Summary of Contents for Matrix MFU201
- Page 1 Manual for installation, use and maintenance MFU201 Integrated refrigerator year parts 1 year labour guarantee www.matrixappliances.co.uk...
- Page 2 Important The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment.
- Page 3 Parts intended to come into contact with food conform to 1935/2004/ This refrigeration appliance is intended for use as a built-in appliance IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU. At the end of its working life, the product must not be disposed of as urban waste.
- Page 4 Important • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • This appliance is intended to be used in household and similar applications such as: 1. Staff kitchen areas in shops, offices and other working environments 2.
- Page 5 door handles, do not pull the condenser at the rear part of the refrigerator and do not touch the compressor unit. • When transporting, moving or positioning the fridge-freezer do not tilt it by more than 40° from the vertical position. Should such a situation occur, the appliance should be switched on after minimum 2 hours from its replacement in the right position.
- Page 6 immediately. • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similar qualified persons in order to avoid a hazard. • This appliance is intended for food storage, do not use it for other purposes.
- Page 7 refrigerating appliances. To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause significant increases of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems.
- Page 8 recommended by the manufacturer. WARNING: Do not damage the refrigerant circuit. WARNING: Risk of fire / flammable materials. Note: please store different foods according to the compartments or target storage temperature of your purchased products. • If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance.
-
Page 9: Before First Use
Before first use You must allow the appliance to settle for at least twenty four hours prior to switching the power on. It is recommended that you clean the interior of the appliance prior to first use, using a solution of bicarbonate of soda and warm water and then thoroughly drying the interior. - Page 10 Controls MAX 10 W Light Temperature Adjusting the temperature Turn the dial to adjust the temperature in the appliance: OFF/0 position Appliance is off Setting 1 The highest temperature inside the appliance (warmer) Settings 2-5 Medium temperature inside the appliance Setting 6 The lowest temperature inside the appliance (cooler)
- Page 11 appliance by unplugging the power cord from the wall outlet. Before unplugging set the lowest setting on the temperature control dial. Additional information on the temperature • The temperature inside the appliance is influenced by many factors. How you set the temperature control dial depends on the ambient temperature, sun exposure, how often you open the door and the amount of food stored.
- Page 12 Storage The fridge section is for short term food storage. Although the temperature can be maintained between 0°C and 10˚C, extended periods of food storage is not recommended. As the cold air circulates within the fridge, the temperature can vary between the different sections.
-
Page 13: Practical Tips
Practical tips Due to the natural circulation of the air in the appliance, there are different temperature zones in the refrigerator chamber. The coldest area is directly above the vegetable drawers. Use this area for all delicate and highly perishable food such as: •... -
Page 14: Installation
Installation This appliance is intended for use as a built-in appliance and must never be installed close to heat sources, e.g. heating elements, cookers or in damp places. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Installation before using the appliance for the first time •... - Page 15 on figure 5.* • Ensure adequate ventilation of the room and free air circulation from all sides of the appliance (fig. 6).* WARNING: Keep ventilation openings, in the appliance enclosure or in the built - in structure, clear of obstruction. Minimum distances from the heat sources •...
- Page 16 Installation of the appliance should be performed by a qualified installer. • The appliance should be placed in furniture case). Once the appliance is placed correctly, adjust the height of the appliance by turning the 4 adjustable feet as appropriate. If necessary, adjacent appliances should be braced with a bracket fixed by screws and fitted in furniture.
- Page 17 Do not use adapters, multiple sockets and two-wire extension leads. If it is necessary to use the extension lead, it must be equipped with a protection ring and a single socket and must have a VDE/GS safety certificate. If an extension lead is used (with a protection ring and safety certificate), its socket must be located at a safe distance, away from the sinks, and must not be in a place where it could be flooded by water or waste water.
- Page 18 Product installation dimensions...
- Page 20 with the other hand. • Holding the door, swing the lower door hinge away from the door using the other hand, then detach the door from the appliance body. • Remove the two screws , which attach the upper hinge to the body and the two screws holding the lower hinge to the appliance body.
-
Page 21: Climate Range
relative to the appliance. Using the supplied screws, attach the furniture board assembly to the bottom of the appliance door. • Replace the mounting bracket cover in its original location. Climate range The information about the climate range of the appliance is provided on the rating plate. -
Page 22: Electrical Information
Electrical Information Warning! This appliance must be earthed. Green and yellow to earth Brown to live 13A Fuse Cord Clamp Blue to Neutral Fig. 10 The mains lead of this appliance has been fitted with a BS 1363A 13Amp fused plug. To change a fuse in this type of plug, follow the steps below: 1. - Page 23 correspond with the coloured markings identifying the terminals in your plug, proceed as follows:- • The wire which is coloured GREEN and YELLOW must be connected to the terminal which is marked with letter (E) or by the Earth symbol or coloured GREEN and YELLOW.
-
Page 24: Care And Maintenance
Care and maintenance Never clean the product’s casing or plastic parts using solvents or strong, abrasive detergents (e.g. washing powders or creams)! Use mild liquid detergents and soft cloths only. Do not use sponges. External surfaces made of plastic should be cleaned with a microfiber cloth, otherwise irreversible micro scratches will appear. - Page 25 • Wash all the accessories (vegetable containers, door shelves, glass shelves, etc.). WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than thode recommended by the manufacturer. Washing the fridge manually It is recommended to wash the fridge and freezer chambers at least once a year.
-
Page 26: Light Replacement
Light replacement This section applies to units factory equipped with incandescent lightbulb and selected appliances equipped with LED lighting with E14 thread. Replace the light bulb • Set the knob to “OFF”, then unplug the appliance. • Remove the bulb cover. •... -
Page 27: Troubleshooting
Troubleshooting If you have any problems with your appliance, you should check the troubleshooting prior to calling Customer Care, to prevent unnecessary service calls and potential cost. Customer Care Phone: 01949 862 012 Email: customer.care@cda.co.uk Certain sounds can be heard during normal use of the refrigerator, which do not affect its correct operation. - Page 28 Issue Possible cause Remedies The electric circuit is • Check whether the plug is properly appliance disrupted inserted into the socket does not • Check whether the power cable of work the appliance is not damaged • Check whether there is voltage in the socket, by plugging another appliance, e.g.
- Page 29 Issue Possible cause Remedies Incorrect setting of the Reset the knob to a higher adjustment knob position The ambient temperature The appliance is adapted to is higher or lower than the operation in the climate range climate range from table with from table with technical technical specification specification...
- Page 30 Serviced by For our Customer Care Department, or for Service, please contact us on: The CDA Group Ltd. Harby Road, Langar, Nottinghamshire, NG13 9HY Tel: 01949 862012 Fax: 01949 862003 Email: customer.care@cda.co.uk...
