Try our online help hub. Description of keys helphub.starrvcom helphub.jucy.com IGNITION KEY: Use the indicated ignition key to: Start your vehicle 2. Lock or unlock the fuel tank’s cap. CABIN DOOR: Use this key to lock or unlock the vehicle’s side entry door lock.
Try our online help hub. Vehicle equipment helphub.starrvcom helphub.jucy.com FIRE EXTINGUISHER Each vehicle is equipped with a dry chemical fire extinguisher, meticulously selected to address both type B fires (involving grease and liquids) and type C fires (involving electrical elements). To deploy the extinguisher effectively, grasp the ring situated atop the bottle, direct the nozzle towards the top of the flames, and press down the lever firmly.
Try our online help hub. Starting the vehicle helphub.starrvcom helphub.jucy.com Gearstick must be in PARK and your foot on the pedal for the vehicle to start. The dashboard will display a ‘P’ indicating the vehicle is in Park. Start the vehicle using the ignition key.
Try our online help hub. Windows & vents helphub.starrvcom helphub.jucy.com WINDOWS To open the windows on board your vehicle, turn the handles inwards. Push the window out and click the latch in place. To access the blind and flyscreen, Pull the bottom metal handle up and the top metal handle down.
Try our online help hub. Cabin door helphub.starrvcom helphub.jucy.com The entrance door may be opened from outside the vehicle by pulling the door handle outward. To open the door from the inside, pull the door handle downwards and apply slight pressure to the door.
Try our online help hub. Outdoor step helphub.starrvcom helphub.jucy.com Your motorhome is equipped with an electric side doorstep and will ONLY operate while the vehicle is off. Please make sure you press the down button to open the step and up button to close the step. The switch to operate the sidestep is located on the righthand kitchen wall.
Try our online help hub. Seatbelts helphub.starrvcom helphub.jucy.com It is the law in New Zealand, that all passengers in a motorhome must be properly restrained with seatbelts. Vehicles are equipped with both lap and shoulder belts. Only seats fitted with seatbelts can be occupied while the vehicle is moving. To use, insert the belt tongue into the correct buckle until you feel it click and latch.
Try our online help hub. 240-volt electrical system helphub.starrvcom helphub.jucy.com To run the microwave, power points, air conditioner and to recharge the house battery, connect the motorhome’s 15 AMP electricity cord to a 240-volt external power source. The listed devices will only work if you are connected to 240-volt power.
Try our online help hub. 12-volt electrical system helphub.starrvcom helphub.jucy.com Your motorhome has two batteries, one in the engine compartment and one in the rear of the cabin. The battery inside the cabin is also called the auxiliary battery. The engine compartment battery is located under the passenger’s side, in the main driver’s cabin.
Problem: Microwave is operable (light on, turntable working) but is not heating food. Possible cause: Microwave may be broken. Please call the Star RV, On roads team for assistance. Problem: Sparks or arcing when the microwave is turned on.
Try our online help hub. Freshwater helphub.starrvcom helphub.jucy.com On board the vehicle is a freshwater system consisting of a water pump and freshwater tank. The water tank has a 120L freshwater tank and is located on the passenger side of the vehicle. This water is for the sink, shower and toilet flush. To check the level of your Fresh water press the button on the Tank panel.
Try our online help hub. Greywater tank helphub.starrvcom helphub.jucy.com The grey water holding tank collects wastewater from the kitchen, bathroom sink and shower. You can check the level of your water on the 12-volt switchboard as seen in the picture. It is not uncommon for the greywater level indicator to give an inaccurate reading.
Try our online help hub. Water pump helphub.starrvcom helphub.jucy.com To use water on board the vehicle, ensure there is water in your freshwater tank outside. On the switchboard, press the Water PUMP symbol once. You must have this this button on to operate the kitchen tap, shower and the toilet flush.
Try our online help hub. Hot water helphub.starrvcom helphub.jucy.com The switch to activate the gas-operated water heater system is situated in the domestic control panel. To operate the water heater in your vehicle, please follow the below steps: Step 1: Turn the gas bottle, to the 'on' position, ensuring the valve is fully opened. Twist the valve on the gas bottle counterclockwise to open and clockwise to close.
Try our online help hub. Toilet use helphub.jucy.com helphub.starrvcom Turn on the water pump and toilet switch on the domestic control panel. 2. Push the blue button on the toilet to fill the base with water 3. Once finished, adjust the lever on the bottom of the toilet to empty into cassette 4.
Try our online help hub. Toilet cassette helphub.starrvcom helphub.jucy.com It is highly recommended to regularly empty the toilet cassette, and it is mandatory to empty and clean it before returning the vehicle to the depot. To empty the cassette, lift the blue lever and remove the entire cassette from the vehicle.
3. Shut off the gas supply at the gas bottle using the valve on top of the bottle. 4. Open doors, windows, hatches, and any other ventilation openings. 5. Evacuate the area until the gas odour dissipates. 6. Contact STAR RV for assistance. manual VEHICLE Page 20 of 37...
