Operator's manual
®
HUSQVARNA AUTOMOWER
535 AWD EPOS
EN, English
Read the operator's manual carefully and make sure that you
understand the instructions before you use the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUTOMOWER 535 AWD EPOS and is the answer not in the manual?

Questions and answers

Related Manuals for Husqvarna AUTOMOWER 535 AWD EPOS

Summary of Contents for Husqvarna AUTOMOWER 535 AWD EPOS

  • Page 1 Operator's manual ® HUSQVARNA AUTOMOWER 535 AWD EPOS EN, English Read the operator's manual carefully and make sure that you understand the instructions before you use the product.

  • Page 2: Table Of Contents

    Contents 5.3 Pattern..............32 1 Safety 5.4 Operation............32 1.1 Safety definitions...........4 5.5 Installation settings..........32 1.2 General safety instructions........4 5.6 Accessories............34 1.3 Safety instructions for installation......5 ® 5.7 General (Bluetooth only)........34 1.4 Safety instructions for operation......5 5.8 Security............... 34 1.5 Safety instructions for maintenance...... 6 ®...
  • Page 3 11.1 Original EU Declaration of Conformity....62 11.2 Translated EU Declaration of Conformity..63 12 Applicable to UK market 12.1 Original UK Declaration of Conformity....64 12.2 Statement of compliance........65 1427 - 012 - 16.10.2024...

  • Page 4: Safety

    • The product must only be used with the equipment Disposal on page 57 . Incorrect use may result in recommended by Husqvarna. All other types of electric shock, overheating or leaking of corrosive use are incorrect. liquid from the battery. In the event of leakage of •...

  • Page 5: Safety Instructions For Installation

    To set the product to OFF work area. Refer to with its special characteristics and safety on page 38 . Husqvarna recommends to set the regulations. product to operate when the work area has no •...

  • Page 6: Safety Instructions For Maintenance

    1.5 Safety instructions for maintenance WARNING: Read the warning instructions that follow before you do maintenance on the product. • Set the product to OFF when you do maintenance on the product. • Do not use a high-pressure washer to clean the product.

  • Page 7: Support

    The serial number and the product number are on the product rating plate and on the product carton. • Register your product on www.husqvarna.com. Enter the serial number of the product, the product number and the date of purchase to register your product.

  • Page 8: Product Overview

    2.3 Product overview Front body 11. Rear wheels Ultrasonic sensors 12. On/Off-button Front top cover 13. LED status indicator Handle 14. STOP button Rear top cover 15. START button ™ EPOS module 16. Battery cover Charging plates 17. Rear chassis with electronics, battery and motors Rear body 18.

  • Page 9: Symbols On The Product

    21. Blades Do not use a high-pressure 22. Blade disc washer or even running water 23. Contact plates to clean the product. 24. LED indicator of the charging station 25. Charging station Use a detachable power sup- 26. Power supply ply as defined on the rating label next to the symbol.

  • Page 10: Led Status Indicator

    2.5 LED status indicator Do not immerse the battery into water. 2.7 Symbols in the app Shows the status of the correction data that the product receives. ™ EPOS confirmed . The The status is product has an accurate position and direction.

  • Page 11: Installation With Epos Technology

    3 Installation with EPOS ™ technology 3.1 Introduction - Installation Note: Refer to www.husqvarna.com for more information about installation. WARNING: Read and understand the safety chapter before you install the product. CAUTION: Use original spare parts and installation material. ™...

  • Page 12: Primary Components For Installation

    (B) is where the product stops after going out from the charging station. The starting distance can be set to 70-250 cm / 28-98 in. Husqvarna recommends to have a minimum of CAUTION: Read the installation 6 m / 19.6 ft. (C) free space in front of the charging chapter before you start the installation.

  • Page 13: To Examine Where To Put The Power Supply

    The baseplate of the charging station must not be operate on gravel. bent. • If the work area has 2 parts separated with a steep slope, Husqvarna recommends to put the charging CAUTION: For careful operation station in the lower section. without noise, isolate all obstacles such as CAUTION: trees, roots and stones.
  • Page 14 Smaller trees do usually not cause interference with the operation of the product. • Husqvarna recommends a maximum distance from the charging station to the most remote part of the installation. The maximum distance is 200 m / 650 •...
  • Page 15 • Husqvarna recommends to set the direction of the lawn mower to go through without cutting. systematic pattern straight up the slope to prevent wear on the grass.

