30 Inch Barrel Charcoal Grill
OUTDOOR USE ONLY! NEVER USE INDOORS!
Burning charcoal inside may be fatal. It gives off carbon monoxide, which has no odor. NEVER burn
charcoal in enclosed spaces.
Read and follow all of the manufacturer instructions before beginning assembly or operation. Failure to
do so could result in fire, burns, or other serious personal injury.
Keep this owner's manual for future reference. If you sell or give this product to someone else, make
sure this manual accompanies this product.
Product Code: NLQ0P
Model # OCBA-3001X
CARBON MONOXIDE HAZARD
1
Advertisement
Table of Contents
Related Manuals for Westinghouse OCBA-3001X
Summary of Contents for Westinghouse OCBA-3001X
- Page 1 30 Inch Barrel Charcoal Grill Product Code: NLQ0P Model # OCBA-3001X OUTDOOR USE ONLY! NEVER USE INDOORS! CARBON MONOXIDE HAZARD Burning charcoal inside may be fatal. It gives off carbon monoxide, which has no odor. NEVER burn charcoal in enclosed spaces.
-
Page 2: Important Safety Information
Product Code: NLQ0P Model #OCBA-3001X IMPORTANT SAFETY INFORMATION DANGER Failure to follow the dangers, warnings, and cautions in this manual may result in serious bodily injury, or death, as well as property damage due to a fire or explosion. WARNING CALIFORNIA PROPOSITION 65 ... - Page 3 Product Code: NLQ0P Model #OCBA-3001X Grill Preparation Safety WARNING DO NOT use this grill without the ash catcher (if available), ash pan, or ash tray in place. DO NOT use this grill unless all parts are in working condition and properly installed.
-
Page 4: After Use Safety
Product Code: NLQ0P Model #OCBA-3001X Grill is hot when in use. To avoid burns: DO NOT attempt to move the grill while lit or still hot. ALWAYS wear protective gloves or oven mitts. DO NOT TOUCH any hot grill surfaces. -
Page 5: Table Of Contents
Product Code: NLQ0P Model #OCBA-3001X Table of Contents Important Safeguards…………………………………………..…Page 2 Preparation……………………………………………………………………..5 Exploded View………………………………………………………………...6 Parts List………………………………………………………………………..7 Hardware & Tools…………………………………………………………...8 Assembly Instructions……………………………………………………..9 Care & Maintenance………………………………………………………20 Operating Instructions…………………………………………………...20 Cleaning & Care……………………………………………………………..23 Limited Warranty…………………………………………………………..24 Preparation DO NOT RETURN PRODUCT TO STORE customerservice@dongfangjm.com 866-273-2284 ... -
Page 6: Exploded View
Product Code: NLQ0P Model #OCBA-3001X Exploded View... -
Page 7: Parts List
Product Code: NLQ0P Model #OCBA-3001X Parts List... -
Page 8: Hardware & Tools
Product Code: NLQ0P Model #OCBA-3001X Hardware & Tools... -
Page 9: Assembly Instructions
Product Code: NLQ0P Model #OCBA-3001X Assembly Instructions Step 1 Connect Rear Wheel Leg (1) and Rear Stationary Leg (2). Connect Front Wheel Leg (3) and Front Stationary Leg (4). Step 2 Insert the Wire Shelf (5) into the holes on the insides of legs (1) and (2) and legs (3) and (4). Stand legs upright. - Page 10 Product Code: NLQ0P Model #OCBA-3001X Step 3 Install the Left Leg Support (6) onto legs (2) and (4) using M6*42 Screws (A) and M6 Flange Nuts (B). Install the Right Leg Support (31) using the same hardware as the Left Leg Support. Do not tighten screws until Step 5 is completed.
- Page 11 Product Code: NLQ0P Model #OCBA-3001X Step 5 Attach the Front Shelf (11) to the front of the Bowl (9) using M6*12 Screws (C). Install the Front Shelf Support Piece (10) to the Front Shelf (11) using M6*12 Screws (C). Note: Now tighten all screws securing in steps 1 through 5.
- Page 12 Product Code: NLQ0P Model #OCBA-3001X Step 7 Install one of the Side Shelf Brackets (13) to the front side hole location of the Bowl with M6*12 Screws (C). Step 8 Put the Side Shelf (14) onto the already assembled Side Shelf Bracket (13). Place the second Side Shelf Bracket (13) onto...
