Aiwa NSX-T9 Service Manual

Aiwa NSX-T9 Service Manual

Compact disc stereo cassette receiver
Hide thumbs Also See for NSX-T9:

Advertisement

Quick Links

Download this manual
NSX-T9
COMPACT DISC STEREO
CASSETTE RECEIVER
•
:
TYPE
EZ
SIMPLE MANUAL
• Replace this Service Manual with "Revision Publishing" when it is issued.
.
S/M Code No
09–994–407–1T3

Advertisement

loading
Need help?

Need help?

Do you have a question about the NSX-T9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa NSX-T9

Summary of Contents for Aiwa NSX-T9

  • Page 1 NSX-T9 COMPACT DISC STEREO CASSETTE RECEIVER • TYPE SIMPLE MANUAL • Replace this Service Manual with "Revision Publishing" when it is issued. S/M Code No 09–994–407–1T3...

  • Page 2: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST - 1/8 NOTE: The characters in the suffix column indicate the part usage. EZSM ....XX........E....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-040 CAP,E 100-16 ABCDE....87-010-186-080 CAP,CHIP 4700P ABCDE....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE....87-010-197-080 CAP, CHIP 0.01 DM ABCDE....
  • Page 3 ELECTRICAL MAIN PARTS LIST - 2/8 87-010-194-080 CAP, CHIP 0.047 ABCDE....87-010-194-080 CAP, CHIP 0.047 ABCDE....87-010-182-080 C-CAP,S 2200P-50 B ABCDE....87-010-197-080 CAP, CHIP 0.01 DM ABCDE....87-010-194-080 CAP, CHIP 0.047 ABCDE....87-010-194-080 CAP, CHIP 0.047 ABCDE....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE....
  • Page 4 ELECTRICAL MAIN PARTS LIST - 3/8 87-A90-535-010 SW,RTRY EC16B24304 ABCDE....87-A91-111-010 SW,RTRY EC12E12404-20MM ABCDE....87-010-071-040 CAP,E 1-50 M 5L SRE ABCDE....87-010-176-080 C-CAP,S 680P-50 SL ABCDE....87-010-187-080 CAP CHIP S5600P ABCDE....87-010-196-080 CHIP CAPACITOR,0.1-25 ABCDE....87-010-213-080 C-CAP,S 0.015-50 B ABCDE....87-012-145-080 CAP, CHIP S 270P CH ...DE....
  • Page 5 ELECTRICAL MAIN PARTS LIST - 4/8 SFR 303 87-024-355-080 SFR,33K DIA6 H ABCDE....SFR 301 87-024-355-080 SFR,33K DIA6 H ABCDE....SFR 304 87-024-355-080 SFR,33K DIA6 H ABCDE....SFR 306 87-024-356-080 SFR,47K DIA6 H ABCDE....SFR 305 87-024-356-080 SFR,47K DIA6 H ABCDE....
  • Page 6 ELECTRICAL MAIN PARTS LIST - 5/8 87-A40-503-080 ZENER,MTZJ39B ABCDE....87-A40-553-080 DIODE,1N4003 LES ABCDE....87-A40-553-080 DIODE,1N4003 LES ABCDE....87-A40-553-080 DIODE,1N4003 LES ABCDE....87-A40-553-080 DIODE,1N4003 LES ABCDE....87-A40-345-080 ZENER,MTZJ10C ABCDE....87-070-274-080 DIODE,1N4003 SEM ABCDE....87-A40-004-080 ZENER,MTZJ16A ABCDE....87-A40-269-080 C-DIODE,MC2836 ABCDE....87-A40-270-080 C-DIODE,MC2838 ABCDE....
  • Page 7 ELECTRICAL MAIN PARTS LIST - 6/8 87-010-213-080 C-CAP,S 0.015-50 B ABCDE....87-010-263-080 CAP, ELECT 100-10V ABCDE....87-010-263-080 CAP, ELECT 100-10V ABCDE....87-010-992-080 C-CAP,S 0.047-25 B ABCDE....87-010-992-080 C-CAP,S 0.047-25 B ABCDE....87-010-314-080 C-CAP,S 22P-50V ABCDE....87-010-322-080 C-CAP,S 100P-50 CH ABCDE....87-010-322-080 C-CAP,S 100P-50 CH ABCDE....
  • Page 8 ELECTRICAL MAIN PARTS LIST - 7/8 87-A60-546-010 CONN,11P H GRY TUC-P11X-C1 ABCDE....87-010-186-080 CAP,CHIP 4700P ABCDE....87-010-186-080 CAP,CHIP 4700P ABCDE....87-010-322-080 C-CAP,S 100P-50 CH ABCDE....87-010-404-080 CAP, ELECT 4.7-50V ABCDE....87-010-404-080 CAP, ELECT 4.7-50V ABCDE....87-010-544-080 CAP, ELECT 0.1-50V ABCDE....87-010-544-080 CAP, ELECT 0.1-50V ABCDE....
  • Page 9 ELECTRICAL MAIN PARTS LIST - 8/8 87-A00-258-080 RES,M/F 0.22-1W J ABCDE....87-A00-258-080 RES,M/F 0.22-1W J ABCDE....87-A00-258-080 RES,M/F 0.22-1W J ABCDE....87-A91-042-080 C-THMS,100K 55001 ABCDE....87-A91-042-080 C-THMS,100K 55001 ABCDE....
  • Page 10 ELECTRICAL MAIN PARTS LIST - 1/3 (TUNER: ZZA-1) NOTE: The characters in the suffix column indicate the part usage. ZRDS ....XX........F....EZKG ....XX........G..... KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-381-080 0E CAP, ELECT 330-16V ABCDEFGH.... 87-010-404-080 0E CAP, ELECT 4.7-50V ABCDEFGH....
  • Page 11 ELECTRICAL MAIN PARTS LIST - 2/3 (TUNER: ZZA-1) 87-010-401-080 0E CAP, ELECT 1-50V ABCDEFGH.... 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGH.... 87-010-405-080 0E CAP, ELECT 10-50V ABCDEFGH.... 87-010-494-080 0E CAP ELECT GAS 1/50 ..E....87-010-494-080 0E CAP ELECT GAS 1/50 ..E....87-012-275-080 0E C-CAP,U 1200P-50 B ABCDEFGH....
  • Page 12 ELECTRICAL MAIN PARTS LIST - 3/3 (TUNER: ZZA-1) 87-A50-022-010 0E COIL,ANT SW(COI) ..E....87-A50-159-010 0E COIL,10MH K C2B ..E....87-A50-173-010 0E COIL,OSC SW-N(COI) ..E....87-A50-432-010 0E COIL,1MH K CW ..E....87-A50-430-010 0E COIL,ANT MW(3BSW) ..E....87-A50-431-010 0E COIL,OSC MW(3BSW) ..E....87-NF4-650-010 1D COIL,AM PACK 4N(TOK) A....

