Pioneer DJM-350-W Service Manual

DJ MIXER
DJM-350-W
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
DJM-350-W SYXJ8
DJM-350-W UXJCB
DJM-350-W LXJ
DJM-350-W AXJ5
DJM-350-W KXJ5
This service manual should be used together with the following manual(s):
Model
DJM-350/SYXJ8
This product is the same as the DJM-350, except for the colors. The major changes are as shown below.
Exterior panels (control panel, front panel, side panels, and rear panel): Changed to white
LED colors: Green changed to blue
Amber (LEVEL meters: CH1, CH2, and Master) changed to white
Amber (FADER START CH1 and CH2) changed to blue
When replacing the above-mentioned parts, be sure to use the parts described in this manual.
Two of the four master effects have been changed, as follows:
GATE to NOISE, CRUSH to SHORT ECHO
With these changes, the firmware becomes different from that for the base model.
With the name modification of the master effect, the button to press
at Test Mode-on is changed from [GATE] to [NOISE]. (Refer to P3.)
