- Page 1 GO22FHD75VA...
- Page 2 GO22FHD75va...
- Page 3 ● Keep the monitor away from water sources or damp places, such as bath rooms, kitchens, basements and swimming pools. ● Make sure the monitor is placed on a at surface. lf the monitor falls down, it may cause human injury or device damage.
-
Page 4: Product Introduction
● Wires supplied may vary with purchased products. Figures in this User Manual are for reference only. Monitor Base Stand stem Screws Mount Stud HDMI signal cable GO22FHD75VA Power adapter User Manual ● Redundant screws can be used as spare screws. -
Page 5: Installation
Installation 1. Open the package to take out foams and put them on a at tabletop. Stand stem Upper foam cover Base Lower foam cover 2. Remove the upper foam cover and put it aside, take out the monitor lm bag and put the monitor in the lower foam cover. - Page 6 3. Take out the base, align it with the bottom of the stand , and rotate it to fasten. 4. Simply hold the stand with hand to stand the monitor upright. Note: During standing of the whole monitor, do not press the liquid crystal screen with hand to avoid damage to the screen.
-
Page 7: Adjusting The Monitor
Adjusting the monitor -5.0° +15° Tilting angle -5.0°(±2.0°)- +15°(±2.0°) - Page 8 Usage Button Function Up rocker button: The rocker is used to quick enter the Game Crosshair menu. Rocker switch button: press to turn on/o the monitor. Left rocker button: Exit the menu interface. Down rocker button: Quickly enter the contextual mode. Right rocker button: Press to enter sub-menus/ quickly enter the main menu.
- Page 9 *The bottom interface con guration at the back of the monitor varies with products. *Note: lf the power cable or signal cable is damaged, you must replace it with special soft cables or special components purchased from the manufacture or maintenance department. Connect audio outputting devices such as earphones to the Audio out interface.
- Page 10 OSD menu Menu description ● The color and shape of the OSD menu of the actual computer may be slightly different from them shown in the figure. ● Specifications of the OSD menu may change with improvements of functions without prior notice.
- Page 11 ENGLISH / TÜRKÇE / 日本語 / 简体中文 / 한국 / PУССКИЙ / ESPAÑOL/ PORTUGUÊS / POLSKI / ITALIANO / NEDERLANDS / DEUTSCH / FRANÇAIS...
-
Page 12: Basic Parameters
Basic parameters Product Name Liquid Crystal Display Product model GO22FHD75VA Screen Size 21.45inches（54.6cm） Aspect Ratio 16:9 Viewing Angle 178°(H) / 178°(V) Pixel pitch 0.0831 (H) × 0.241 (V) mm Contrast ratio 3000:1（TYP） Colors 16.7M Resolution 1920x1080 Maximum refresh rate 75Hz Power Input DC 12.0V... - Page 21 GO22FHD75VA...
- Page 23 GO22FHD75va...
- Page 24 GO22FHD75VA...
- Page 25 注：说明书仅供参考，一切以实物为准！！！ 108.007.19071 22H2F GO22FHD75VA 说明书 Gameon 2022-07-07 140*210mm 封面封底120G铜版纸+光膜，内页80G铜版纸，彩色印刷，骑马钉 唐喜阳 备注:如不够页数，可以在封面封底的内面插入空白页...
