Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Critical installation warnings Installation cautions Critical usage warnings Usage cautions Critical cleaning warnings Installation What’s included Installation requirements Step-by-step installation Before you start Detergent guidelines Smart Check Laundry guidelines...
Safety information • Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use, and care of your appliance. Read this manual thoroughly before using the washing machine to ensure that you know how to safely and efficiently operate the features and functions that your new washing machine offers.
Safety information Important safety precautions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
Page 5
6. The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. 7. This appliance is intended to be used in household only and it is not intended to be used such as: –...
Page 6
Safety information 13. Adequate ventilation has to be provided to avoid the back flow of gases into the room from appliances burning other fuels, including open fires. 14. Do not dry unwashed items in the tumble dryer. 15. Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer.
22. Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances burning gas or other fuels. 23. The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the tumble dryer, in such a way that a full opening of the tumble dryer door is restricted.
WARNING If the appliance is flooded, turn off the water & power supplies immediately and contact your nearest Samsung Customer Service. • Do not touch the power plug with wet hands. • Failure to do so may result in electric shock.
• Failure to do so may result in electric shock, fire, problems with the product, or injury. • In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from doing it.
Safety information Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc. • This may result in electric shock or injury. Critical cleaning warnings WARNING Do not clean the appliance by spraying water directly onto it. Do not use the a strong acidic cleaning agent.
What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer centre or the retailer. 01 Lid 02 Bubble Kit...
Installation NOTE • Lid: Make sure to keep the lid closed while the washing machine is operating. • Filter: This collects lint that builds up from the laundry being washed. • Levelling feet: Adjust the feet to level the washing machine on a flat floor. Installation requirements Electrical supply and grounding WARNING...
Step-by-step installation STEP 1 Select a location Location requirements: • Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 ˚C) •...
Page 14
Installation STEP 2 Adjust the levelling feet Unpack the product package. 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet (A). 2. Level the washing machine by manually adjusting the levelling feet. 3. When levelling is complete, tighten the nuts (B) if provided (some models may not have the nuts).
Page 15
If there is a water leak, stop operating the washing machine and disconnect from the electrical supply. Then, contact a local Samsung service centre in case of a leak from the water hose, or contact a plumbing technician in case of a leak from the water tap. Otherwise, this may cause electric shock.
Page 16
Installation CAUTION Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high- pressure hose. Connecting to a non-threaded water tap (applicable models only) 1. Remove the adaptor (A) from the water hose (B). 2.
Page 17
6. While pulling down part (D) on the water hose, connect the water hose to the adaptor. Then, release part (D). The hose fits into the adaptor with a clicking sound. 7. To complete connecting the water hose, see 2 and 3 on the "Connecting to a threaded water tap (applicable models only)"...
Page 18
Installation STEP 4 Position the drain hose General type 1. Press and hold down the joint ring, and insert it into the drain hose. 2. Insert the drain hose into the drain outlet. Make sure to connect them firmly using the joint ring. The drain hose is extensible.
Page 19
Pump type (applicable models only) 1. Open the hose cap (A), and insert the drain hose. Tighten the drain hose using the joint ring. NOTE • The position (side or rear) of the drain outlet depends on the model. • Availability of the hose cap depends on the model. 2.
Page 20
Plug the power cord into a wall socket protected by a fuse or circuit breaker. Then, press Power to turn on the washing machine. STEP 6 Calibration Mode Your Samsung washing machine detects the laundry weight automatically. For more accurate weight detection, please run Calibration Mode after the installation. To run Calibration Mode, follow these steps: 1.
Before you start Detergent guidelines The washing machine provides a two-compartment dispenser for detergent and fabric softener. The bleach compartment is located on the left side of the tub. • Detergent compartment with Bubble Kit (A): Apply a recommended amount of detergent (liquid or powder) into the compartment.
Page 22
Before you start 4. Add a recommended amount of fabric softener into the softener compartment. 5. Add a recommended amount of non-chlorine bleach into the bleach compartment. NOTE Do not exceed the max line when applying the cleaning agents. CAUTION Do not pour undiluted liquid chlorine bleach directly onto the load or into the tub.
Smart Check To enable this function, you must first download the Samsung Smart Washer app at the Play Store or the Apple Store , and install it on a mobile device featuring a camera function. The Smart Check function has been optimised for Galaxy & iPhone series (applicable models only).
Before you start Laundry guidelines Checkpoints • Check for stains or dirt. Apply a little detergent to a white towel. Rub the white towel and the dirty clothes together to transfer the dirt or colour to the white towel. • Before washing, pre-treat the sleeves, collars, dress hems, and pockets by brushing with detergent. •...
Page 25
STEP 1 Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon. • Colour: Separate whites from colours. • Size: Mixing different-sized items together in the tub improves the washing performance. •...
Page 26
Before you start STEP 3 Use a laundry net or wash certain items separately • Brassieres (water washable) must be placed in a laundry net. Metal parts of the brassieres may break through and tear other laundry items. • Cashmilon, large volume garments, and lightweight clothes (lace-decorated clothes, lingerie, nylon stocking, and synthetic fabrics) may float on water during washing and cause problems to the machine.
