HS3 Series TABLE OF CONTENTS 1. SAFETY PRECAUTIONS ..........................................2 1.1. About this document....................................3 1.1.1. Overview ......................................... 3 1.1.2. Target audience ......................................3 1.2. Safety ..........................................3 1.2.1. Safety levels ........................................3 1.2.2. Symbol explanation ..................................... 4 1.2.3. Safety instructions ....................................... 5 1.3.
Page 4 HS3 Series 2.5. LED indicators on the HS3 inverter ..............................19 3. Transportation and Storage ........................................22 3.1. Transportation ......................................23 3.2. Storage ......................................... 23 4. Installation ............................................... 26 4.1. Precautions ......................................... 27 4.2. Determine the installation site ................................27 4.2.1.
Page 5 HS3 Series 5.2.10. Assemble the communication connection ..........................97 5.2.11. Close the AC-side cover ................................103 5.3. Assemble the DC-side connection ..............................104 5.3.1. Open the DC-side cover ..................................104 5.3.2. Connect the PV cables ................................... 105 5.3.3. (Optional) Connecting the battery cables between multiple stacks ..................108 5.3.4.
Page 6 HS3 Series 9.2.3. Battery junction box ....................................142 9.2.4. EV charger ......................................... 142 10. Appendix ..............................................143 10.1. Recycling and disposal ..................................144 10.2. Warranty ........................................144 10.3. Contacting support ....................................144 10.4. Trademark ........................................144...
Page 7 HS3 Series...
Page 8: Safety Precautions
HS3 Series SAFETY PRECAUTIONS...
Page 9: About This Document
SAJ system HS3-(5K-12K)-T2-(W, G)-(B, P) . It is a three-phase all-in-one energy storage system which includes the SAJ products listed in section 2.2.2.3.2 "Product models". Read the user manual carefully before any installation, operation and maintenance and follow the instructions during installation and operation.
Page 10: Symbol Explanation
HS3 Series 1.2.2. Symbol explanation Symbol Description Danger: Electrical shock hazard This device is directly connected to public grid and thus all work to the battery shall only be carried out by qualified personnel. WARNING: No open flames Do not place or install near flammable or explosive materials.
Page 11: Safety Instructions
• Do not stay close to the equipment while there are severe weather conditions including storm, lighting, etc. • Before opening the housing, the SAJ inverter must be disconnected from the grid and PV generator; you must wait for at least five minutes to let the energy storage capacitors completely discharged after disconnecting from power source.
Page 12: Safe Handling
• Disconnect the AC circuit breaker, or keep it disconnect if it is tripped, and secure it against reconnection. • The SAJ inverter must only be operated with the PV generator. Do not connect any other source of energy to the SAJ inverter.
Page 13: Battery
⚫ Operate and use the battery properly according to the user manual. Any attempts to modify battery without the permission from SAJ will void the limit warranty for the battery. ⚫ The battery must be installed at a suitable location with sufficient ventilation.
Page 14 HS3 Series area where the battery pack is installed. Wear a gas mask and avoid inhaling toxic gases and harmful substances produced by the fire. ⚫ Use an ABC fire extinguisher, if the fire is not caused by battery and not spread to it yet.
Page 15 HS3 Series...
Page 16: Product Information
HS3 Series PRODUCT INFORMATION...
Page 17: General Introduction
SAJ HS3 inverter is built internally with a battery management system (BMS), which is used to ensure efficiency of the battery and protect the battery from operating outside its specified limitations. Working with an optional BC3 battery junction box, up to 8 battery packs can be used for storage expansion.
Page 18 HS3 Series ⚫ HS3-4K-T2-G-B ⚫ HS3-4K-T2-G-P ⚫ HS3-5K-T2-G-B ⚫ HS3-5K-T2-G-P HS3-6K-T2-G-B HS3-6K-T2-G-P ⚫ ⚫ HS3-8K-T2-G-B HS3-8K-T2-G-P ⚫ ⚫ HS3-10K-T2-G-B HS3-10K-T2-G-P ⚫ ⚫ HS3-10K-T2-G-B-BE* HS3-10K-T2-G-P-BE* ⚫ ⚫ HS3-12K-T2-G-B HS3-12K-T2-G-P ⚫ ⚫ HS3-12K-T2-G-B-IE* HS3-12K-T2-G-P-IE* ⚫ ⚫ Inverter (Australian version) ◼ Model type...
Page 19: Model Description
HS3 Series 2.3.3. Model description HS3 - T2 - HS3 - T2 - HS3: Inverter model series K: Rated power. For example, 6K indicates the rated power of the inverter is 6 kW. T2: Three phases with 2 MPPT W: This model uses a built-in AIO3 module.
Page 20: Dimension
HS3 Series 2.3. Dimension 2.3.1. HS3 inverter Dimension (mm): 450*695*170 Figure 2.1. HS3 inverter dimension 2.3.2. BU3 battery pack BU3 battery pack—Type A ◼ Battery pack with a base...