  • Page 16: Installation Of The Product

    • Install the virtual boundaries in slopes that are unit are clean and dry before you connect maximum 50%. them. 3.8.4 To examine where to make stay-out When you connect the power supply, only use a power zones outlet that is connected to a residual-current device •...
  • Page 17 Download the Husqvarna Fleet Services app and ® Automower Connect app on your mobile device. ™ Log on to the Husqvarna Fleet Services app. Set the product to ON. ® Enable the Bluetooth pairing operation mode on your mobile device.
  • Page 18 For each work area and the related stay-out zones and transport path the total maximum number of waypoints are 800. Husqvarna recommends to add maximum 1000 waypoints for the complete installation of the map. To make smooth curves use several waypoints.
  • Page 19 Note: Walk 2-3 m / 6.5-9.8 ft. behind the product when you operate the product with . To make a work area Minimum 3 waypoints are necessary to make a work area. • Operate the product clockwise around the boundary of the work area. •...
  • Page 20 To make a transport path • Operate the product and add waypoints on the map to install a transport path. Start in a work area minimum 1 m / 3.3 ft. from the virtual boundary. • Install the transport path perpendicular to the virtual boundary of the work area.
  • Page 21 ™ 1427 - 012 - 16.10.2024 Installation with EPOS technology - 21...

  • Page 22: Installation With Boundary Wire

    The first weeks after installation the sound level when the product cuts the grass can be higher than usual. The sound level decreases after some time. Note: Refer to www.husqvarna.com for more information about installation. 4.4 Before the installation of the wires 4.2 Primary components for installation You can select to attach the wires with stakes or bury them.

  • Page 23: To Examine Where To Put The Boundary Wire

    • Put the charging station in an area with protection CAUTION: For careful operation from the sun. without noise, isolate all obstacles such as • If the charging station is installed on an island, trees, roots and stones. make sure to connect the guide wire to the island. To make an island on page 25 .
  • Page 24 Put the boundary wire 35 cm / 14 in. (B) from an obstacle that is more than 5 cm / 2 in. high. wire around the charging station • Husqvarna recommends to put the boundary wires straight out from the charging station (A). " > 5 cm / 2 "...
  • Page 25 > 1.5 m / 5 ft > 1.5 m / 5 ft >60 cm / 24" >30 cm / 12" > 1.5 m / 5 ft 0% - 50% 50% - 70% • Make sure that there is an area of 50 cm / 1.6 ft. between level ground and steep slopes.

  • Page 26: To Examine Where To Put The Guide Wire

    To make an island, isolate areas in the work area with the boundary wire. We recommend to isolate all stable objects in the work area. Note: The product must be manually moved between Some obstacles are resistant to a collision, for example, the main area and the secondary area.

  • Page 27: Work Area Examples

    • If the work area has a slope, put the guide wire in a straight line from the bottom of the slope to the top of the slope. If it is not possible to make a straight line, put the guide wire diagonally across the slope. CAUTION: Do not put the guide wire in parallel with the slope, as the...

  • Page 28: To Install The Boundary Wire

    Close the connector with a pair of pliers. Note: Do not attach the charging station to the ground with the screws until the guide wire is To install the guide wire on page installed. Refer to 28 . Connect the low-voltage cable to the charging station.

  • Page 29: To Put The Wire Or The Cable Into Position With Stakes

    insulation may not cause disruptions until several weeks or months later. Put the wire or the cable on the ground. Put the stakes at a maximum of 75 cm / 30 in. distance from each other. Attach the stakes to the ground with a hammer or a plastic mallet.

  • Page 30: To Do A Visual Check Of The Charging Station

    Download the Husqvarna Fleet Services app and ® Automower Connect app on your mobile device. ™ Log on to the Husqvarna Fleet Services app. Set the product to ON. ® Enable the Bluetooth pairing operation mode on your mobile device.

  • Page 31: Settings

    5 Settings The product has factory settings but the settings can be Note: When the product has cut the work area it adapted to each work area. goes to the charging station. The product is parked in the charging station until the next schedule 5.1 Schedule starts.

  • Page 32: Pattern

    To start the product manually in the work area directions for the best possible cutting result. you must first enable the loop signal. Husqvarna recommends to use irregular pattern if the work area is complex and has many obstacles. 5.4.3.1 To enable the loop signal 5.4 Operation...

  • Page 33: Lawn Coverage

    Use the Note: Lawn Coverage remote parts of the work area. Use the Husqvarna recommends to set the charging function if the work area includes remote parts that are station signal to max . It is usually better to move the...

