Item no.
Volt
521001
12
521002
24
Limited warranty
- Roca warrants the wiper motors to be free
from defective material and workmanship
for a period of 3 years from the date of
purchase.
- This warranty does not apply to failure or
damage caused by improper installation,
misuse, lightning strike or damage from
a power surge.
- If failure occurs during this period, return
it to your dealer for repair or replacement.
n
4,7
8,3
45
(102)
n
11
Ø6 h7
Accessories
Wiper arm 520100
Blade
520911
Wiper motor | W5
Installation Instructions
Before installation please read these instructions.
•
Motor 12VDC / 24VDC
•
Adjustable sweep 90° / 110°
•
1 speed (40 Sweeps/minutes)
•
Adjustable left or right selfparking
•
12V/24V
•
Fuse 3A
•
Blade / Arm -
Max
www.rocaindustry.com
355 / 355
Advertisement
Related Manuals for Roca W5
Summary of Contents for Roca W5
- Page 1 Limited warranty Accessories • Blade / Arm - 355 / 355 - Roca warrants the wiper motors to be free from defective material and workmanship Wiper arm 520100 for a period of 3 years from the date of purchase. - This warranty does not apply to failure or...
- Page 2 Fuse 3A Battery Switch To change the the parking position. Remove the cover. 3 Remove the angle plate part 4 Rotate the angle plate part (180°) To switch sweep angle position. 1 Unscrew the screws 5 Push the angle plate part back to position 2 Remove the cover 1 Remove the 4 screws and plate 2 110°...