Page 21 HS3 Series Figure 2.2. Dimension of the type A battery pack with a base Battery pack without a base Figure 2.3. Dimension of the type A battery pack without a base BU3 battery pack—Type B ◼ Battery pack with a base...
Page 22: Bc3 Battery Junction Box
HS3 Series Battery pack without a base Figure 2.5. Dimension of the type B BU3 battery pack without a base 2.3.2. BC3 battery junction box Dimension (mm): 150*695*170 Figure 2.6. Dimension of the BC3 battery junction box 2.3.3. CU2 charger...
Page 23: Ports, Switches, And Led On The Hs3 Inverter
HS3 Series 2.4. Ports, switches, and LED on the HS3 inverter Figure 2.8. Ports, switches, and LED on the HS3 inverter...
Page 24 HS3 Series Callout Silkscreen Description SIM CARD SIM card slot Only available when a 4G module is embedded in the inverter. Port for connecting an Energy management system (EMS) device Used in the paralleling scenario. LAN port Only available when an AIO3 module is embedded in the inverter. It is used by the AIO3 module for communication.
Page 25: Led Indicators On The Hs3 Inverter
HS3 Series 2.5. LED indicators on the HS3 inverter Figure 2.9. HS3 inverter LED LED indicator Status Description The inverter is powered off. Breathing 6s The inverter is in initialization or standby state. Solid on The inverter is working properly.
Page 26 HS3 Series Solid on The grid is connected and working properly. On 1s, off 1s The grid is not working properly. GRID No grid is detected. Solid on The PV array is working properly. On 1s, off 1s The PV array is not working properly.
Page 27 HS3 Series...
Page 28: Transportation And Storage
HS3 Series TRANSPORTATION AND STORAGE...
Page 29: Transportation
HS3 Series 3.1. Transportation DANGER Load or unload batteries with caution. Otherwise, the batteries may be short-circuited or damaged (such as leakage and crack), catch fire, or explode. ⚫ Batteries have passed the test of UN38.3. This product meets the transportation requirements for dangerous goods for lithium batteries.
Page 30 The battery cannot be disposed of as household refuse. When the service life of the battery reaches to the limit, it is not required to return it to the dealer or SAJ, but it must be recycled to the special...
Page 31 HS3 Series...
Page 32: Installation
HS3 Series INSTALLATION...
Page 33: Precautions
HS3 Series 4.1. Precautions For safety, be sure to read all the safety instructions carefully prior to any works and observe the appropriate rules and regulations of the country or region where you installed the energy storage system. DANGER •...
Page 34: Installation Location Requirements
HS3 Series seepage. ⚫ The product is to be installed in a high traffic area where the fault is likely to be seen. 4.2.2. Installation location requirements The device employs natural convection cooling, and it can be installed indoor or outdoor.
Page 35 HS3 Series In some restricted conditions, the allowable backward-tilted angle must not be greater than 3 degrees, and the allowable side-tilted angle must not be greater than 2 degrees. Figure 4.3. Installation angle ⚫ Choose a solid and smooth wall to ensure that the inverter can be installed securely on the wall.
Page 36: Preparing Installation Tools
HS3 Series 4.3. Preparing installation tools The tools illustrations are for your reference. Installation tools include but are not limited to the following recommended ones. Use other auxiliary tools based on site requirements. Multimeter Measurement Utility knife Marker Measuring tape...
Page 37: Unpacking
4.4. Unpacking 4.4.1. Check the outer packing Although SAJ’s products have thoroughly tested and checked before delivery, there is possibility that the products may suffer damages during transportation. Check the outer packing package for any damage, such as holes and cracks.
Page 38 HS3 Series In some configurations, the grid and backup load connector kits might be different. Backup connector (gray) Grid connector (black) kit The meter kit contains the following items: Communication cable with an Current transformer x3 Smart meter RJ45 connector...
Page 39 HS3 Series ⚫ (Optional) Battery without a base (BU3-5.0-(TV1, TV2) or BU3-5.0-(TV1, TV2)-PRO) M6*50 screw x2 Battery module Locking bracket x2 M6*80 expansion bolt x2 Gasket x2 M5*14 screw x4 ◼ BU3 battery pack—Type B Type B battery pack has two mounting ears on the rear cover.
Page 40 HS3 Series ⚫ (Optional) Battery without a base (BU3-5.0-(TV1, TV2) or BU3-5.0-(TV1, TV2)-PRO) M6*50 screw x2 Battery module Locking bracket x2 M6*80 expansion bolt x2 Gasket x2 M5*14 screw x4 M4*12 screw x2 Grounding plate (For Australian version) (For Australian version) BT3-TV wall-mounting bracket ◼...
Page 41: Installation
HS3 Series Positive connector M4*12 screw Negative connector (For Australian version) (For Australian version) CU2-11K-T-1 EV charger ◼ This is an optional package, depending on your system configuration. Charger Holster M4*32 screw x4 Expansion bolt x4 M5*14 screw x2 M4*12 screw x2...
