Summary of Contents for AEG HKB64453NW

  • Page 1 HKB64453NB User Manual HKB64453NW USER MANUAL...
  • Page 2: Table Of Contents

    10. ENVIRONMENTAL CONCERNS..............26 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3: Children And Vulnerable People Safety

    ENGLISH instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance is not intended for use by persons • (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 4 Never use water to extinguish the cooking fire. Switch • off the appliance and cover flames with e.g. a fire blanket or lid. WARNING: The appliance must not be supplied • through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
  • Page 5: Safety Instructions

    ENGLISH overvoltage category III must be guaranteed. The earth cable is excluded from this. When you route the mains cable, make sure that the • cable doesn't come into direct contact (for example using insulating sleeving) with parts that can reach temperatures of more than 50°C above room temperature.
  • Page 6: Gas Connection

    • Do not let the electricity mains cable adjustment of the appliance are tangle. compatible. • Make sure that a shock protection is • Make sure that there is air circulation installed. around the appliance. • Use the strain relief clamp on the •...
  • Page 7 ENGLISH • Do not put cutlery or saucepan lids on • Make sure the flame does not go out the cooking zones. They can become when you quickly turn the knob from hot. the maximum to the minimum • Do not operate the appliance with wet position.
  • Page 8: Installation

    2.7 Disposal • Disconnect the appliance from the mains supply. WARNING! • Cut off the mains electrical cable Risk of injury or suffocation. close to the appliance and dispose of • For information on how to dispose of • Flat the external gas pipes.
  • Page 9: Injectors Replacement

    ENGLISH 3.4 Conversion to G20 13 • it can not get hot more than room temperature, higher than 30°C; mbar • it is no longer than 1500 mm; • it shows no throttles; For the G20 13 mbar • it is not subject to traction or torsion; conversion please contact •...
  • Page 10 3. Ignite the shaft manually without the WARNING! knob. Make sure the flame does 4. Turn the shaft on the minimum not go out when you quickly position. turn the knob from the 5. With a thin screwdriver, adjust the maximum position to the bypass screw position (A).
  • Page 11: Connection Cable

    ENGLISH 3.8 Assembly If the pilot lights turn on after connecting the hob to the ON-TOP INSTALLATION mains, turn on and off the control knob and wait until the residual heat indicator goes out. 3.7 Connection cable To replace the connection cable use only the special cable or its equivalent.
  • Page 12 A. supplied seal B. supplied brackets INTEGRATED INSTALLATION...
  • Page 13: Possibilities For Insertion

    ENGLISH 3.9 Installing hob under the hood If you install the hob under a hood, please see the installation instructions of the hood for the minimum min. distance between the 30 mm appliances. min. 2 mm 3.10 Possibilities for insertion The panel installed below the hob must be easy to remove and let an easy access in case a technical assistance...
  • Page 14: Product Description

    4. PRODUCT DESCRIPTION 4.1 Cooking surface layout Semi-rapid burner Ultra Rapid burner Auxiliary burner Control panel Control knobs Window for Hob²Hood infrared signal 4.2 Control panel layout Use the sensor fields to operate the Minute Minder and Hob²Hood. The displays, indicators and sounds tell which functions operate.
  • Page 15: Control Knob

    ENGLISH Sen‐ Function Comment field To increase or decrease the time. To switch Hob²Hood Automatic Modes. Stand-by mode: Press the for at least 1 second to activate the display. 4.3 Control knob Symbol Description Symbol Description minimum gas supply no gas supply / off posi‐ 1 - 9 power levels tion...
  • Page 16: Daily Use

    Semi-rapid 30 sec 3 min 10 min (rear right) Auxiliary 30 sec 3 min 5 min 5. DAILY USE 1. Push the control knob down and turn WARNING! it counterclockwise to the maximum Refer to Safety chapters. gas supply position ( 2.
  • Page 17: Turning The Burner Off

    ENGLISH In the last minute the time The spark generator can decreases in seconds, and start automatically when you the last 10 seconds the timer switch on the mains, after emits a sound signal. installation or a power cut. It is normal.
  • Page 18: Hints And Tips

    1. When timer is off, touch Minute After the Automatic Mode is selected, Minder for 3 seconds. wait till it disappears from the display so 00 comes on. that this setting is saved in Flash Memory and recalled at startup.
  • Page 19: Energy Saving

    To find the full range of cooker hoods Semi-rapid (rear left) 160 - 220 which work with this function refer to our consumer website. The AEG cooker Semi-rapid (rear right) 160 - 240 hoods that work with this function must...
  • Page 20: Suggested Recipes

    6.5 Suggested recipes Food categories Recipes Burner type Heat up phase Cooking phase power power level level Bechamel Small Sauces - Dressing Tomato sauce Small Mushrooms rice Large Couscous Large Pasta - Rice - oth‐ er Cereals Spaghetti Large...
  • Page 21: Care And Cleaning

    ENGLISH Food categories Recipes Burner type Heat up phase Cooking phase power power level level Caramel Small Desserts Custard Small Panna cotta Small 1) Useful to reach optimal cooking condition. All recipes for approximately The settings suggested in 4 portions. the cooking table should only serve as guidelines and be adjusted depending on...
  • Page 22: Cleaning The Hob

    Be very careful when discoloration. Clean the hob with a you replace the pan moist cloth and a non-abrasive supports to prevent the detergent. After cleaning, wipe the hob top from damage. hob dry with a soft cloth.
  • Page 23: Troubleshooting

    ENGLISH 8. TROUBLESHOOTING WARNING! Refer to Safety chapters. 8.1 What to do if... Problem Possible cause Remedy There is no spark when you The hob is not connected to Check if the hob is correctly try to activate the spark gen‐ an electrical supply or it is connected to the electrical erator.
  • Page 24: Technical Data

    Problem Possible cause Remedy The display shows "E t" Turn off the control knobs and wait until the display is off or disconnect the appli‐ ance to the main to return to the initial condition. Selected Automatic Mode is Refer to "Daily use".
  • Page 25: Bypass Diameters

    ENGLISH Depth 520 mm 9.2 Bypass diameters BURNER Ø BYPASS 1/100 mm Ultra Rapid Semi-rapid Auxiliary 9.3 Other technical data Gas original: G20 (2H) 20 mbar 8,5 kW TOTAL POW‐ Gas replace‐ G30/G31 (3B/P) 30/30 mbar 582 g/h ment: G20 (2H) 13 mbar 8,25 kW Electric supply: 220-240 V ~ 50-60 Hz Appliance cate‐...
  • Page 26: Environmental Concerns

    9.6 Gas burners for LPG G30/G31 30/30 mbar BURNER NORMAL MINIMUM INJECTOR NOMINAL GAS POWER kW POWER kW MARK FLOW kW Ultra Rapid 1,75 Semi-rapid 1,85 0,55 Auxiliary 0,45 10. ENVIRONMENTAL CONCERNS appliances marked with the symbol Recycle materials with the symbol with the household waste.
  • Page 28 www.aeg.com/shop...
