KNX elsner Cala T 101 Manual

Room temperature controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
Cala KNX T 101
Room Temperature Controller
Item numbers 70980 (white), 70982 (black)
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the elsner Cala KNX T 101 and is the answer not in the manual?

Questions and answers

Related Manuals for KNX elsner Cala KNX T 101

Summary of Contents for KNX elsner Cala KNX T 101

  • Page 1 Cala KNX T 101 Room Temperature Controller Item numbers 70980 (white), 70982 (black) Manual...

  • Page 3: Table Of Contents

    6.4.1. Heating control stage 1/2 ................16 6.4.2. Cooling control stage 1/2 ................19 Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany Room Temperature Controller Cala KNX T 101 • from application 1.0 Status: 29.01.2024 • Technical changes and errors excepted.
  • Page 4 Clarification of signs This manual is amended periodically and will be brought into line with new software releases. The change status (software version and date) can be found in the contents footer. If you have a device with a later software version, please check www.elsner-elektronik.de in the menu area "Service"...

  • Page 5: Safety And Operating Instructions

    (mixed value). The Cala KNX T 101 has got an integrated PI controller for a heating and a cooling system (one or two step). The room temperature is adjusted by means of the „+“ and „-“...

  • Page 6: Commissioning

    Control according to separate target values or basic target temperature Commissioning Configuration is made using the KNX software as of ETS 5. The product file can be downloaded from the ETS online catalogue and the Elsner Elektronik website on www.elsner-elektronik.de.
  • Page 7 Changes with + or - are visible. The display returns to the room temperature if no button is touched for 7 seconds. Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 8 (e.g. Eco mode overnight) or reset to the stored values. The button functions can be locked due to operating mode with priority 1. Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.

  • Page 9: Transfer Protocol

    Temp. controller: Current set point Output R-CT [9.1] 2 bytes DPT_Value_Temp Temp. controller: Switching Input -WC- [1.1] DPT_Switch 1 bit (0: Heating | 1: Cooling) Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 10 R-CT [1.1] DPT_Switch 1 bit 1 (1:ON | 0:OFF) Temp. controller: Status heater stage Output R-CT [1.1] DPT_Switch 1 bit 2 (1:ON | 0:OFF) Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.

  • Page 11: Setting The Parameters

    No • Yes after using the push button Switching off after (if automatic switch off 1 ... 255; 2 Sec. after operation is used) Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.

  • Page 12: Temperature Measured Value

    The parameter is only taken into consideration if the setting by object is activated further down. Please note that the setting "After power restoration and programming" Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 13 (Default). Then configure a temperature control block using the blocking object. Mode after reset • Comfort • Standby • Eco • Building protection Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 14 If the actual value is between the heating and cooling setpoint values, the existing operating mode is retained. If heating was previously used, the Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 15 0 • 1 (with switching object) The grades for the set point changes are predefined. Grading for set point changes 1… 50; 10 (in 0.1 °C) Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 16 (only if both heating and cooling are used, without switching object) Set point for standby Standby mode is usually used for daytime mode when people are absent. Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 17 Set points for frost protection (heating) and heat protection (cooling) are de- termined which may not be modified from outside (no access via operating devices Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.

  • Page 18: Heating Control Stage 1/2

    In the second stage (thus only in the case of 2-stage heating), heating is controlled via a PI or a 2-point-control. For explanations of the parameters, see the corresponding sections. Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 19 This setting provides fixed parameters for frequent applications. Control type • PI control Setting of the controller by • Controller parameter • Specified applications Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 20 When blocked, the control variable should • not be sent • send a specific value Value (in %) 0...100 only if a value is sent Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.

  • Page 21: Cooling Control Stage 1/2

    (observe the manufactur- er's instructions). Maximum control variable is reached 1...5 at set point/actual difference of (in °C) Reset time (in min) 1...255; 30 Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 22 1-bit object (on/off) or an 8-bit object (on with percentage/off). Control variable is on • 1-bit object • 8-bit object Value (in %) 0...100 (with 8-bit object) Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.
  • Page 23 (only if a value is sent) In the case of a common control variable for heating and cooling, 0 is always transmit- ted as a fixed value. Room Temperature Controller Cala KNX T 101 • Version: 29.01.2024 • Technical changes and errors excepted.

  • Page 24: Questions About The Product

    • Serial number or software version • Source of supply (dealer/installer who bought the device from Elsner Elektronik) For questions about KNX functions: • Version of the device application • ETS version used for the project Elsner Elektronik GmbH Control and Automation Engineering...

This manual is also suitable for:

7098070982