  • Page 34: Accessories

    Test Each area can be enabled or disabled. Use the Note: Husqvarna recommends to use the headlights function to measure the distance from the charging at night time. station to where the product must start to cut. The default settings lets the product follow the guide 5.6.2 To avoid collisions with the...

  • Page 35: Automower ® Connect (Bluetooth ® Only)

    In the factory setting this 5.8.3.3 Carried away function is enabled. Husqvarna recommends you to Carried away is enabled, the product senses If the alarm update the firmware when new firmware is available.

  • Page 36: To Reinstall The Charging Station On The Map

    The data collection for the AIM map starts automatically. The product collects data while it operates and the map is completed in 1-2 weeks. Remove temporary obstacles on the lawn when the product operates and collects data. If you change the installation of the wires or charging station, you must do a new map.

  • Page 37: Operation

    6 Operation 6.1 To set the product to ON The product can only go from the charging station when the battery is full and if the Schedule is set to let the product to operate. WARNING: Read and understand the safety chapter before you use the product.

  • Page 38: Operating Mode - Park

    6.3.3 Select work area This function lets the product temporarily operate in a selected work area. For work areas with irregular pattern you can select a time limit for this function. After that time period, the product continues to operate as it is set in the schedule.
  • Page 39 Note: If the battery is empty the product must charge for a longer period of time before the product can start. 1427 - 012 - 16.10.2024 Operation - 39...

  • Page 40: Maintenance

    7 Maintenance 7.1 Introduction - maintenance It is important that the blade disc rotates easily and that the edges of the blades are not damaged. The usual lifetime of the blades are 3 to 6 weeks. The conditions WARNING: Set the product to OFF that follow can increase or decrease the lifetime of the before you do maintenance on the product.

  • Page 41: Clean The Product

    The product does not operate satisfactorily in slopes if the wheels are blocked with grass. Use a soft brush to clean the product. Husqvarna recommends to use a special cleaning and maintenance kit, available as accessory. Speak to your Husqvarna representative for more information.

  • Page 42: Replacement Of The Blades

    7.4 Replacement of the blades WARNING: Husqvarna can only guarantee safety if you use Husqvarna original blades with the embossed crowned H-mark logotype. WARNING: You must replace the screws when you replace the blades. The used screws can wear quickly and make the blade come loose, this can cause serious Make sure that the blade disc can rotate freely.

  • Page 43: Battery

    7.6 Winter service Speak to your Husqvarna central service to make winter service before storage of the product. Do winter service of the product yearly to keep the product in good condition.

  • Page 44: Troubleshooting

    There is a proposal action to the cause and steps to take for each message. This chapter also presents some symptoms that can guide you if the product does not work as expected. More suggestions for steps to take in the event of malfunction or symptoms can be found on www.husqvarna.com. 8.2 Messages ®...
  • Page 45 PIN code to your registered e-mail address. If you have not registered the e-mail address, contact your local Husqvarna representative. Empty battery For an installation with boundary wire: Change the position of the guide wire. Refer To install the guide wire on page 28 .
  • Page 46 Message Cause Action Upside down The product is leaning too much or has Turn the product the right way up. turned over. Mower tilted The product is tilted more than the permitted Move the product to a flat area. slope. Lifted A blockage has activated the lift senors and Remove the product from the blockage.
  • Page 47 Message Cause Action FlexiFence problem The battery of the FlexiFence accessory is Park the product and charge the FlexiFence low. The FlexiFence accessory does not op- accessory before you start the product. erate when the battery is empty. The product can cut in the stay-out zone if you start the product before you charge the FlexiFence accessory.
  • Page 48 Message Cause Action Outside work area The boundary wire connections to the charg- Make sure that the boundary wire is connec- To examine where to ing station are crossed. ted correctly. Refer to put the boundary wire on page 23 . The boundary wire is too close to the edge of Make sure that the boundary wire has been the work area.
  • Page 49 Message Cause Action Collision sensor A blockage has caused the product to stop. Remove the product from the blockage and problem, front/rear examine the cause of the stop. Collision The body of the product cannot move freely Remove dirt and unwanted material between around the chassis.
  • Page 50 Message Cause Action No loop signal The power supply or the voltage-cable are Examine the LED status on the charging sta- not connected. tion. If the LED is not lit, it indicates that there is no power. Examine the power outlet con- nection and whether an earth-fault breaker has tripped.
  • Page 51 Message Cause Action Work area tampered The charging station or the reference station Do a new installation of the map. with was moved. Guide 1/2/3 not found The guide wire is not connected to the charg- Check that the guide wire’s connector is ing station.