Page 42: Type A Battery Pack: Ground Mounting Manner
HS3 Series 4.5.1. Type A battery pack: ground mounting manner Before you start Make sure that the ground should be flat and no inclination. Procedure Step 1. Install the base battery (BU3-5.0-(TV1, TV2)-BASE or BU3-5.0-(TV1, TV2)-PRO-BASE). Get the cardboard from the base battery package. Place the cardboard on to the wall. Drill six holes (8 mm in diameter and 55 mm in depth) on the marked positions on the cardboard.
Page 43 HS3 Series Use two M5*14 screws to install two locking brackets on the left and right sides of the battery pack. On the desired installation site, place the base battery on the floor. Make sure that: The left and right battery bases are aligned with the vertical black lines on the cardboard.
Page 44 HS3 Series On the left and right upper sides of the battery pack, align the locking brackets to the drill holes and install M6*50 screws to secure the locking brackets to the wall. Note: If the battery is installed outdoors, it is suggested to remove the cardboard which is not waterproof.
Page 45 HS3 Series Step 2. (Optional) Install other batteries (BU3-5.0-(TV1, TV2) or BU3-5.0-(TV1, TV2)-PRO). Note: In one stack, up to three batteries are supported. Use two M5*14 screws to install two locking brackets on the left and right sides of the battery pack.
Page 46 HS3 Series On the left and right upper sides of the battery pack, align the locking brackets to the drilled holes and install the gaskets and M6*50 screws to secure the battery pack to the wall. On the left and right bottom sides of the battery pack: Install two M5*14 screws to secure two batteries.
Page 47 HS3 Series (Optional) If needed, repeat steps a and b to install the third battery. M6*50 M6*50 5 N· m 5 N· m M5*14 M5*14 2.5 N· m 2.5 N· m Figure 4.11. Installing the third battery...
Page 48 HS3 Series Step 3. (Optional) Install the EV charger (CU2-11K-T-1). Get the holster from the charger package. Install the holster onto the right side of the charger. Place the charger onto the battery. Push it downwards. On the left and right bottom sides, install M5*14 screws to secure the charger to the beneath battery.
Page 49 Install the holster on the wall by using three M4*32 screws. Note: The holster is used to secure the charger cable. You can connect the cable after all installation is completed. It is recommended that you purchase the cable from SAJ. M4*32 5 N·...
Page 50 Notes: ⚫ It is recommended that you connect the cable after all device installation is completed. It is recommended that you purchase the cable from SAJ. ⚫ For a long cable, you can wrap the cable on the holster. ⚫...
Page 51 HS3 Series Step 4. Install the inverter (HS3- k-T2-W-B, HS3- K-T2-W-P, HS3- k-T2-G-B, or HS3- K-T2-G-P). (Optional) If you have installed a charger, loosen the screws on the inverter, and remove the port cover, as shown below: Figure 4.15. Removing the port cover Place the inverter onto the battery or charger (if available) and push it downwards.
Page 52 HS3 Series Installation completion view Single stack: supporting 1 to 3 batteries Example of 3 batteries: Inverter + charger + batteries Inverter + batteries Figure 4.17. Completion view of a single stack...
Page 53: Type B Battery Pack: Ground Mounting Manner
HS3 Series 4.5.2. Type B battery pack: ground mounting manner Before you start Make sure that the ground should be flat and no inclination. Procedure Step 1. Install the base battery (BU3-5.0-(TV1, TV2)-BASE or BU3-5.0-(TV1, TV2)-PRO-BASE). Get the cardboard from the base battery package. Place the cardboard on to the wall. Drill six holes (8mm in diameter and 55mm in depth) on the marked positions on the cardboard.
Page 54 HS3 Series Use two M5*14 screws to install two locking brackets to the mounting ears on the top of the battery pack. On the desired installation site, place the base battery on the floor. Make sure that: ⚫ The left and right battery bases are aligned with the vertical black lines on the cardboard.
Page 55 HS3 Series On the top of the battery pack, align the locking brackets to the drilled holes and install M6*50 screws to secure the locking brackets to the wall. Note: If the battery is installed outdoors, it is suggested to remove the cardboard which is not waterproof.
Page 56 HS3 Series Step 2. (Optional) Install other batteries (BU3-5.0-(TV1, TV2) or BU3-5.0-(TV1, TV2)-PRO). Note: In one stack, up to three batteries are supported. Use two M5*14 screws to install two locking brackets to the mounting ears on the top of the battery pack.
Page 57 HS3 Series On the top of the battery pack, align the locking brackets to the drilled holes and install the gaskets and M6*50 screws to secure the battery pack to the wall. On the left and right bottom sides of the battery pack, install M5*14 screws to secure two batteries.
Page 58 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. Figure 4.23. Installing the grounding plate...
Page 59 HS3 Series (Optional) If needed, repeat steps a and b to install the third battery. M6*50 5 N· m M5*14 2.5 N· m M5*14 2.5 N· m Figure 4.24. Installing the third battery...