  • Page 13: Mechanical Parts List

    MECHANICAL PARTS LIST - 1/2 NOTE: The characters in the suffix column indicate the part usage. EZSM ....XX........E....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-NF3-090-010 RING,FOOT ABCDE....8Z-NF3-001-010 CABI,FR H AB.DE....8Z-NF3-002-010 CABI,FR U ..C....8Z-NF3-008-010 CABI,STEEL U ....8Z-NF3-009-010 CABI,STEEL ABCDE....
  • Page 14 MECHANICAL PARTS LIST - 2/2 87-085-185-010 BUSHING, AC CORD (E) AB.DE....87-085-189-010 BUSHING, CORD (U) ..C....87-A80-105-010 AC CORD ASSY,AZ ...D....87-A80-110-010 AC CORD ASSY,U SPT-2W ..C....87-A90-562-010 F-BEAD,9.5-17.5-28.5 BRH ABCDE....87-A91-080-010 FAN, F614R-12MC-19-400MM ABCDE....88-906-481-110 FF-CABLE, 6P 1.25 480MM ABCDE....

  • Page 15: Accessories / Package List

    ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. EZSM ....XX........E....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8Z-NF3-901-010 IB,U (ESF)M ..C....8Z-NF3-902-010 IB,H (ECA)M A....8Z-NF3-903-010 IB,LH (ESP)M .B.D....8Z-NF3-904-010 IB,EZ (9L)M ..E....
  • Page 16 SCHEMATIC DIAGRAM _ 1 (MAIN 1/3)
  • Page 17 SCHEMATIC DIAGRAM _ 2 (MAIN 2/3)
  • Page 18 SCHEMATIC DIAGRAM _ 3 (MAIN 3/3)
  • Page 19 SCHEMATIC DIAGRAM _ 4 (FRONT)
  • Page 20 SCHEMATIC DIAGRAM _ 5 (TUNER : ZZA-1)
  • Page 21 SCHEMATIC DIAGRAM _ 6 (PRO)
  • Page 22 SCHEMATIC DIAGRAM _ 6 (AC)
  • Page 23 9620450 Tokyo Japan Printed in Singapore...
