Summary of Contents for Deluo DeluoGPS
-
Page 2: Table Of Contents
Contents Contents ..........................2 Minimum system requirements..................3 Things to remember ......................3 Charging the battery for the first time................3 Hardware description....................... 4 Installation on Mac OS X....................8 Frequently Asked Questions..................15 Contact us ........................16 Page 2... -
Page 3: Minimum System Requirements
• Your Deluo Bluetooth GPS obtains information from the “free” system of 24 GPS satellites orbiting the earth. You should be able to get a position during any time of the day from any place on the surface of the earth provided you have a clear view of the sky. -
Page 4: Hardware Description
Hardware description LED Function Deluo Bluetooth GPS PRO Three LEDs indicate Bluetooth GPS PRO status Battery LED • Red: battery charge is low • Orange: battery is charging • Green: battery is full or has enough charge GPS LED •... - Page 5 Deluo Bluetooth GPS Lite GPS LED • Steady: indicates position has been fixed • Blinking: GPS receiver is turned on Bluetooth LED • Blinking: indicates the GPS is waiting for connection from another master Bluetooth device • Steady: indicates a Bluetooth connection has been established with another...
- Page 6 Switches Deluo Bluetooth GPS PRO • DC5V: plug the car charger or travel charger to charge the internal battery (DV5V – 500mA) • Power switch: turn power On or Off • Bluetooth pair switch: this switch will enable Bluetooth pairing function (Bluetooth...
- Page 7 External Antenna Connector This connector is designed for external MMCX type GPS antenna. When to use the External Antenna When the GPS is inside a car or any other environment where GPS signal is blocked, the external GPS antenna will help to receive better GPS signal. Please place the external GPS antenna in an outdoor open-space to ensure a better GPS performance.
-
Page 8: Installation On Mac Os X
Installation on Mac OS X MAKE SURE YOUR BLUETOOTH GPS RECEIVER IS ON AND WITH IN A TEN METERS RANGE AWAY FROM YOUR LAPTOP Note: This guide is based on Mac OS 10.3 (Panther). On Mac OS 10.4 Tiger, the serial port settings will be located in the Bluetooth preferences, under the tab for sharing. - Page 9 Step 3: Select the “Other Device” option and hit “Continue”. Step 4: Select your Bluetooth GPS unit from the discovered devices list and hit “Continue”. Page 9...
- Page 10 Step 5: Enter the passkey to access your Bluetooth GPS. Type “0000” in the “Passkey” field and hit “Continue”. Step 6: Click on “Quit” to finish your Bluetooth GPS discovery process. Page 10...
- Page 11 Step 7: Open Finder, click “Applications” and open the “Utilities” folder. Then run the “Bluetooth Serial Utility”. Step 8: In the Bluetooth Serial Utility window, click “New” to set up a new Bluetooth Serial link to your GPS. Page 11...
- Page 12 Step 9: Type a name for your GPS in the “Name” field (for instance “myDeluoGPS”) and make sure “Outgoing” is selected and “Port type” is RS-232. “Require Authentication”, “Require Encryption” and “Show In Network Preferences” must remain unchecked. Page 12...
- Page 13 Step 10: Click on “Select Device…” button to open the open the Device selector. Locate the GPS you have just added in “Step 4” and click on it to show its services. Select the SPP slave service on the right hand list and then hit the “Select” button to go back to the previous window.
- Page 14 Step 12: Close the “Bluetooth Serial Utility” window to finish the setup process. Step 13: Test your GPS unit using your favorite mapping software. Page 14...
-
Page 15: Frequently Asked Questions
Frequently Asked Questions Q: Is Deluo GPS compatible with my mapping software? A: Our GPS receivers are fully compatible with the NMEA 0183 sentence specification that most GPS mapping software use as their communication protocol. Please check out our web store for each product specs, there you will find the applications we know that works fine with our GPS units. -
Page 16: Contact Us
For technical support: support@deluo.com For billing related questions: billing@deluo.com If you want to become a reseller: resellers@deluo.com En Español: contacto@deluo.com Website: http://www.deluogps.com Deluo, LLC 10084 NW 53rd Street Sunrise, FL 33351 Fax: +1 (954) 332 0445 info@deluo.com Page 16...