Try our online help hub. Stove top & grill helphub.starrvcom helphub.jucy.com Warning: It is not safe to use cooking appliances for comfort heating. How it operates The gas burners in the vehicle operate on LPG. The basic operation is the same as a gas stove in a house. However, the amount of oxygen in a motorhome is limited due to its size;...
Try our online help hub. Fridge helphub.starrvcom helphub.jucy.com To turn on the fridge turn on the domestic switch The fridges should already be set to auto meaning that the fridge will automatically find the next available power source. To tell if it is on auto on the display screen will be the words AUTO This Motorhome is equipped with a 3-way fridge this means that the fridge will operate on 3 different power supplies.
Page 22
Try our online help hub. Setting the temperature The Fridge is set to the correct temperature which is 3 bars illuminated. If this is showing lower or you want to increase: helphub.starrvcom helphub.starrvcom Push the circle dial in. The icons on the screen will dim with the icon you want will be illuminated.
LED 3 red – illuminated – (fault) Red LED illuminates The device is indicating a fault. Switch device off, wait for a short time and switch on again. If the red LED continues to illuminate, please call Star help line. IMPORTANT: Always ensure to turn off the air conditioner unit using the remote before disconnecting the vehicle from the 240v mains power.
Try our online help hub. Stereo helphub.starrvcom helphub.starrvcom The back media play is for use to play your music while the vehicle is off. There are speakers inside and on the outside of the vehicle. To operate Turn on the media switch on in the domestic control panel and then on the stereo 2.
Page 25
Try our online help hub. To move to the next zone, push the dial and the next zone will be highlighted manual VEHICLE Page 26 of 37 2024005 Vehicle Manual Templates Round 1...
Try our online help hub. Heater helphub.starrvcom helphub.starrvcom Heating symbol Operating Button Led ring. Back button 13. Press the operating button (2) and scroll to the heating symbol (1) which look like wavy arrows. Press the button to confirm. Scroll either left or right to the desired time you want the heating to run and press the dial to confirm.
Try our online help hub. Lights helphub.starrvcom helphub.jucy.com To use the cabin lights, turn on the light switch on the domestic control panel. Use the switches on the wall of the motorhome to turn on the lights. Switches by the cabin door control the Kitchen, Outside, Dining area and Front ceiling lights Switches by the TV control the toilet, Shower, You can operate the lights individually by turning...
Try our online help hub. Bed conversion helphub.starrvcom helphub.jucy.com There are three double beds on board your motorhome. To make up each of the beds, please follow these instructions: BED 1 (middle dinette) Step 1: Remove the tabletop from the attachment on the seat. Step 2: halfway down the table leg is a button you push to fold the table leg in half Step 3: Insert the tabletop between the two seats so that it is resting on the ledges...
Page 29
Try our online help hub. BED 2 (Rear dinette) helphub.starrvcom helphub.jucy.com Step 1: Pull handle 1 out and rotate right. Clip back in and rotate left; repeat to loosen and remove the table top. Repeat for handles 2 & 3 and remove table leg. and put aside.
Page 30
Try our online help hub. BED 3 (Overhead bed) The overhead bed can be accessed using the ladder stored next to the helphub.starrvcom helphub.jucy.com compartment. This ladder must be connected to the attachment points horizontally to ensure that it is secure for use. The bed can then be secured with the provided net.
Try our online help hub. Awning helphub.starrvcom helphub.jucy.com To roll out the awning: 1- The awning handle is located in the back compartment. 2- Connect the hook on the end of the crank to the awning. 3- Partially deploy the awning about halfway, or just enough so you (or your helping hands) can reach the front of the awning to access the legs.
Page 32
Try our online help hub. 7- Slide the rafter arms up until they ‘click’ securely into the side mounts. 8- Tighten the locking knobs on both rafter arms. 9- Retrack the awining to the height you need. *If there are no side mounts on the motorhome then the legs can be pegged to the ground.
Once filled with diesel, place the fuel cap on the inlet and turn the key clockwise to lock it. IMPORTANT: The vehicle accepts diesel fuel only. If you fill the vehicle with unleaded, water or AdBlue, please do not start the engine and call STAR RV Roadside Assistance immediately. manual...
Try our online help hub. AdBlue helphub.starrvcom helphub.jucy.com Every 2500 km the vehicle will require AdBlue to be refilled. If the AdBlue level is low, a warning light or symbol illuminates on the dashboard and a message advises you to top up the AdBlue tank. Please find the nearest fuel station or auto shop which supplies AdBlue and refill the vehicle with AdBlue as soon as possible.
Try our online help hub. Jack & spare tyre helphub.jucy.com helphub.starrvcom The tools can be found as follows: they are located under the front driver’s seat. The spare tyre can be found underneath the rear of the vehicle. To access it, use the provided tool.
