Sony TRINITRON KX-2501 Service Manual

ctober, 1981
Color system
Picture tube
Inputs
Г Баве
| шіге
"MICROFILM
МТ5С
Trinitron tube
25-inch picture measured
diagonally,
114-degree deflection
VIDEO INPUT (phono jack)
1 V p-p, NTSC, 75 ohms,
unbalanced, sync negative
AUDIO INPUT (2 phono jacks)
—5 dBs (436 mV rms), 47 kilohms
CONTROL INPUT (minijack)
5V р-р
MULTI INPUT (8-pin DIN)
Same as the above VIDEO/AUDIO! *
CONTROL INPUTS
SPECIFICATIONS
Output
Power requirements
Power consumption
AC outlet
Dimensions
Weight
Accessories supplied
US Model
Chassis No. SCC-383A-A
50 > "7 и» 2
The adjustment procedures are not соп-
tained in this manual.
When performing the adjustments, refer
to the separate-volume 'ADJUSTMENT
MANUAL",
SPEAKER
Accepts speakers of 8-16 ohms
120V ac, 60 Hz
180 W (max.) 132 W (average)
1.8W (in standby condition)
Switched, max. 200 W
Approx. 660 x 560 x 487 mm (w/h/d)
(26 x 22% x 19% inches)
Approx. 55 kg (121 Ib 4 oz)
Video Cable VMC-1S (phono plug to phono
plug, 1.2 m)
Connecting Cord RK-105A (miniplug to
2 phono plugs, 1.5 m)
— Continued on next page —
TRINITRON „
COMPONENT TV