Page 60 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.25. Installing the grounding plate...
Page 61 HS3 Series Step 3. (Optional) Install the EV charger (CU2-11K-T-1). Get the holster from the charger package. Install the holster onto the right side of the charger. Place the charger onto the battery. Push it downwards. On the left and right bottom sides, install M5*14 screws to secure the charger to the battery.
Page 62 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.27. Installing the grounding plate...
Page 63 Install the holster on the wall by using three M4*32 screws. Note: The holster is used to the charger cable. You can connect the cable after all installation is completed. It is recommended that you purchase the cable from SAJ. M4*32 5 N·...
Page 64 Notes: ⚫ It is recommended that you connect the cable after all device installation is completed. It is recommended that you purchase the cable from SAJ. ⚫ For a long cable, you can wrap the cable on the holster. ⚫...
Page 65 HS3 Series Step 4. Install the inverter (HS3- k-T2-W-B, HS3- K-T2-W-P, HS3- k-T2-G-B, or HS3- K-T2-G-P). (Optional) If you have installed a charger, loosen the screws on the inverter, and remove the port cover, as shown below: Figure 4.30. Removing the port cover Place the inverter onto the battery or charger (if available) and push it downwards.
Page 66 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.32. Installing the grounding plate...
Page 67 HS3 Series Installation completion view Single stack: supporting 1 to 3 batteries Example of 3 batteries: Inverter + charger + batteries Inverter + batteries Figure 4.33. Completion view of a single stack...
Page 68: Type B Battery Pack: Wall Mounting Manner
HS3 Series 4.5.3. Type B battery pack: wall mounting manner Before you start Make sure that the wall can bear the weight of the inverter and accessories. Procedure Step 1. Install the wall-mounting bracket. Place the mounting bracket onto the wall. Mark six holes. Remove the bracket.
Page 69 HS3 Series Install the mounting bracket on to the wall. Figure 4.36. Installing the mounting bracket Step 1. Install the base battery (BU3-5.0-(TV1, TV2)-BASE or BU3-5.0-(TV1, TV2)-PRO-BASE). Get the cardboard from the base battery package. Place the cardboard onto the wall and align the vertical lines on the cardboard with the bracket edges.
Page 70 HS3 Series Drill six holes (8mm in diameter and 55mm in depth) on the marked positions on the cardboard. Install the provided expansion bolts into the drilled holes. Figure 4.38. Drilling holes Figure 4.39. Installing expansion bolts...
Page 71 HS3 Series Use two M5*14 screws to install two locking brackets to the mounting ears on the top of the battery pack. Place the base battery onto the floor. Make sure that: The battery feet are aligned with the vertical black line on the cardboard.
Page 72 HS3 Series On the top of the battery pack, align the locking brackets to the drilled holes and install M6*50 screws to secure the locking brackets to the wall. Secure battery to the wall-mounting bracket by tightening two M5*14 screws.
Page 73 HS3 Series Step 2. Install other batteries (BU3-5.0-(TV1, TV2) or BU3-5.0-(TV1, TV2)-PRO). Note: In one stack, up to three batteries are supported. Use two M5*14 screws to install two locking brackets to the mounting ears on the top of the battery pack.
Page 74 HS3 Series On the top of the battery pack, align the locking brackets to the drilled holes and install the gaskets and M6*50 screws to secure the battery pack to the wall. On the left and right bottom sides of the battery pack, install M5*14 screws to secure two batteries.
Page 75 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. Figure 4.44. Installing the grounding plate...
Page 76 HS3 Series (Optional) If needed, repeat steps a and b to install the third battery. M6*50 5 N· m M5*14 2.5 N· m M5*14 2.5 N· m Figure 4.45. Installing the third battery...
Page 77 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.46. Installing the grounding plate...
Page 78 HS3 Series Step 3. (Optional) Install the EV charger (CU2-11K-T-1). Get the holster from the charger package. Install the holster onto the right side of the charger. Place the charger onto the battery. Push it downwards. On the left and right bottom sides of the battery pack, install M5*14 screws to secure the charger to the battery.
Page 79 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.48. Installing the grounding plate...
Page 80 Install the holster on the wall by using three M4*32 screws. Note: The holster is used to secure the charger cable. It is recommended that you purchase the cable from SAJ and connect the cable after all devices are installed. M4*32 5 N·...
Page 81 Notes: It is recommended that you connect the cable after all device installation is completed. ⚫ ⚫ It is recommended that you purchase the cable from SAJ. For a long cable, you can wrap the cable on the holster. ⚫...
Page 82 HS3 Series Figure 4.50. Connecting the charger cable Step 4. Install the inverter (HS3- k-T2-W-B, HS3- K-T2-W-P, HS3- k-T2-G-B, or HS3- K-T2-G-P). (Optional) If you have installed a charger, loosen the screws on the inverter, and remove the port cover, as shown below: Figure 4.51.
Page 83 HS3 Series Figure 4.52. Installing the inverter For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.53. Installing the grounding plate...
