深圳市爱坤电子科技有限公司
AIKUN SHENZHEN ELECTRONIC COMPANY LTD.
2.1
SPECIFICATION AND USER MANUAL
Model NO.
MP DATE
Product picture
Sort
Projiect
keyboard type
Interface Type
Connection mode
Multimedia
function key
Operating voltage
battery
Charging current
Key type
Key load
Key life
Wireless light
sleep mode
Wireless keyboard
sleep mode
Switch type
Programmable
Page 1 Total 7
GX922WR
Specifications/Parameters
Mechanical luminescent
keyboard
USB
USB+2.4G+Bluetooth(3.0-5.0)
Support (FN+F1~F12 keys)
UBS 5V
3.7V-2400mAh
640mA
Mechanical switch
60g±10g
50 million times
Default 2 minutes
Default 30 minutes
Green axis/tea axis/black axis, etc
Yes "Software Driver"
TYPE
3 mode mechanical keyboard
DATE
Projiect
Layout version
Dimensions
(L*W*H)
Net weight
Receiver size (L *
W * H)
Net receiver
weight
Wireless color
Charging mode
Power switch
Interface
compatibility
System
compatibility
Backlight color
Low pressure
warning
Shutdown low
Keystroke
collision
VERSION:
2023/01/05
Specifications/Parameters
US/UK/optional
Without palm rest/443.5*141*40
With palm rest/443.5*204*40
Keyboard 827±10g / hand rest 146±5g
18.5*14.5*6.2mm
1.6g
Standard Black / OEM
Computer USB-5V power supply
Support
USB1.1/2.0/3.0
Win7/Win8/Win10/ MacOS X
10.5/Android4.4 and above
RGB
Around 3.3V
Around 3.0V
All keys do not conflict
Engineer: David Wu

Advertisement

loading
Need help?

Need help?

Do you have a question about the GX922WR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AIKUN GX922WR

  • Page 1 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: SPECIFICATION AND USER MANUAL Model NO. GX922WR TYPE 3 mode mechanical keyboard MP DATE DATE 2023/01/05 Product picture Sort Projiect Specifications/Parameters Projiect Specifications/Parameters keyboard type Mechanical luminescent Layout version US/UK/optional keyboard Interface Type Dimensions Without palm rest/443.5*141*40...
  • Page 2 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: Plug and play Support Inner Memory Storage Character Print Double shot injection + laser engraving Macro keys Yes “Software Driver” Solution (IC model) IC manufacturer Rongyuan Technology YC3121-SOC IC package QFN56 IC package...
  • Page 3 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: Material Specifications Parts Color/ Specification Surface treatment Material Cover Black or Gray Brushed Aluminum Matt / Bottom Cover Black – other color Optional Keycap Black – other color Optional ABS / BPT Decorative strip Black –...
  • Page 4 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: 使用说明: 1. Unpack the product package, remove the cable tie of the keyboard cable, and insert the cable into the USB port of the computer. 2. When using this keyboard for the first time, the system may need to install the USB driver, then the computer will automatically search and install the keyboard driver.
  • Page 5 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: SPECIFICATION AND USER MANUAL 产品型号/Model NO. GX922WR 产品类别/TYPE 3 模机械键盘 量产日期/MP DATE 修订日期/DATE 2023/01/05 产品图片 分类 项 目 规格/参数 项 目 规格/参数 键盘类型 机械发光键盘 按键语言文版 US/UK/PT/可选 键盘尺寸(长*宽* 不带手托:443.5*141*40 接口类型 高) 带托手: 443.5*204*40 键盘 875±10g 连接工作方式...
  • Page 6 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: 键盘主控 (IC 型 YC3121-SOC IC 厂 商 深圳市容圆科技有限公司 号) IC 封装 QFN56 接收器芯片 RY6010 封装 QFN32 260mA(默认:随波逐流) 无线工作电流 480mA (白光全亮) 无线工作电流 电性 (默认:光波) 参数 2.4G 工作电流 15mA(无灯光) 蓝牙 3.0 工作电流 11mA(无灯光) 蓝牙 5.0 工作电流...
  • Page 7 深圳市爱坤电子科技有限公司 AIKUN SHENZHEN ELECTRONIC COMPANY LTD. VERSION: 使用说明: 1. 拆开产品包装,取掉键盘线的扎带,将线材插入电脑的 USB 端口; 2. 第一次使用此键盘,系统可能需要安装 USB 驱动,这时电脑会自动搜索并安装好键盘的驱动; 3. 驱动安装完成后,键盘即可正常工作使用; 4. FN+ INS 可切换灯光模式(18 种模式)随波逐流、碧波荡漾、繁星点点、川流不息、如影随形、重峦叠嶂、 正弦波、彩泉涌动、踏雪无痕、百花争艳、一石二鸟、峰回路转、多彩纵横、满天飞雪、流星、 常亮、动态呼吸、光谱循环。 5. FN+ DEL 可切换模式颜色 6. FN+ ↑ / FN+ ↓ 可调节背光亮度 5 档可调 7. FN+ ← / FN+ → 可调节背光速度 5 档可调...
