- Page 1 111 Highland Drive – Putnam, CT 06260 Phone 860-928-5834 – Fax 860-928-2676 www.spectralproducts.com 30W High Stability Tungsten- Halogen Light Source - ASB-W-030 - Operation Manual...
-
Page 2: Important Safety Notices
This SP’s product is warranted against defects in material and workmanship for a period of one year from the date of shipment. During the warranty period, Spectral Products will, without charge, repair or replace, at its discretion, the defective product or component parts. -
Page 3: General Information
General Information The ASB-W-030 is a complete light source assembly with a tungsten-halogen lamp that emits in the 300 to 2600 nanometer (nm) wavelength region. It has been designed to transfer the maximum possible illumination from a tungsten-halogen lamp to Digikröm monochromators. The tungsten-halogen lamps of the ASB-W-030 are near blackbody sources of light with fused silica envelopes around the lamp filaments. -
Page 4: Current Adjustment
2. CURRENT ADJUSTMENT: The current driving the lamp may be adjusted at the front of the ASB-W-030 power supply. The color temperature, power output, and lamp life can be altered by adjusting the amount of current. -
Page 5: Specifications
111 Highland Drive – Putnam, CT 06260 Phone 860-928-5834 – Fax 860-928-2676 www.spectralproducts.com Specifications Type: Tungsten-halogen Filament size: 1mm x 4mm Power input: 30Ws (nominal) Lamp Light Output: 530 lumens (nominal) Current: 2.75 amp (nominal) Color Temperature: 3100°K Average Life: 400 hours (nominal) Tapered flange, adjustable, Post mounting for standalone Mount operation... -
Page 6: Changing The Bulb
4. Reconnect the Lamp leads and re-insert the lamp assembly into the housing. Centering screws (3 ea) Focus screw ASB-W-030 LAMP HOUSING Fig 1. - Page 7 111 Highland Drive – Putnam, CT 06260 Phone 860-928-5834 – Fax 860-928-2676 www.spectralproducts.com Appx. Power supply technical datasheet 1. Key features: • RoHS compatible for all six substances • CE marked to Low Voltage Directive • Worldwide AC input capabilities •...
-
Page 8: Technical Support
111 Highland Drive – Putnam, CT 06260 Phone 860-928-5834 – Fax 860-928-2676 www.spectralproducts.com Technical Support Toll Free: (877) 928-5834, ext 215 Tel: (860) 928-5834, ext 215 Fax: (860) 928-2676 Website: http://www.spectralproducts.com Email: mdrugan@spectralproducts.com support@spectralproducts.com...