- Page 13 Product Code: NLQ0P Model #OCBA-3001X Step 9 Attach the Lid Hinges (18) on both sides of the Lid using M5*10 Stage Screws (G). Step 10 Remove the nut, spring and chimney lid from the Chimney. Install Chimney (19) into the Lid using M6*12 Screws (C). Reassemble the chimney lid, spring and nut.
- Page 14 Product Code: NLQ0P Model #OCBA-3001X Step 12 Unscrew the preassembled nut from the Temperature Gauge (20). Place the Temperature Gauge (20) into the Lid and reassemble the nut. Step 13 Align the holes of the Lid Hinges and the Bowl. Put the Hinge Pin (H) through the holes of the Lid Hinges and the Bowl.
- Page 15 Product Code: NLQ0P Model #OCBA-3001X Step 14 Install the Warming Rack (21) inside the Lid and Bowl. Insert the Cotter Pins (J) through the holes in the Warming Rack. Step 15 Use the Charcoal Tray Brackets (22) to lower the Charcoal Tray (23) into the grill base.
- Page 16 Product Code: NLQ0P Model #OCBA-3001X Step 16 Place the Cooking Grids (24) on the support rim of the Bowl. Step 17 Partially screw two M6*12 Screws (C) to the grill bowl as shown below. Install the Firebox Supporting Piece (32) to the Right Leg Support (31) using two M5*15 Screws (L).
- Page 17 Product Code: NLQ0P Model #OCBA-3001X Step 18 Install the Firebox Handle (25) and Firebox Handle Spacers (26) to the Firebox Lid (30) with M5*10 Screws (M) and M5*14 Washers (K). Position the two pieces of the firebox together. Align and seat the upper piece screws into the holes in the lower piece as shown.
- Page 18 Product Code: NLQ0P Model #OCBA-3001X Step 20 Use one M5*15 Screws (L) from inside of the firebox through the hole and tighten into the Firebox Supporting Piece. Tighten all the screws (C) from Step 17 and add four more M6*12 Screws (C) to connect the firebox to the grill.
- Page 19 Product Code: NLQ0P Model #OCBA-3001X Step 22 Attach the Firebox Handle (25) and Firebox Handle Spacers (26) to the Firebox Charcoal Tray (27) with M5*14 Washers (M) and M5*15 Screws (K). Attach Air Vent (12) onto the Firebox Charcoal Tray (27) as show below using one M5*10 Screw (C) and M6 Flange Nut (B).
- Page 20 Product Code: NLQ0P Model #OCBA-3001X Freestanding Firebox Assembly To use the firebox as a freestanding grill, you will first need to remove the firebox from the main barrel. Open the lid and remove the firebox charcoal tray. Attach the legs to the bottom of the firebox using M6*12 Screws (C) and M6 Flange Nuts (B).
-
Page 21: Care & Maintenance
Product Code: NLQ0P Model #OCBA-3001X Care & Maintenance Wash cooking grids and charcoal grates with hot, soapy water. Rinse well and dry completely with a towel to prevent rusting. After washing and drying, lightly coat grids with vegetable oil or vegetable oil spray. - Page 22 Product Code: NLQ0P Model #OCBA-3001X Lighting Instructions (continued) Never add charcoal starter fluid to hot or warm coals as flashbacks may occur causing injury. You are ready to begin cooking when the pile of briquettes ashes over and produces a red glow (approximately 10-15 minutes).
- Page 23 Product Code: NLQ0P Model #OCBA-3001X Controlling Flare-ups Flare-ups are a part of cooking meats on a charcoal grill and adds to the unique flavor of grilling. Excessive flare-ups can over cook your food and cause a dangerous situation for you and your charcoal grill.
-
Page 24: Cleaning & Care
Product Code: NLQ0P Model #OCBA-3001X Cleaning & Care CAUTION! All cleaning and maintenance should be done when charcoal grill is cool and with the fuel supply removed. Notices Abrasive cleaners will damage this product. Never use oven cleaner to clean any part of this charcoal grill. -
Page 25: Limited Warranty
Product Code: NLQ0P Model #OCBA-3001X Limited Warranty Dong Fang Jun Ma Co., Ltd. (DFJM) warrants to original retail purchaser of this product, and to no other person, that if this product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in such product shall be free from defects in material and workmanship.