Page 27
STEP 4 Prewash (if necessary) • To remove stains and dirt on collars, sleeves, hems, and pockets, apply detergent lightly and brush off. • Use powder or liquid detergents. Do not use soap, as this may remain on the tub after washing. •...
Page 28
Before you start STEP 6 Apply a proper detergent type The type of detergent depends on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling. Always use “low suds” laundry detergent, which is designed for automatic washing machines.
Operations Control panel WA80F**B** WA80F**S** 01 Power Press to turn on/off the washing machine. 02 Cycles Press to select the desired cycle. 03 Start/Pause Press to start or pause an operation. 04 Cycle indicators The indicator next to each wash cycle turns on to indicate the selected cycle. Displays the current cycle information and estimated time remaining, or an 05 Display information code if the washing machine needs to be checked.
Operations Press to change the number of rinses (maximum 5 rinses) or press and hold 09 Rinse to start rinse cycle only. Press to select a different spin speed or press and hold to start spin cycle 10 Spin only. Press this button to activate/deactivate the Eco Bubble function.
Cycle overview Max load Cycle Description (kg) • For most fabrics including cottons, linens, and normally NORMAL soiled items. AI WASH • Adjusts the cycle according to the laundry type. • For lightly soiled items that you want to finish washing QUICK WASH quickly.
Operations Special features Child Lock The Child Lock function alerts the user when the lid opens while the function is on, to ensure safety during operation and to prevent accidents. Enabling and disabling the Child Lock function Press and hold Water Level and Wash simultaneously for approximately 3 seconds to enable or disable the Child Lock function.
Delay End You can set the washing machine to finish a cycle later. The hour displayed indicates the time the wash will finish. 1. Select a cycle. Then, change the cycle settings if necessary. 2. Press Delay End repeatedly until a desired end time is set. 3.
• This appliance supports the Wi-Fi 2.4 GHz protocols. Download On an app market ( Google Play Store , Apple App Store , Samsung Galaxy Apps ), find the SmartThings app with a search term of “ SmartThings ”. Download and install the app on your device.
Directive 2014/53/EU . The full text of the EU declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name.
Maintenance Cleaning Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Exterior • Use a soft cloth to wipe up all detergent, bleach, or other spills as they occur. • Clean the control panel with a soft, damp cloth. Do not use abrasive powders or cleaning pads. Do not spray cleaners directly on the panels.
Page 37
TUB CLEAN reminder • The TUB CLEAN indicator reminds you of cleaning the tub when necessary. If you happen to see the indicator blinking after washing is complete, remove the laundry and run the TUB CLEAN cycle. • You can ignore this reminder and continue to run cycles normally because this is not a system failure. However, the reminder remains active for 6 consecutive cycles immediately after each cycle is complete.
Page 38
Maintenance Filter 1. Press down the upper area of the filter case to remove. 2. Unlock the cover, and clean the filter with running water and a brush. 3. When cleaning is complete, close the cover and reinsert the filter case to the original position. You will hear a clicking sound when the filter case fits in.
Page 39
Pump filter (applicable models only) 1. Put a floor-cloth or towel under the Pump filter. Turn the filter knob anticlockwise to remove. 2. Clean the filter with running water and a soft brush. 3. Reinsert the filter, and turn clockwise until it locks into position.
Maintenance Mesh filter 1. Use pliers to pull out the mesh filter from inside the water inlet as shown. 2. Use a soft brush to clean the mesh filter with running water. 3. Reinsert the filter. Make sure it is tightened against water leaks.
Page 41
2. To remove, pull the detergent drawer while pushing the ends of each side. 3. Remove the Bubble Kit (A) from the compartments. Rinse the Bubble Kit (A) and the drawer in warm water and clean with a soft brush. 4.
Troubleshooting Checkpoints If you encounter a problem with the washing machine, first check the table below and try the suggestions. Problem Action • Make sure you use rated power for the product. Does not turn on. • Make sure the power cord is completely plugged in. •...
Page 43
Problem Action • Make sure the washing machine is set on a level floor. If the floor is not level, use the levelling feet to adjust the washing machine. • Make sure the washing machine is not contacting any other object. •...
Page 44
Troubleshooting Problem Action • Fully open both water taps. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct water taps. Flush water lines. • Disconnect the hoses and clean the screens. The hose filter screens may be clogged.
Page 45
• Excessive suds collect in recesses and can cause foul odours. Has odours. • Run cleansing cycles to sanitise periodically. • Dry the washing machine interior after a cycle has finished. If a problem persists, contact a local Samsung service centre. English 45 Untitled-5 45 Untitled-5 45...
Troubleshooting Information codes If the washing machine fails to operate, you may see an information code on the display. Check the table below and try the suggestions. Code Action The Water Level sensor is not working properly. • Check Water Level Sensor wire harness. •...
Page 47
“Ub” check message will be shown in the display. If any information code keeps appearing on the screen, contact a local Samsung service centre. English 47 Untitled-5 47...
Specification Specification sheet Top loading washing machine Type WA80F21B** WA80F21S** WA80F19B** Max load Capacity (kg) 21.0 21.0 19.0 AC 220-240 V / 1400-1650 1400-1650 50 Hz Power consumption (W) AC 230 V / 1400-1650 1400-1650 60 Hz Dimensions (mm) W637 x D701 x H1093 Net weight (kg) 47.0 45.0...