Page 84 HS3 Series Installation completion view Single stack: supporting 1 to 3 batteries Example of 3 batteries: Inverter + charger + batteries Inverter + batteries Figure 4.54. Completion view of a single stack...
Page 85: Optional) Installation Of Multiple Battery Stacks
HS3 Series 4.5.4. (Optional) Installation of multiple battery stacks About this task One inverter supports up to eight batteries; however, for safety reason, a maximum of three batteries can be installed vertically in one stack. Therefore, extra batteries must be installed in other stack(s) and the extra battery stack must be installed with a battery junction box (BC3-TV).
Page 86 HS3 Series Step 2. Depending on the battery type, perform as follows: ⚫ Type A battery pack: Install screws on both lower sides of the junction box to secure the junction box to the beneath battery. M5*14 2.5 N· m Figure 4.56.
Page 87 HS3 Series Type B battery pack: Install screws on both lower sides of the junction box to secure the ⚫ junction box to the beneath battery. M5*14 2.5 N· m Figure 4.57. Installing a battery junction box...
Page 88 HS3 Series For Australian version: Install and secure the metal grounding plate on both sides. M4*12 1.2 N· m Figure 4.58. Installing the grounding plate...
Page 89 HS3 Series Installation completion view Multiple battery stacks: supporting 4 to 8 batteries Take eight batteries as an example. Quantities of the batteries in different stacks are 2, 3, and 3, as shown below. The distance between each stack is 0.5 meter.
Page 90: Electrical Connection
HS3 Series ELECTRICAL CONNECTION...
Page 91: Safety Instructions
HS3 Series 5.1. Safety instructions Electrical connection must only be operated on by professional technicians. Operators must be aware that the inverter is a bi-power supply equipment. Before connection, necessary protective equipment must be employed by technicians including insulating gloves, insulating shoes, and safety helmet.
Page 92: Connect The Grounding Cable
HS3 Series Figure 5.2. AC-side cover opened 5.2.2. Connect the grounding cable About this task This additional grounding cable must be connected before other electrical connection. This inverter complies with IEC 62109-2 clause 13.9 for earth fault alarm monitoring. After system startup and commissioning, if a grounding error occurs, the ring light on the inverter LED panel will be lit up in red and an error code <44>...
Page 93 HS3 Series Procedure Step 1. Assemble the cable and OT/DT terminal. Figure 5.3. Preparing the grounding cable Heat shrink tube OT/DT terminal Step 2. Remove the M4*10 screw from the grounding port. Connect and secure the grounding cable。 M4*10 1.2 N· m...
Page 94: Optional) Install A Sim Card
HS3 Series 5.2.3. (Optional) Install a SIM card Only the 4G model provides the SIM card slot. Loosen the cover of the SIM card slot. Then, insert the SIM card into the slot. Figure 5.5. Loosening the cover on the SIM card slot...
Page 95: Optional) Assemble The Lan Electrical Connection
HS3 Series 5.2.4. (Optional) Assemble the LAN electrical connection About this task Only the W (Wi-Fi) model provides the LAN port. If you choose to use Wi-Fi connection manner or has an EMS connected in the ESS, no need to connect the LAN cable.
Page 96: Assemble The Ems Electrical Connection
Step 2. Use a standard RJ45 cable. Insert the cable through the cable fastener as shown below. Assembly the cable fastener. Figure 5.9. Preparing the EMS cable Step 3. Connect the cable from the EMS port on the inverter to the EMS port on SAJ eManager (EMS). Figure 5.10. Connecting the EMS cable...
Page 97: Install A Circuit Breaker
Manufacturer Zhejiang Chint Instrument & Meter Co., Ltd. Model DTSU666 Application 3-phase Nominal voltage 230 V Max. current 100 A per line conductor Class of accuracy Communication type RS485 If you need to use other meters, contact SAJ for consultation.
Page 98: Connect The Grid And Backup Loads
HS3 Series 5.2.9. Connect the grid and backup loads About this task Depending on your system configuration, the grid and backup load ports on the inverter are ⚫ different. Accordingly, the grid and backup load connector kits are different in the accessory bags.
Page 99 HS3 Series ◼ Type A ports Procedure Step 1. Strip the insulation off (13-mm length) the cables. Step 2. Insert the cables through the dustproof cover, nut, and connector body of the connector and secure the cables to the terminal block with a spanner.
Page 100 HS3 Series Step 3. Remove the dustproof covers from the GRID and BACK-UP ports. Use a flathead screwdriver to press down the tab in the cover. Rotate the cover anti-clockwise and pull it upwards. Figure 5.12. Removing the dustproof covers Step 4.
Page 101 HS3 Series ◼ Type B ports Procedure: Step 1. Strip the insulation off (13-mm length) the cables. Step 2. Insert the cables through the dustproof cover, nut, and connector body of the connector and secure the cables to the terminal block with a spanner.