  • Page 52: Led Indicator Of The Charging Station

    8.3 LED indicator of the charging station The LED indicator of the charging station is green when Speak to your local Husqvarna representative or go to the installation is correct. If the LED indicator of the www.husqvarna.com for more information.

  • Page 53: Symptoms

    If your product does not work as expected, follow the symptoms guide below. There is a FAQ (Frequently Asked Questions) on www.husqvarna.com which provides more detailed answers to a number of standard questions. Contact your local Husqvarna representative if you still cannot find the reason for the fault.
  • Page 54 Symptoms Cause Action Schedule Uneven mowing re- The product works too few hours per day. Increase the mowing time. Refer to on page 31 . sults. Lawn coverage function are Lawn coverage The settings for Examine the settings for the incorrect in relation to the layout of the work function.

  • Page 55: Find Breaks In The Loop Wire

    8.5 Find breaks in the loop wire Switch the connections between the guide wire and the boundary wire in the charging station. Breaks in the loop wire are usually the result of Start by switching connection AL and G1. Some unintentional physical damage to the wire such as when models have additional guide wires (G2, G3).
  • Page 56 Continue until only a very short section of the wire remains which is the difference between a solid green light and a flashing blue light. Then follow instruction in step 5 below. If indicator lamp still flashes blue in step 3 above: Put AL and G1 back in their original positions.

  • Page 57: Transportation, Storage And Disposal

    Note: If you keep the charging station outdoors, do not disconnect the power supply and the connectors. • Speak to your Husqvarna service for information about available storage accessories for your product. 9.3 Disposal • Obey the local recycling requirements and applicable regulations.
  • Page 58 Disconnect the 2 cables from the battery and remove the battery. 58 - Transportation, storage and 1427 - 012 - 16.10.2024 disposal...

  • Page 59: Technical Data

    10 Technical data 10.1 Technical data ® Dimensions Automower 535 AWD EPOS Length, cm / in. 93 / 36.6 Width, cm / in. 55 / 21.6 Height, cm / in. 33 / 13.1 Weight, kg / lbs 17.6 / 39 ®...
  • Page 60 ® Mowing Automower 535 AWD EPOS Cutting system 5 pivoted cutting blades Maximum cutting motor speed, rpm 2475 Power consumption during cutting, W +/- 20 % Cutting height, cm / in. 3-7 / 1.2-2.8 Cutting width, cm / in. 22 / 8.7 Narrowest possible passage for wire installation, cm / in.

  • Page 61: Registered Trademarks

    Deviations from this general technical data are included in the country specific chapters. Husqvarna AB does not guarantee full compatibility between the product and other types of wireless systems such as remote controls, radio transmitters, hearing loops, underground electric animal fencing or similar.

  • Page 62: Declaration Of Conformity

    11 Declaration of Conformity 11.1 Original EU Declaration of Conformity 62 - Declaration of Conformity 1427 - 012 - 16.10.2024...

  • Page 63: Translated Eu Declaration Of Conformity

    11.2 Translated EU Declaration of Conformity We, Husqvarna AB, SE 561 82 Huskvarna, SWEDEN, Tel. +46 36 146500 declare on our sole responsibility that the product: Description Robotic lawn mower Brand Husqvarna ® Type/Model HUSQVARNA AUTOMOWER 535 AWD EPOS Identification...

  • Page 64: Applicable To Uk Market

    12 Applicable to UK market 12.1 Original UK Declaration of Conformity 64 - Applicable to UK market 1427 - 012 - 16.10.2024...

  • Page 65: Statement Of Compliance

    12.2 Statement of compliance This product complies with the UK Product Security and Telecommunications Infrastructure Regulation. Statement of compliance for your product can be found at www.husqvarna.com/uk/support/. 1427 - 012 - 16.10.2024 Applicable to UK market -...
  • Page 66 66 - Applicable to UK market 1427 - 012 - 16.10.2024...
  • Page 67 1427 - 012 - 16.10.2024 Applicable to UK market -...
  • Page 68 AUTOMOWER ® is a trademark owned by Husqvarna AB. © Copyright 2024 HUSQVARNA. All rights reserved. www.husqvarna.com Original instructions 1144024-26 2024-10-28...
