WARNING
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read this instruction manual
thoroughly before installing or
servicing this equipment.
WARNING
For Outdoor Use Only
Note : Read and understand this manual before use.
Keep this manual for future reference.
2 PLASTIC WHEELS AND
2 CASTERS (WITH LOCK)
INSTRUCTION MANUAL
CHARCOAL GRILL
CK171115
STEEL FRONT DOOR
STEEL HANDLES
3 STAINLESS
FIXED TYPE SIDE SHELVES
STAINLESS STEEL
THERMOMETER
Advertisement
Related Manuals for Westinghouse CK171115
Summary of Contents for Westinghouse CK171115
-
Page 1: Charcoal Grill
INSTRUCTION MANUAL CHARCOAL GRILL CK171115 WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read this instruction manual thoroughly before installing or servicing this equipment. WARNING For Outdoor Use Only Note : Read and understand this manual before use. - Page 2 Assembly Instructions...
-
Page 3: Parts List
PARTS LIST Part Description Picture of part Quantity Nunber 1PCS Up buckle 2PCS Thermometer 1PCS Air flap 4PCS Handle 1PCS Warming grill 1PCS Cooking grill 3PCS Charcoal rack 1PCS... - Page 4 Down buckle 2PCS Left stator 1PCS Right stator 1PCS Back plate 1PCS Side plate 2PCS Front plate 1PCS Crankshaft 1PCS Cranking bar 1PCS Front baffle plate 1PCS...
- Page 5 Handle decorative 1PCS sheet Handle 2PCS Oil collector 1PCS Handle 2PCS Left panel 1PCS Support 1 2PCS Support 2 2PCS Right panel 1PCS Left front leg 1PCS...
- Page 6 Left rear leg 1PCS Right front leg 1PCS Right rear leg 1PCS Frame supporting 2PCS tube Baseboard 1PCS axle 1PCS Wheel 2PCS wheel (with 1PCS brake) Bottle opener 1PCS...
- Page 7 HARDWARE Hardware Description Picture of Hardware Quantity Numder M6*40 screw 4PCS M6*35 screw 4PCS M6*15 screw 64PCS M6 step screw 2PCS Shaft 2pcs Bolt M6 nut 31PCS M8 nut 2PCS Gasket 1PCS IMPORTANT Please check the pack contents before attempting to assemble this barbecue. A full list of parts is given on the page 2-6, also directions on what to do if there are damaged or missing parts.
- Page 8 STEP 1: Assembly the side plate (13) and back plate (12) together with 4pcs screw (C) and 4pcs nut (G). Notice Please make sure to use the first hole and the third hole (From the top to count the holes), as same as the STEP2 STEP 2: Assembly front plate (14) to the side plate (13) by using 4pcs M6 screw (C) and...
- Page 9 STEP 3: Assembly the right front leg (28) right rear leg (29) left front leg (26) left rear leg (27) to the fire bowl by using 8pcs M6 screw (C) . STEP 4: Assemble the frame supporting tube (30) and leg by using M6 screw (C), assembly the baseboard (31) and leg by using M6 screw (C).
- Page 10 STEP 5: Assembly wheel (34) (35) to the left front leg and left rear leg, assemble the axle (32) to the right legs, and then assemble the wheels (33) to the axle (32) by using 2pcs M8 nut (H). STEP 6: As the drawing: Assembly the crankshaft (15) and the right stator (11) and fire bowl together by using 2pcs screw (C) as below (the crankshaft is upon the stator).
- Page 11 STEP 7: Assembly the left stator (10) and the fire bowl by using 2pcs screw (C). STEP 8: Assembly the charcoal rack (8) with the stator by using 2pcs step screw (D) and 2pcs nut (G), place it to the slot of the stator.
- Page 12 STEP 9: Assembly the air flap (4) to the fire bowl by using 2pcs screw (C) and 2pcs nut (G), please do not fasten the screw, so that the air flap can be moved. STEP 10: Assemble the down buckle (9) and the back plate by using 4pcs screw (A).
- Page 13 STEP 11: Place the handle decorative sheet (18) on to the handle (19), then assemble the handle to the front plate (14) by using gasket (I) and M6 nut (G). Notice: Please pay attention to the direction when assembling the front plate.
- Page 14 STEP 12: Assembly the up buckle (2) and the cover (1) by using 4pcs screw (B) and 4pcs nut (G). STEP 13: Assembly the handle (5) to the cover by using M6 screw (C), assembly the air flap (4) to the cover by using M6 screw(C), please do not fasten the screw for the air flap, so the it can be moved.
- Page 15 STEP 14: Assemble the cover (1) with the fire bowl by using shaft (E) and bolt (F). STEP 15: Assembly the handle (21) to the left panel (22) by using M6 screw (C), fix the support 1 (23)& support 2(24) to the left panel (22) by using M6 screw (C) and M6 nut (G), and fix left panel to the fire bowl by using M6 screw (C).
- Page 16 STEP 16: Assembly the handle (21) and the oil collector (20) by using 2pcs screw (C). STEP 17: Fix the oil collector to the fire bowl.
- Page 17 STEP 18: Fix the warming grill to the fire bowl and the cover as below. STEP 19: Place the cooking grill (7) into the fire bowl.
- Page 18 STEP 20: Fix the bottle opener (36) to the leg by using 2pcs screw (C). STEP 21: Fix the cranking bar (16) to the fire bowl as below.
- Page 19 CAUTION □ Use outside only. Never use barbecue inside or in confined space or under canopies or trees. □ Do not use or pour petrol, methylated spirits or paraffin onto burning coals. □ Locate on a firm and level surface, away from wooden fences, shrubs, trees, sheds and fuel tanks.
