Page 1
Aikun Shenzhen Electronic Company ltd. VERSION: 2.1 Specification And User Manual - VERSION: 2.1 Model NO. GX650ML RGB Product Type Wired Gaming keyboard Mass Production 2021-06-10 Patent No ZL 2021 3 0268708.1 ID Design 3 Sides Products Picture Class Item...
Page 2
Aikun Shenzhen Electronic Company ltd. VERSION: 2.1 Class Item Specification Item Specification HK9708 MCU Vendors Dakai Industrial IC package Working voltage DC4.2V-5.5V Operating current 200mA Operating current ≤50mA Working ℃ Storage ℃ 0~45℃ -20~+60℃ Working humidity Storage humidity ≤93% (40℃) 20~90%...
Page 3
Aikun Shenzhen Electronic Company ltd. VERSION: 2.1 1 - Gaming Keyboard IC This is a dedicated USB Gaming keyboard IC with built-in backlight control, and can work with a special matrix to achieve a fixed 26-key non-conflicting key function keyboard.
Page 4
Aikun Shenzhen Electronic Company ltd. VERSION: 2.1 12. Anti Ghosting Function - Special function description Special matrix: support 26 keys at the same time without conflict ("Q", "A", "Z", "W", "S", "X", "E", "D", "C"," B", "R","F","V","T","G","M","SPACE", "↑ (UP)", "↓ (Down)","← (Left) ”,”(Right t) →”), “Tab”, “Alt-L”, “Ctrl-L”, “Shift-L”, “CAPS”.
Page 5
Aikun Shenzhen Electronic Company ltd. VERSION: 2.1 Material specification parameter Components Components Material Design Upper case Black Bottom case Black Keycaps Black Membrane Transparent Dual PVC Silver Standard Rubber 15mm*6mm Rubber Dome Standard Stand Black ABS Standard Palm stand Black ABS Standard 1.6mm single side board...