Page 102 HS3 Series Remove the dustproof covers from the GRID and BACK UP ports. Use a screwdriver to loosen the screw of the dustproof cover. Pull the covers upwards. Figure 5.15. Removing the dustproof cover Step 3. Connect the cables to the GRID and BACKUP ports on the inverter.
Page 103: Assemble The Communication Connection
HS3 Series Step 4. Tighten the screws of the GRID and BACKUP ports on the inverter. Figure 5.17. Securing the grid and backup load connectors 5.2.10. Assemble the communication connection Step 1. Disassemble the communication cable connector. ① Press the tabs on two sides of the connector terminal inwards and pull out the terminal from the connector body.
Page 104 HS3 Series Figure 5.18. Disassembling the 24-pin communication cable connector Step 2. Prepare cables. ⚫ Meter communication: Use the provided communication cable kit. It contains a communication cable and cable fastener parts. The cable provides an RJ45 port and two assembled terminals.
Page 105 HS3 Series Figure 5.20. Installing the insulated crimp terminals on the cable ends Step 3. Insert all communication cables through the nut, seals, and connector body. Figure 5.21. Inserting the cables through the connector Step 4. Locate the ports and terminals on the connection terminal block according to their silkscreens.
Page 106 HS3 Series 3: DRM3/7 For RCR 4: DRM4/8 For RCR 5: REF D/0 6: COM D/0 7: NC 8: NC Terminals DO1+ Dry output 1 DO1- Dry output 1 DO2+ Dry output 2 DO2- Dry output 2 RS485-A For external RS485 (with a 120 Ω...
Page 107 HS3 Series ⑤ ② ④ ① ③ Figure 5.22. Assembling the connector Step 6. Connect the assembled communication terminal connector to the COMM port on the inverter. Figure 5.23. Connecting the connector to the inverter...
Page 108 HS3 Series Step 7. Connect the other end of the cables to external devices. Meter connection: Take the communication cable (A) and smart meter out of the meter kit. For details, refer to the inverter package in section 4.4.2 "Check the package contents".
Page 109: Close The Ac-Side Cover
HS3 Series 5.2.11. Close the AC-side cover Push the cover downwards. Use a screwdriver to tighten the screw to lock the cover securely. Figure 5.24. Closing the AC-side cover Figure 5.25. Securing the screw...
Page 110: Assemble The Dc-Side Connection
HS3 Series 5.3. Assemble the DC-side connection 5.3.1. Open the DC-side cover Loosen the screw that locks the cover. Then, lift the cover upwards. Figure 5.26. Opening the DC-side cover Figure 5.27. DC-side cover opened...
Page 111: Connect The Pv Cables
HS3 Series 5.3.2. Connect the PV cables About this task Read the safety instructions first before operations. ⚫ DANGER · Dangerous to life due to electric shock when live components or DC cables are touched. · The PV panel string will produce lethal high voltage when exposed to sunlight. Touching live DC cables results in death or lethal injures.
Page 112 HS3 Series ⚫ Connect one end of the positive cable to the positive side of the solar panels and connect one end of the negative cable to the negative side of the solar panels. ⚫ Make sure that the DC switch on the inverter is in OFF position to avoid short circuit caused by maloperations.
Page 113 HS3 Series Step 3. Insert the assembled cable ends into the blue positive and negative connectors. Gently pull the cables backwards to ensure firm connection. Figure 5.32. Assembling the positive and negative cables Step 4. Tighten the lock screws on the positive and negative cable connectors.
Page 114: Optional) Connecting The Battery Cables Between Multiple Stacks
HS3 Series Figure 5.34. Connecting the PV cables 5.3.3. (Optional) Connecting the battery cables between multiple stacks About this task This task is only applicable to the scenario in which four to eight batteries are connected to one inverter. On top of the first stack, an inverter is installed; while in the top of other stacks, a battery junction box has been installed on top of the stack.
Page 115 HS3 Series Prerequisite For the battery stack without an inverter, a battery junction box (BC3-TV) has been installed on top of the stack. Procedure Step 1. Prepare and connect the grounding cable to the battery junction box. Figure 5.35. Connecting the grounding cable Step 2.
Page 116 Removing the waterproof cover The provided cables have been assembled with connectors. In some special cases, if you need ⚫ to use your own cables, contact SAJ for technical support. Taking eight batteries connecting to one inverter as an example: BAT+...
Page 117: Close The Dc-Side Cover
HS3 Series 5.3.4. Close the DC-side cover Push the cover downwards. Use a screwdriver to tighten the screw to lock the cover securely. Figure 5.38. Closing the DC-side cover Figure 5.39. Securing the screw...
Page 118: System Connection
HS3 Series 5.4. System connection 5.4.1. For Europe The system connection for the grid system without special requirements is as below: Note: The backup PE line and earthing bar must be grounded properly. Otherwise, the backup function may be inactive during blackout.
Page 119: For Australia And New Zealand
HS3 Series 5.4.2. For Australia and New Zealand Notes: For safety, the neutral cable of AC and backup side must be connected together. ⚫ DO NOT connect the PE terminal of the BACKUP side. ⚫ ⚫ The E-BAR and the N-BAR must be short-circuited.
