- Page 1 ASB-XE-E180 Xenon Light source Operator Manual 111 Highland Drive Putnam, Connecticut 06260 LIT-034 Spectral Products Rev. M Page 1 of 12...
-
Page 2: Table Of Contents
6.2 Operation 7. CLEANING AND DISINFECTION 8. MAINTENANCE, SERVICING, REPAIR & WARRANTY 8.1 Lamp Replacement 8.2 Fuse Replacement 8.3 Limited Warranty 8.4 Repair 9. END OF PRODUCT LIFE 10. TROUBLESHOOTING 11. SYMBOLOGY LIT-034 Spectral Products Rev. M Page 2 of 12... -
Page 3: Introduction
1. INTRODUCTION Congratulations on the purchase of your new ASB-XE-E180 Xenon Illuminator! This user-friendly LED light source is a high efficiency light source utilizing state-of-the-art superior illumination technology. It offers a variety of features such as: • 5600 K daylight brightness for perfect color definition •... -
Page 4: Warnings And Cautions
200mΩ of ground impedance and less than 16ft (<5m) of length. If unauthorized cables are used, the device may have increased electromagnetic emissions and/or decreased electromagnetic immunity which may result in improper operation. LIT-034 Spectral Products Rev. M Page 4 of 12... -
Page 5: Cautions
If there is a power interruption during use, the illuminator will shut down and automatically restart if the power switch remains in the ON position. There may be a short delay as the unit reboots. LIT-034 Spectral Products Rev. M Page 5 of 12... -
Page 6: Specifications
IPX-0; no protection. harmful ingress of water Degree of safety in the Equipment is NOT suitable for use in the presence of presence of Flammable flammable anesthetics. Anesthetics Mode of operation Continuous LIT-034 Spectral Products Rev. M Page 6 of 12... -
Page 7: Overview
5. OVERVIEW FRONT PANEL Name Function Light Output Interface Connection point for light guide Intensity Control Mechanically adjusts light intensity Power Button Turns light source ON and OFF. Illuminates green when energized. LIT-034 Spectral Products Rev. M Page 7 of 12... -
Page 8: Rear Panel
Allows ventilation and cooling of light source 12VDC Fan cools the lamp Hour Meter Reset Resets hour meter to zero hours. Press when installing a new lamp. Ground Stud For potential equalization LIT-034 Spectral Products Rev. M Page 8 of 12... -
Page 9: Setup And Operation
Apply cleaning agents by light spray or dampened towels. Do not pour liquids onto the device. Do not allow liquids to enter the device seams or ventilation openings. Follow all applicable bloodborne pathogen procedures as required by OSHA and/or your hospital when cleaning and disinfecting the product. LIT-034 Spectral Products Rev. M Page 9 of 12... -
Page 10: Maintenance, Servicing, Repair & Warranty
The illuminator carries a 3-year warranty from the date of shipment on workmanship and all defects of material. Should your product prove to have such defects within three years of shipment, Spectral Products will repair or replace the product or part without charge. Should your product(s) need servicing under this warranty, please contact Spectral Products or a local distributor for return authorization documentation. -
Page 11: End Of Product Life
Symbol for Authorized Representative in the European Community Caution, consult accompanying documents Consult Instructions for Use CE mark Do not use if package is damaged. Not for disposal in general waste Medical device LIT-034 Spectral Products Rev. M Page 11 of 12... - Page 12 Caution: Hot Surface Caution: Dangerous Voltage Storage / Shipping Humidity Barometric Pressure Unique Device Identifier Keep Dry AC Current Product Safety Mark Equipotentiality Power on Power off Type BF Protective Earth (Ground) LIT-034 Spectral Products Rev. M Page 12 of 12...
