Whelen Engineering Company WeCanX Tracer Series Installation Manual
Whelen Engineering Company WeCanX Tracer Series Installation Manual

Whelen Engineering Company WeCanX Tracer Series Installation Manual

Lightbar

Advertisement

51 Winthrop Road
Chester, Connecticut 06412-0684
Phone: (860) 526-9504
Internet: www.whelen.com
Sales e-mail: autosale@whelen.com
Customer Service e-mail: custserv@whelen.com
Whelen's emergency vehicle warning devices must be properly mounted and wired in order to be effective and safe. Read and follow all of Whelen's written
instructions when installing or using this device. Emergency vehicles are often operated under high speed stressful conditions which must be accounted for
when installing all emergency warning devices. Controls should be placed within convenient reach of the operator so that they can operate the system without
taking their eyes off the roadway. Emergency warning devices can require high electrical voltages and/or currents. Properly protect and use caution around
live electrical connections.Grounding or shorting of electrical connections can cause high current arcing, which can cause personal injury and/or vehicle
damage, including fire. Many electronic devices used in emergency vehicles can create or be affected by electromagnetic interference. Therefore, after
installation of any electronic device it is necessary to test all electronic equipment simultaneously to insure that they operate free of interference from other
components within the vehicle. Never power emergency warning equipment from the same circuit or share the same grounding circuit with radio
communication equipment. All devices should be mounted in accordance with the manufacturer's instructions and securely fastened to vehicle elements of
sufficient strength to withstand the forces applied to the device. Driver and/or passenger air bags (SRS) will affect the way equipment should be mounted. This
device should be mounted by permanent installation and within the zones specified by the vehicle manufacturer, if any. Any device mounted in the deployment
area of an air bag will damage or reduce the effectiveness of the air bag and may damage or dislodge the device. Installer must be sure that this device, its
mounting hardware and electrical supply wiring does not interfere with the air bag or the SRS wiring or sensors. Mounting the unit inside the vehicle by a
method other than permanent installation is not recommended as unit may become dislodged during swerving; sudden braking or collision. Failure to follow
instructions can result in personal injury. Whelen assumes no liability for any loss resulting from the use of this warning device. PROPER INSTALLATION
COMBINED WITH OPERATOR TRAINING IN THE PROPER USE OF EMERGENCY WARNING DEVICES IS ESSENTIAL TO INSURE THE SAFETY OF
EMERGENCY PERSONNEL AND THE PUBLIC.
Whelen's emergency vehicle warning devices are intended to alert other operators and pedestrians to the presence and operation of emergency vehicles and
personnel.
However, the use of this or any other Whelen emergency warning device does not guarantee that you will have the right-of-way or that other
drivers and pedestrians will properly heed an emergency warning signal. Never assume you have the right-of-way. It is your responsibility to proceed safely
before entering an intersection, driving against traffic, responding at a high rate of speed, or walking on or around traffic lanes. Emergency vehicle warning
devices should be tested on a daily basis to ensure that they operate properly. When in actual use, the operator must ensure that both visual and audible
warnings are not blocked by vehicle components (i.e.: open trunks or compartment doors), people, vehicles, or other obstructions. It is the user's responsibility
to understand and obey all laws regarding emergency warning devices. The user should be familiar with all applicable laws and regulations prior to the use of
any emergency vehicle warning device. Whelen's audible warning devices are designed to project sound in a forward direction away from the vehicle
occupants. However, because sustained periodic exposure to loud sounds can cause hearing loss, all audible warning devices should be installed and
operated in accordance with the standards established by the National Fire Protection Association.
Safety First
This document provides all the necessary information to allow your Whelen product to be properly and safely installed. Before beginning the installation and/or
operation of your new product, the installation technician and operator must read this manual completely. Important information is contained herein that could
prevent serious injury or damage.
WARNING: This product can expose you to chemicals including Methylene Chloride which is known to the State of California to cause cancer, and
Bisphenol A, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
Proper installation of this product requires the installer to have a good understanding of automotive electronics, systems and procedures.
Whelen Engineering requires the use of waterproof butt splices and/or connectors if that connector could be exposed to moisture.
Any holes, either created or utilized by this product, should be made both air- and watertight using a sealant recommended by your vehicle
manufacturer.
Failure to use specified installation parts and/or hardware will void the product warranty.
If mounting this product requires drilling holes, the installer MUST be sure that no vehicle components or other vital parts could be damaged
by the drilling process. Check both sides of the mounting surface before drilling begins. Also de-burr the holes and remove any metal shards
or remnants. Install grommets into all wire passage holes.
If this manual states that this product may be mounted with suction cups, magnets, tape or Velcro®, clean the mounting surface with a 50/50
mix of isopropyl alcohol and water and dry thoroughly.
Do not install this product or route any wires in the deployment area of your air bag. Equipment mounted or located in the air bag deployment
area will damage or reduce the effectiveness of the air bag, or become a projectile that could cause serious personal injury or death. Refer to
your vehicle owner's manual for the air bag deployment area. The User/Installer assumes full responsibility to determine proper mounting
location, based on providing ultimate safety to all passengers inside the vehicle.
For this product to operate at optimum efficiency, a good electrical connection to chassis ground must be made. The recommended
procedure requires the product ground wire to be connected directly to the NEGATIVE (-) battery post (this does not include products that use
cigar power cords).
If this product uses a remote device for activation or control, make sure that this device is located in an area that allows both the vehicle and
the device to be operated safely in any driving condition.
Do not attempt to activate or control this device in a hazardous driving situation.
This product contains either strobe light(s), halogen light(s), high-intensity LEDs or a combination of these lights. Do not stare directly into
these lights. Momentary blindness and/or eye damage could result.
Use only soap and water to clean the outer lens. Use of other chemicals could result in premature lens cracking (crazing) and discoloration.
Lenses in this condition have significantly reduced effectiveness and should be replaced immediately. Inspect and operate this product
regularly to confirm its proper operation and mounting condition. Do not use a pressure washer to clean this product.
It is recommended that these instructions be stored in a safe place and referred to when performing maintenance and/or reinstallation of this
product.
FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE
AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS!
©2023 Whelen Engineering Company Inc.
Form No.14E24G (062223)
Warnings to Installers
Warnings to Users
For warranty information regarding this product, visit www.whelen.com/warranty
Page 1
Installation Guide:
WeCanX™ Tracer™ Series Lightbar

