- Page 1 Portable EV Charger User Manual Charging plug US Type1 Current 6-16A 6-32A 6-40A √ NEMA5-20 NEMA6-20(additional) √ Power plug NEMA6-50 NEMA14-50 √...
-
Page 2: Product Overview
Product Overview Charging plug Display sreen Touch Key-press (Indicator light) Power plug (NEMA 14-50) Cable *Additional 14-50R to 6-20P AC Power Adapter *Charging plug and power plug refer choices on cover page. Appearance of portable AC charger... -
Page 3: Basic Parameters
Basic Parameters Parameter Working voltage 110-240V AC,60Hz Rated power 1.3-9KW Max Rated current 6-40A adjustable IP Degree IP65 Mechanical life No-load plug in/pull out>10000 time Impact of external force 1m drop and 2T vehicle run over pressure Insulation Resistance > 100M ohm (DC 500V) <50K Terminal Temperature Rise Use environment... - Page 4 Control Box Function . Leakage protecyion (restart recover). . Over voltage, under-voltage protection (self-checking recover). . Lightning protection. . Over current protection. . Overheat protection. Cautions . DO not step on the cable, do not pull it, do not fold it up and do not knot it. .
-
Page 5: Warranty
5. Make sure that the vehicle connector is fully inserted until it clicks into place. 6. The charger works automatically, the indicator light is blinking blue. 7. Set the current according to the power supply before plugging the connector into the vehicle. - Page 6 The interface display EV Charger Function Select Time reservation Charge current Ground protection Not grounded protect Initial interface Setting interface Long press 3sec Click to select Enter the Settings page Long press 3sec to confirm Charge current Time reservation POWER TIME Click to adjust the power Click once to add...
-
Page 7: Indicator Light Description
Indicator light description Light state Working Condition Green Blue Power On (Unplugged) Stays On Insert the plug (Uncharged) Flashing Charging Mode Flashing Charging Completed Stays On Communication Error 1 Flash Under-voltage protection 2 Flashes Over-voltage protection 3 Flashes Ground Fault 4 Flashes Over current protection 5 Flashes... -
Page 8: Symbol Meaning
Symbol Meaning Symbol Meaning “Non-recyclable” mark: located on the product, instruction manual or package, indicating that electrical and electronic equipment and its accessories should be treated separately from ordinary household waste. When scrrapped, it should be treated as industrial waste, otherwise it may cause accidents. Warning sign: indicates danger.