Page 120: System Connection Diagram
HS3 Series 5.5. System connection diagram If the length of the RS485 cable between the inverter and the meter exceeds 20 meters, connect a 120Ω resistor to ports 24 and 25 on the meter. One HS3 ⚫ CT wire 250 A meter...
Page 121 HS3 Series Configuration Instructions ⚫ For other scenarios, refer to Chapter 4 “System Connection: Three-phase hybrid inverter” in the Multiple HS3 (parallelling scenario) One HS3 working with a solar inverter (AC coupling scenario) Multiple HS3 working with a solar inverter (AC coupling + parallelling scenario)
Page 122 HS3 Series...
Page 123: Startup And Shutdown
HS3 Series STARTUP AND SHUTDOWN...
Page 124: Startup
HS3 Series 6.1. Startup Step 1. (Optional) If there are multiple battery stacks, turn on the battery switch on the right side of the battery junction box. Step 2. On the left side of the inverter, perform as follows: Turn on BATTERY SWITCH.
Page 125: Commissioning
HS3 Series COMMISSIONING...
Page 126: About The Elekeeper App
HS3 Series 7.1. About the Elekeeper App The Elekeeper App can be used for both nearby and remote monitoring. Depending on the communication module used, it supports Bluetooth/4G or Bluetooth/Wi-Fi to communicate with your energy storage system (ESS). 7.2. Download the App On your mobile phone, search for “Elekeeper”...
Page 127: System Maintenance
HS3 Series SYSTEM MAINTENANCE...
Page 128: Routine Maintenance
HS3 Series 8.1. Routine maintenance To ensure that the system can operate properly for a long term, routine maintenance is recommended. To purchase the routine maintenance service, contact the installer, distributor, or SAJ after sales. Check item Check method Maintenance interval...
Page 129: Troubleshooting
HS3 Series Grounding Check whether the PE cable is securely 6 months after the first commissioning reliability connected. and once every 6 to 12 months after that Sealing Check whether all terminals and ports Once a year are properly sealed.
Page 130 HS3 Series Error code Error message Master Phase1 DCV Error Master Phase2 DCV Error Master Phase3 DCV Error Master No Grid Error DC ReverseConnect Error Parallel machine CAN Com Error Master GFCI Error Master Phase1 DCI Error Master Phase2 DCI Error...
Page 131 HS3 Series Error code Error message BMS Lost.Conn Warn AFCI Lost Com.Err Lost Communication between inverter and PV Meter EV_Lost.Conn Warn DCDC_Lost.Conn Warn DCDC_ Device Error Grid Power Emergency Disconnect Lost Communication D<->C Master Arc Device Error Master PV Mode Error...
Page 132 HS3 Series Error code Error message Charge Cell Under Temperature Protect Charge Cell Over Temperature Protect Discharge Cell Under Temperature Protect Discharge Cell Over Temperature Protect Relay Error Pre-charge Error Insulation Error BMS supplier Incompatibility Battery cell supplier Incompatibility Battery cell Incompatibility...
Page 133 HS3 Series Error code Error message Battery Voltage Exceeds BMS Upper Limit Fault Battery Voltage Exceeds BMS Lower Limit Fault Battery Side Precharge Fault Bus Voltage Overvoltage Fault Bus Voltage Undervoltage Fault Bus Discharge Overcurrent Fault Bus Charge Overcurrent Fault...
Page 134 HS3 Series Error code Error message AC over current AC over frequency AC under frequency DC residual current exception A Emergency Stop Under temperature AC residual current Input terminal over temperature Bluetooth fault DC residual current exception B Relay exception...
Page 135 HS3 Series...
Page 136: Product Specifications
HS3 Series PRODUCT SPECIFICATIONS...
Page 137: European Version
HS3 Series NOTICE Depending on the countries or regions, the specifications of the products might vary due to local regulations. 10.1. European version 9.2.2. System HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) Model HS3-6K-T2-(W, HS3-8K-T2-(W, G)- HS3-3K-T2-(W, HS3-4K-T2-(W, HS3-5K-T2-(W,...
Page 138 HS3 Series HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) Model HS3-6K-T2-(W, HS3-8K-T2-(W, G)- HS3-3K-T2-(W, HS3-4K-T2-(W, HS3-5K-T2-(W, G)-(B, P) G)-(B, P) G)-(B, P) G)-(B, P) (B, P) Parameter HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) 12000 ⚫ Rated AC Power [W]...
Page 139 HS3 Series HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) Model HS3-6K-T2-(W, HS3-8K-T2-(W, G)- HS3-3K-T2-(W, HS3-4K-T2-(W, HS3-5K-T2-(W, G)-(B, P) G)-(B, P) G)-(B, P) G)-(B, P) (B, P) Parameter HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) AC Output [Back-up] 11000 12000 ⚫...