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WeCanX Tracer Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Whelen Engineering Company WeCanX Tracer Series

  • Page 1 FAILURE TO FOLLOW THESE SAFETY PRECAUTIONS AND INSTRUCTIONS COULD RESULT IN DAMAGE TO THE PRODUCT OR VEHICLE AND/OR SERIOUS INJURY TO YOU AND YOUR PASSENGERS! ©2023 Whelen Engineering Company Inc. For warranty information regarding this product, visit www.whelen.com/warranty Form No.14E24G (062223)
  • Page 2 IMPORTANT NOTE FOR ALL MOUNTING OPTIONS: There is a label, saying “This Side Up” on each lightbar showing the correct orientation the lightbar should be mounted. Always refer to the direction indicated when mounting the lightbar. Running Board Mounting Mounting: 2015-19 Ford Explorer Universal L-Bracket 2015-18 Dodge Ram 1500 Crew Cab...
  • Page 3 Mounting: 2021 Chevrolet Tahoe PPV/SSV (with Factory Running Board) / 2021 Suburban IMPORTANT: These mounting brackets can only be used with factory equipped molded plastic running boards 2021 Suburban: Mounting is the same except the Suburban uses an extra mounting bracket (Fig. 6) The Tracer™...
  • Page 4 Mounting: 2009-18 Chevy Silverado 1500 (with Factory Running Board) Using #6-32 x ¼ self-tapping screws (included), loosely install the Tighten each of the 6 screws firmly to lock the Tracer™ into six stand-off blocks onto the mounting bracket as shown with position.
  • Page 5 Mounting: 2015-21 Ford F-150 (with Factory Running Board) 2017-21 Ford F-250/350 (with Factory Running Board) 2018-21 Ford Expedition (with Factory Running Board) F-150: Using the hardware removed in Step 1, install these brackets onto the vehicle in the same location as the existing Fig.
  • Page 6: Installation

