIGH mode 1. Turn on the Transmitter. Proper connection with separate 2. Verify that the test leads are properly connected;... - Page 5 2. For precise pinpointing of hot wire versus neutral wire, increase or decrease sensitivity by pressing + or - on the keypad. ©2018 Beha-Amprobe For detailed specifications and ordering go to beha-amprobe.com 6011095 A ®...
- Page 6 AT-6000-EUR Special Application: Finding Shorts Set-up: Set-up: AT-6000-TE Transmitter Receiver TRANSMITTER Precision tracing mode Verify the Loop LED is AT-6000-RE 1. Connect the Transmitter with the test leads 1. Turn on the Receiver to the circuit. 2. Press the MODE button to select a wire tracing mode (either Quick Scan or 2.
- Page 7 This method will be affected by signal cancellation effect. Expect a relatively weak signal. Note: For best results, ground all De-energized wires that run in parallel with the black test lead. ©2018 Beha-Amprobe For detailed specifications and ordering go to beha-amprobe.com 6011095 A ®...
-
Page 8: Tracing Wires In Metal Conduit
AT-6000-EUR Special Application: Metal Conduit Set-up: Set-up: Test Leads Receiver AT-6000-TE TRANSMITTER Precision tracing mode AT-6000-RE Proper connection with separate ground 1. Turn on the Receiver. Press the MODE button 1. Connect the green and red test leads to the to select a wire tracing mode (either Quick Scan Transmitter. -
Page 9: Specifications
12 - 1.5 V AA (IEC R6) Batteries • – 12 - Rechargeable Batteries – • 3 - Battery Chargers – • (charger and batteries are not available to order separately) AT-6020 AT-6030 ©2018 Beha-Amprobe For detailed specifications and ordering go to beha-amprobe.com 6011095 A ®... - Page 10 79286 Glottertal, Germany Tel. +49 (0) 7684 - 8009-0 info@beha-amprobe.de beha-amprobe.de Science Park Eindhoven 5110 NL-5692 EC Son The Netherlands Tel. +31 (0) 40 267 51 00 beha-amprobe.com Beha-Amprobe 52 Huricanne Way NR6 6 JB United Kingdom e-mail: info@beha-amprobe.co.uk beha-amprobe.com...