Page 140 HS3 Series HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) Model HS3-6K-T2-(W, HS3-8K-T2-(W, G)- HS3-3K-T2-(W, HS3-4K-T2-(W, HS3-5K-T2-(W, G)-(B, P) G)-(B, P) G)-(B, P) G)-(B, P) (B, P) Parameter HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) - Ports on the inverter: VP-D4B-PHSM4 and VP-D4B-PHSF4 MC4 (optional) ⚫...
Page 141: Battery Pack
HS3 Series HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) Model HS3-6K-T2-(W, HS3-8K-T2-(W, G)- HS3-3K-T2-(W, HS3-4K-T2-(W, HS3-5K-T2-(W, G)-(B, P) G)-(B, P) G)-(B, P) G)-(B, P) (B, P) Parameter HS3-10K-T2-(W, G)- HS3-12K-T2-(W, G)- (B, P) (B, P) Weight [kg] Warranty [Year] Refer to the warranty policy.
Page 142: Charger
HS3 Series Model BC3-TV Parameter Communication Port Dimension [mm] (H*W*D) 150*695*170 Weight [kg] 9.2.5. Charger Model CU2-11K-T-I Parameter Input Power supply 3L+N+PE Rated Voltage [V AC] 230/400, ± 20% Rated Current [A] Frequency [Hz] 50/60 Output Output Voltage [V AC] 400, ±...
Page 143 HS3 Series Communication Wi-Fi 2.4G only Max. RF Output Power <20 dBm (-10 dBW) Safety Ingress Protection IP54 Electrical Protection Over-current protection ⚫ ⚫ Residual current protection Surge protection ⚫ Over-voltage and under-voltage protection ⚫ ⚫ Over-frequency and under-frequency protection Over temperature protection ⚫...
Page 144: Australian Version
HS3 Series 10.2. Australian version 9.2.1. System Model HS3-5K-T2-W-P HS3-8K-T2-W-P HS3-10K-T2-W-PX-BE Parameter DC Input Max. PV Array Power [Wp]@STC 10000 12000 15000 Max. Input Voltage [V] 1000 Start Voltage / Min. Input Voltage[V] Rated Input Voltage [V] MPPT Voltage Range [V] 180–900...
Page 145 HS3 Series Model HS3-5K-T2-W-P HS3-8K-T2-W-P HS3-10K-T2-W-PX-BE Parameter Max. AC Fault Current [A] Max. AC Over-Current Protection 20.8 33.3 41.8 Connection Manner 3L+N+PE 220/380, 230/400, 240/415 Rated AC Voltage / Range [V AC] 180-280/312-485 50 Hz: 45–55 Rated Output Frequency and Range ⚫...
Page 146 HS3 Series Model HS3-5K-T2-W-P HS3-8K-T2-W-P HS3-10K-T2-W-PX-BE Parameter Power Factor [cos φ] 0.8 leading to 0.8 lagging Efficiency Max. Efficiency 98.0% Euro Efficiency 97.6% Protection Battery Input Reverse Polarity Integrated Protection Overload Protection Integrated AC Short Circuit Current Protection Integrated DC Surge Protection...
Page 147: Battery Pack
HS3 Series Model HS3-5K-T2-W-P HS3-8K-T2-W-P HS3-10K-T2-W-PX-BE Parameter ⚫ RS485 ⚫ Dry contact ⚫ General Parameters Topology Transformer-less -30℃ to +50℃ Operating Temperature Range >45 ℃ derating Storage Temperature Range -10℃ to +40℃ Cooling Method Natural convection Ambient Humidity 5–95% non-condensing Max.
Page 148: Battery Junction Box
HS3 Series Without the base: 52 ⚫ Nominal Voltage [V] Operating Voltage [V] 380–500 Max. Charging Current [A] Max. Discharging Current [A] Battery Designation IFpP170/695/370/(1P16S) M/-10+50/90 Ingress Protection IP65 Ground-mounting ⚫ Mounting Wall-mounting ⚫ Operating Temperature Range -30℃ to +50℃...
Page 149: Appendix
HS3 Series APPENDIX...
Page 150: Recycling And Disposal
Check the product warranty conditions and terms on the SAJ website: https://www.saj-electric.com/ 10.3. Contacting support Guangzhou Sanjing Electric Co., Ltd. Address: SAJ Innovation Park, No.9, Lizhishan Road, Guangzhou Science City, Guangdong, P.R.China. Postcode: 510663 Website: https://www.saj-electric.com/ Technical Support & Service...
Page 151 HS3 Series GUANGZHOU SANJING ELECTRIC CO.,LTD Tel: (86)20 66608588 Fax: (86)20 66608589 Web: www.saj-electric.com Add: SAJ Innovation Park,No.9, Lizhishan Road, Science City, Guangzhou High-tech Zone , Guangdong, P.R.China...

SAJ HS3 Series User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SAJ HS3 Series

Summary of Contents for SAJ HS3 Series

This manual is also suitable for:

Table of Contents