    Mounting: 2020-21 Ford Interceptor SUV (with Factory Running Board) MOUNTING CLIP MOUNTING CLIP #10 Flat Washer 10-24 Elastic Stop Nut 10 - 24 X 3/4 Hex Head 5/16 Flat Washer MOUNTING 5/16 Split Lock Washer CLIP 5/16 X 1” Hex Bolt Mtg.
  • Page 7 Lightbar Mounting Mounting the brackets: FRONT VIEW 1. Flip the lightbar upside-down and place the bracket onto the 1/2" minimum clearance at closest point track in the middle of the extrusion, sliding one side of the bracket under one of the lips on the extrusion (Fig. 2). Rotate the bracket 90°...
  • Page 8: Connecting The Power Cable

    Mounting: 2019-21 Chevrolet Silverado: Fig. 3 Bracket Orientation Fig. 1 #6-32 x 1/4 Phillips Installing Fan Head Machine slider to Screw Bracket Spacer T I N T I N I D E Fig. 4 Installing bracket to lightbar Loosely install the slides and spacers onto the four mounting brackets using the supplied 6 - 32 X 1/ 4 Phillips Fan Head Machine Screws (Fig.
  • Page 9 Mounting: 2021 - 22 Tesla Tracer™: Remove the 2 lower plastic trim pieces. Remove the lower one (Fig. Remove the battery securing bolt and install a Tracer™ mounting bracket (Fig. 2). There are 8 bolts per side that secure the battery.
  • Page 10: Hardware Kit

    Mounting: 2021-2022 Ford Mach-E Hardware Kit: • Mounting Bracket (x5) Battery Battery • 10-24 x 3/4” Hex Screw (x5) • 10-24 Elastic Stop Nut (x5) Bolt Bolt • #10 Flat Washer (x5) 10-24 10-24 5/16 Flat 5/16 Flat Stop Nut Stop Nut 1.
  • Page 11 2.04 “L” 0.67 (REFER TO SIZE CHART) 0.30 0.93 TRACER™ SIZE CHART PART NUMBER DESCRIPTION 13.80" 01-0688807-01 FINAL ASSEMBLY, WeCanX™ TRACER™ 1 MODULE 26.16" 01-0688807-02 FINAL ASSEMBLY, WeCanX™ TRACER™ 2 MODULE 38.53" 01-0688807-03 FINAL ASSEMBLY, WeCanX™ TRACER™ 3 MODULE 50.90" 01-0688807-04 FINAL ASSEMBLY, WeCanX™...
  • Page 12 2020 - DODGE DURANGO 2019 - FORD UTILITY QTY. ITEM PART NUMBER DESCRIPTION QTY. ITEM PART NUMBER DESCRIPTION TRACER™ SERIES 01-0488807-75 01-0488807-15 TRACER™ SERIES 01-0488807-00 GENERIC MOUNTING KIT 07-247359-023 BRKT, MTG CONTOUR EXPLORER BLK TRACER™ SERIES 2020 - DODGE RAM 1500 07-247360-023 BRACKET, MTG FLAT EXPLORER BLK TRACER™...
  • Page 13 2022 - TESLA MODEL Y QTY. ITEM PART NUMBER DESCRIPTION 01-0488807-J5 TRACER™ SERIES 07-248393-023 BRACKET, TESLA MODEL Y BLACK, TRACER™ 14-104436-120 SCREW, 10-24 X 3/4" HEX HDMS SS 16-1001220-06 WASHER, #10 FLAT 18-8 SS 13-104132-062 NUT, 10-24 ELASTIC STOP BRASS NICKEL PLATE Page 13...

Table of Contents
