Side Wall Guided
Tank Gauge
Installation and Specification Guide
PRODUCT DETAILS
Code
Country
Designed to provide accurate readings even in windy
conditions, the Side Wall Guided Tank Gauge clearly
TGSW02
GLOBAL
displays the exact water position, enabling a quick
understanding of your water level.
Featuring a red reflective band around the gauge
indicator, it's highly visible from a distance, allowing
for quick readings at any time of day. The UPVC float
is suitable for use with drinking water, and since the
float is the only element which contacts the contents
of the tanks, it is suitable for other liquids also. Plus,
its durable counterweight system guarantees that
your measurements are accurate and precise.
rainharvesting.com.au
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blue Mountain RAIN HARVESTING TGSW02
Summary of Contents for Blue Mountain RAIN HARVESTING TGSW02
- Page 1 Side Wall Guided Tank Gauge Installation and Specification Guide PRODUCT DETAILS Code Country Designed to provide accurate readings even in windy conditions, the Side Wall Guided Tank Gauge clearly TGSW02 GLOBAL displays the exact water position, enabling a quick understanding of your water level. Featuring a red reflective band around the gauge indicator, it's highly visible from a distance, allowing for quick readings at any time of day.
-
Page 2: Installation
Installation WHAT’S IN THE BOX? TOOLS/MATERIALS YOU MAY REQUIRE Side Wall Guided Tank Gauge 76mm / 3" Hole Saw Guide pole foot bracket Drill with Philips driver Guide pole bracing bracket x 2 For concrete tanks - toggle screws to Screws: replace standard screws a) 6 x Screws for securing gauge to the tank... - Page 3 INSTALLATION 1 - Select a location which is not to close to the pump (to avoid the float pulling towards it). Since the float drops in through the hole you're about to cut - the position does not need to be next to the tank opening. 2 - Measure the height of your tank, at the point where you will install the gauge.
- Page 4 INSTALLATION 3 - Time to adjust the string length. Lay out tank gauge on the ground like shown. Untie the knot at the indicator and float. The counterweight should be against the main gauge body like shown. Pull the float and indicator to the correct length as shown.
- Page 5 INSTALLATION 6 - Select how you would like to install the gauge on your tank A - If the tank is domed, this is the best option for installing the gauge. This method is also suitable for angled straight tank tops (like shown in image B). B - For angled tops where there is no dome in the top, you may install as shown in A or B.
- Page 6 INSTALLATION 8 - Then, bend down the arms as shown, so that the bracket sits horizontally on the tank. 9 - Position the foot on the ground, and the tank gauge on the tank. Measure the distance between the fittings where the guide post will sit, and cut the guide post to suit.
- Page 7 INSTALLATION 10 - Secure the foot to the ground, using the appropriate fasteners for the surface. Ensure the pole will sit vertically. 11 - Insert the pole into position. The pole will be held in position by the gauge and the mounting foot. 12 - Check the string length by pulling the indicator all the way down and up again.
- Page 8 INSTALLATION 14 - Trim or tie off excess string. 15 - Fasten the gauge to the tank using the supplied screws and washers. rainharvesting.com.au...
-
Page 9: Product Specifications
Product Specifications Side Wall Guided Tank Gauge Dimensions COUNTRY CODE 50mm (2 inch) Square foot Tank Global TGSW02 Ø160 Ø75 Height 50mm-60mm (1.5" to 2") Round Pipe All dimensions are in mm unless otherwise stated. rainharvesting.com.au... -
Page 10: Maintenance
Maintenance No maintenance is expected. If the indicator becomes stuck, simply give it a jiggle to release it. If you find there is a build up around the pulleys caused by pests, it can be brushed out from the underside by removing the gauge from the tank. - Page 11 For more information or to find out how we can help, just give us a call on +61 7 3248 9600 Or visit our website at rainharvesting.com.au...
